- Page 1 TEKMV41-HD HDMI 4x1 Quad Multi-Viewer (79079) User’s Manual 17, 2018 Dec. 1 / 12...
- Page 2 Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
-
Page 3: Table Of Contents
Table of Contents 1. Introduction ..............4 2. Features ............... 4 3. Package Contents ............4 4. Operation Controls and Functions ....... 5 4.1 Front Panel .............. 5 4.2 Rear panel ..............5 5. Display modes .............. 6 6. Remote Control ............7 7. -
Page 4: Introduction
1. Introduction The high performance 4x1 quad multi-viewer supports four high definition input contents be displayed on one screen simultaneously, and five multi-viewer display modes can be selected. The product can be controlled via the front panel button, remote control and RS-232. 2. -
Page 5: Operation Controls And Functions
4. Operation Controls and Functions 4.1 Front Panel POWER: System power indicator. IR: Remote control receiver window. AUDIO: Output audio selection or turn off the audio. MAIN: Input source selection. MODE: Select multi-viewer display modes. Please see the below detail description. -
Page 6: Display Modes
5. Display modes The quad multi-viewer has 5 display modes. MODE1: The quad multi-viewer will separate display the four HD inputs, and switch the MAIN button on front panel or IR remote, the HDMI output will change to the next source, the sequence is IN1-IN2-IN3-IN4-IN1… MODE2: The quad multi-viewer will divide the four HD inputs into the same size and display on one screen. -
Page 7: Remote Control
Attention: Switch the AUDIO button on front panel or buttons in Audio area on IR remote, the HDMI output audio will corresponding to the selected input source or be muted. 6. Remote Control Power /Standby: Press this button to power on the unit or set it to standby mode. -
Page 8: Connection Diagram
7. Connection Diagram 8 / 12... -
Page 9: Rs232 Commands
RS232 Commands Communication protocol: Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none Terminate with <CR> Hex 0D Feedback command name Terminate with <LF> Hex 0A Command Description PWR0 <CR> Power Off PWR1 <CR> Power On OSD0 <CR> OSD Off OSD1 <CR>... - Page 10 Command Description SWA1 <CR> Switch Audio Input 1 to Channel SWA2 <CR> Switch Audio Input 2 to Channel SWA3 <CR> Switch Audio Input 3 to Channel SWA4 <CR> Switch Audio Input 4 to Channel VBX0 <CR> Clear Split Line VBX1 <CR> Draw Split Line SWA0 <CR>...
-
Page 11: Specifications
9. Specifications Technical HDMI Compliance HDMI 1.4b, compliant with DVI 1.0 HDCP 1.4 HDCP Compliance 6.75Gbps Video Bandwidth 1080P@60Hz, 720p@60Hz, 480P@60Hz Video Resolutions RGB, YCbCr 4:4:4, YCbCr 4:2:2 Color Space 10-bit, 12-bit Color Depth HDMI Audio Formats LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X (Pass-through) Human body model —... - Page 12 Mechanical Metal Enclosure Housing Black Color 160.2mm [W] x 84mm [D] x 15.5mm [H] Dimensions 337g Weight Input: AC100 - 240V 50/60Hz Power Supply Output: DC 5V/2A (US/EU standards, CE/FCC/UL certified) Power Consumption 6W(Max) Operation 32 - 104°F / 0 - 40°C Temperature Storage temperature -4 - 140°F / -20 - 60°C...
