parts List and Diagram

pLEASE READ THE FOLLOWING cAREFULLy
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM
IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR
MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE
ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
parts List
part Description
1 M5 Nut
2 Left Head Housing
3 Die Holder
4 Ø52 Retaining Ring
5 M5X22 Screw
6 Right Head Housing
7 Ø5 Washer
8 Ø5 Washer
9 ST4.9x35 Screw
10 Cap
11 Ø12 Retaining Ring
12 Bearing (Ø17xØ12x12)
13 Plane Bearing 51101
14 Worm Gear
15 Key (5x6)
16 Gear
17 Ø12 Retaining Ring
18 629 Bearing
19 Armature
20 608 Bearing
21 608 Bearing Sheath
22 Cover
23 ST3.9x75 Screw
24 Stator
25 Housing
Record product's Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
Page 14
Qty
6
1
1
1
6
1
4
4
2
1
2
2
2
1
1
1
1
1
1
1
1
1
2
1
1
For technical questions, please call 1-888-866-5797.
part Description
26 Nameplate
27 Carbon Brush Holder
28 Carbon Brush
29 Carbon Brush Cover
30 Right Handle
31 ST3.9x16 Screw
32 ST3.9x45 Screw
33 Direction Switch
34 Trigger
35 Left Handle
36 Cord Clamp
37 Cord Protector
38 Power Cord
39 Roll Pin
40 Clamp
41 Clamp Bar
42 1/2" Die
42a 1/2" Die Blade Set
43 3/4" Die
43a 3/4" Die Blade Set
44 1" Die
44a 1" Die Blade Set
45 1-1/4" Die
45a 1-1/4" Die Blade Set
Qty
1
2
2
2
1
3
4
1
1
1
1
1
1
1
1
1
1
-
1
-
1
-
1
-
Item 62203
