User Manual Ethernet from/to DeviceNet Master
Document code: MN67154_ENG
Revision 1.000
Page 10 of 14
Industrial Electronic Devices
CHARACTERISTICS OF THE CABLES:
E
:
THERNET
The connection at Ethernet socket must be with a Ethernet Cable with a RJ45 plug.
232:
RS
The connection from RS232 socket to a serial port (example one from a personal computer) must be made with a NULL MODEM cable (a serial
cable where the pins 2 and 3 are crossed).
It is recommended that the RS232C Cable not exceed 15 meters.
Figure 8: Null modem cabling
ADFweb.com Srl – IT31010 – Mareno – Treviso
INFO:
www.adfweb.com
Phone +39.0438.30.91.31
