Summary of Contents for Kärcher 210 Plus
- Page 1 5.959–496 Ä12664 05/00...
- Page 2 Safety instruction for high-pressure cleaners Before start-up please read these instructions ! Before using the machine please read the is away from the water spray area where the operating instructions for your unit and comply in appliance is in use. particular with these safety instructions.
- Page 3 Safety instruction for high-pressure cleaners Before start-up please read these instructions ! Application Operation Before use, check that the unit and operating The operator must use the unit in accordance equipment are in perfect condition and are safe with the regulations. He/she must take local to operate.
- Page 4 Kärcher 210 plus 1 Appliance switch (ON/OFF) 5 Detergent suction hose 8 High-pressure hose 2 High-pressure outlet 6 Spray lance with 9 Spray gun with safety ratchet(A) 3 Water connection with filter high-pressure nozzle 10 Connection lead 4 Coupling 7 Spray gun with Dirt Blaster...
- Page 5 Starting • Do not simply discard the packing materials with the house-hold waste. Take the packing materials to the appropriate collection areas for recycling. • Impurities in the intake water damage the pump. To prevent this we expressly urge you to use the Kärcher water filter (order no.
- Page 6 Operation with high pressure • The appliance is equipped with a pressure-operated switch. The motor starts only if the lever of the gun is pulled. • The safety ratchet does not lock the trigger of the gun during operation but only prevents it from opening unintentionally.
-
Page 7: Operation With Detergent
Operation with Detergent • We recommend that you use detergent sparingly for the sake of the environment. Observe the recommended dosage on the detergent label. • By offering you an individuali- sed range of cleaning and preserving agents, Kärcher guarantees trouble-free operation of the unit. - Page 8 Switching OFF / Care and maintenance • Pull the trigger until there is no more pressure in the ap- pliance, and secure the trigger with the safety ratchet against unintentional opening. • The appliance should be rinsed clean after detergent has been used.
- Page 9 No Detergent Suction General Information - Set the double nozzle to low pressure. - Clean the detergent suction hose with filter, Safety Equipment and check for leaks. When the spary gun is closed, the overflow valve switches off the appliance via a pressure- operated switch.
-
Page 10: Eu Declaration Of Conformity
EU Declaration of Conformity We hereby declare that the equipment described below conforms to the relevant fundamental safety and health requirements of the appropriate EU Directives, both in its basic design and construction as well as in the version marketed by us. This declaration will cease to be valid if any modifications are made to the machine without our express approval. -
Page 11: Spare Parts
Spare Parts 210 A 210 PLUS 232 PLUS 6.388-216.0 6.647-616.0 6.647-789.0 6.414-277.0 6.414-252.0 6.389-870.0 2.880-296.0 6.390-464.0 5.037-137.0 4.775-389.0 6.363-031.0 6.362-498.0 5.332-464.0 2.883-111.0 4.760-357.0 2.883-111.0 4.763-977.0 08.02.2000...
