Read this manual thoroughly before installing, operating, or maintaining this lift. When done with installation be
sure to return documents to package and give all materials to lift owner/operator. When installation is complete
be sure to run lift up and down a few cycles with and without "typical" vehicle loaded on lift.
© September 2010 by Vehicle Service Group. All rights reserved.
PP9 Plus
Four Post Lift
9,000 lbs. Capacity
(4,500 lbs. per axle)
Minimum wheelbase 101" at rated capacity
INSTALLATION / OWNERS MANUAL
CO7703.1
Reference ANSI/ALI ALIS,
IMPORTANT
Safety Requirements for
Installation and Service of Automotive Lifts
before installing lift.
IN50004
Rev. E 07/19/2010

Advertisement

loading
Need help?

Need help?

Do you have a question about the PP9 Plus and is the answer not in the manual?

Questions and answers

Roy Shankel
May 26, 2025

I don't see any instructions or suggestion on lubing the lift ? I have the Direct-Life PP9 Plus.

0
1 comments:
Mr. Anderson
May 26, 2025

To lubricate the Direct-Lift PP9 Plus, use penetrating oil and wipe down the components. It is important to keep the lift free of corrosive agents and solvents, as failure to do so can reduce the service life of components, cause cable failure, and potentially lead to property damage or personal injury.

This answer is automatically generated

0

Related Manuals for Direct-Lift PP9 Plus

Summary of Contents for Direct-Lift PP9 Plus

  • Page 1 PP9 Plus Four Post Lift 9,000 lbs. Capacity (4,500 lbs. per axle) Minimum wheelbase 101" at rated capacity Reference ANSI/ALI ALIS, IMPORTANT Safety Requirements for Installation and Service of Automotive Lifts before installing lift. INSTALLATION / OWNERS MANUAL Read this manual thoroughly before installing, operating, or maintaining this lift. When done with installation be sure to return documents to package and give all materials to lift owner/operator.
  • Page 2 TABLE OF CONTENTS ........................pg 2 ............................ pg 4 ..........................pg 4 ..............................pg 5 ......................pg 6 ................... pg 8 ................. pg 9 ....................pg 13 ..........................pg 13 ..........................pg 15...
  • Page 3 ........................pg 13 ................... pg 15 ..........................pg 17 ........................pg 19 ........................pg 26 IMPORTANT INFORMATION Four Post Lifts 1. Always inspect the lift for damage and make note of any damage on the bill of lading. 2. In case of freight damage, call the truck line immediately and report the damage as a freight claim. 4.
  • Page 4 lifting methods particular to an individual application. Rather, the contents of this manual are intended as a basis for operation and maintenance of the unit as it stands alone or as it is intended and anticipated to be used in damages.

  • Page 6: Tools Required

    TOOLS REQUIRED INSTALLATION INSTRUCTIONS that is already connected to the cylinder. Locate the hole in the side of the runway and install the upside down. Place this runway in your bay with the hydraulic fitting facing toward your previously chosen corner for the power unit. ing bracket in the above chosen corner.
  • Page 7 Position the Crossbeams at the second lowest locking position on all columns. beam rail to the outside of the other Crossbeam rail measure's 184.5”. Compare the measurements from the runways later. for Cable routing installation. Reinstall the Cable Sheaves, Shafts, Spacers and hardware as shown in...
  • Page 8 lift to adjust for leveling. Each post has this adjustment. Adjust the proper columns to level the lift. Place level on each runway and crossbeam and check for proper levelness. will lock the Lock Ladder in position. up and down level.

  • Page 9: Foundation And Anchoring Requirements

    CASTER KIT INSTALLATION Raise the Lift two to four feet high and in below diagram. Install the four Pivot pins and Cotter pins to secure assembly to each column as shown below. Lower the Lift confirming that the Caster assemblies engage the Crossbeam rails and the four Columns FOUNDATION REQUIREMENTS Concrete shall have compression strength of at least 3,000 PSI and a minimum thickness of 4”.
  • Page 10 ANCHORING TIP INSTRUCTIONS CAUTION! Anchors must be at least 6” from the edge of the slab or any seam. move residue to reduce binding.
  • Page 11 low the anchor to be driven thru the bottom of foundation if the threads are damaged or if the lift will need to be relocated. For better holding power blow dust from the hole. OPERATION INSTRUCTIONS Only authorized personnel are to operate lift. Read Operating and safety procedures Manual completely before operating lift.

  • Page 13: Owner / Employer Responsibilities

    the lift runways. OWNER / EMPLOYER RESPONSIBILITIES The Owner / Employer: location in the lift area convenient to the operator. Lift Lockout/Tagout Procedure Purpose...
  • Page 14 sonnel by the operation of lifts in need of repair or being serviced. All employees shall comply with this proce- dure. Responsibility ed in the safety significance of the lockout procedure by the facility owner/manager. Each new or transferred designee) in the purpose and use of the lockout procedure. Preparation the lockout procedure.

  • Page 15: Safety Procedures

    Lift is not intended for outdoor use and has an operating ambient temperature range Read all instructions Care must be taken as burns can occur from touching hot parts. folds or moving fan blades. the outlet. Grasp plug and pull to disconnect. safety glasses.

  • Page 16: Preventive Maintenance Schedule

    tected indoor location. Failure by the owner to provide the recommended shelter could result in unsatisfactory lift performance, property damage, or personal injury. PREVENTIVE MAINTENANCE SCHEDULE Periodic maintenance is to be performed on a daily, weekly, and yearly basis as given in the following para- graphs.
  • Page 17 Weekly Maintenance (every 40-Hours) use an impact wrench to tighten anchor bolts. Yearly Maintenance Special Maintenance Tasks...

  • Page 18: Troubleshooting

    an undersized or restricted line will cause a drop in pressure. All valve, pump, and hose connections should be TROUBLESHOOTING Motor Does Not Operate Motor Functions but Lift Will Not Rise ance. Remove the check valve cover and clean ball and seat.
  • Page 19 cal properties, precautionary measures to take, and first aid measures as stated in the Safety Summary before performing any maintenance with the hydraulic system. Oil level too low. Oil level should be just under the vent cap port when the lift is down. Relieve all hydrau Oil Blows out Breather of Power Unit Motor Hums and Will Not Run Faulty wiring..…..
  • Page 20 be used as a “dipstick”. Lift makes excessive noise / vibrates 1. Cross beam ends are rubbing the columns. Readjustment needed. 2. Cylinder too tight, load lift half capacity and cycle up and down a few times to break in. Cable Inspection Guide 3/8”...
  • Page 21 Daily Inspection & Maintenance vents, and road salts. If such agents are spilled or splashed on any lift component, immediately with Penetrating Oil and wipe down. Failure to keep lift free of corrosive agents and solvents will lead to reduced component service life, cable fail- ure, etc., which could result in property damage and/or personal injury.
  • Page 22 Failure to keep lift free of corrosive agents and solvents will lead to reduced component service life, cable fail- ure, etc., which could result in property damage and/or personal injury. its normal appearance, must be replaced. If any cable is found to be in need of replacement, the entire cable set must be replaced immediately.
  • Page 23 periodic inspection. replaced immediately. the cable adjustment available, all cables must be replaced immediately. If any cable is found to be in need of replacement, the entire cable set must be replaced immediately. years, unless earlier replacement is indicated during inspection. Sheaves and Pins Check sheaves and replace if cracks are found.
  • Page 24 Inspect the hydraulic cylinder mounting to the runway. Inspect cylinder and hydraulic hoses for leaks. Check and tighten the hydraulic cylinder rod nuts holding the cable pull bar. tracks.
  • Page 25 WARNING! Worn or damaged tracks must be repaired immediately. Failure to do so will lead to reduced service life which could result in property damage and/or personal injury. Latch Inspection and Adjustment Check locking latches for proper operation. Inspect for worn or missing parts. Replace worn or damaged parts Latches Check latch operation on all four corners.
  • Page 27 Lower lift and remove vehicle.
  • Page 28 as the first locking latch clicks into place. Synchronize the other three columns with this col-...
  • Page 31 When making changes to adjustment nuts on cable end or latch bar stud, always leave at least two threads...
  • Page 32 showing between nut and stud end.
  • Page 33 Part Number P3543...
  • Page 34 Part Number PP7-9802-2...
  • Page 35 COVER 30400-1999 Wheel Chock Angle Iron Rubber Accessories Included in Four Post 9,000 lb Lift...
  • Page 36 You may contact us by one of the following: By Standard Mail Direct Lift 996 Industrial Drive MADISON IN, 47250 UNITED STATES Email: sales@directlift.com Phone: 866-347-5438 Fax: 812-273-7315...
