  • Page 1 Secure Router Manual XG-1541 Netgate Oct 03, 2019...

  • Page 2: Table Of Contents

    CONTENTS 1 Getting Started 2 I/O Ports 3 Connecting to the Console Port 4 Additional Resources 5 Warranty and Support 6 Safety and Legal...
  • Page 3 Secure Router Manual, XG-1541 This Quick Start Guide covers the first time connection procedures for the Netgate XG-1541 1U Secure Router also provides information needed to stay up and running. CONTENTS...

  • Page 4: Getting Started

    CHAPTER GETTING STARTED Use the following steps to configure the TNSR Secure Router. 1. To configure the Network Interfaces and gaining access to the Internet, follow the instructions provided in the Zero-to-Ping documentation. Note: Not all steps in the Zero-to-Ping documentation will be necessary for every configuration scenario. 2.

  • Page 5: O Ports

    CHAPTER I/O PORTS Contents • I/O Ports – Default Configuration Network Ports Other I/O Status LEDs – With CPIC-8955 Accelerator Card with Intel® QuickAssist Technology – With 2 Port Intel 1 Gbps Ethernet Expansion Card – With 4 Port Intel 1 Gbps Ethernet Expansion Card –...
  • Page 6 Secure Router Manual, XG-1541 2.1.1 Network Ports Port CentOS Label TNSR Label Port Type Port Speed eno1 GigabitEthernet6/0/0 RJ-45 1 Gbps eno2 GigabitEthernet6/0/1 RJ-45 1 Gbps eno3 TenGigabitEthernet3/0/0 RJ-45 10 Gbps eno4 TenGigabitEthernet3/0/1 RJ-45 10 Gbps Note: Default Host OS Interface is eno1. The Host OS Interface is one network interface that is only available to the host OS and not available in TNSR.
  • Page 7 Secure Router Manual, XG-1541 State Description Continuously on and red An overheat condition has occurred. (This may be caused by cable congestion.) Blinking red (1Hz) Fan failure, check for an inoperative fan. Blinking red (0.25Hz) Power failure, check for a non-operational power supply.
  • Page 8 Secure Router Manual, XG-1541 2.2 With CPIC-8955 Accelerator Card with Intel® QuickAssist Tech- nology Port CentOS Label TNSR Label Port Type Port Speed eno1 GigabitEthernet6/0/0 RJ-45 1 Gbps eno2 GigabitEthernet6/0/1 RJ-45 1 Gbps eno3 TenGigabitEthernet3/0/0 RJ-45 10 Gbps eno4 TenGigabitEthernet3/0/1...
  • Page 9 Secure Router Manual, XG-1541 and updating the host OS. 2.4 With 4 Port Intel 1 Gbps Ethernet Expansion Card Port CentOS Label TNSR Label Port Type Port Speed ens2f0 GigabitEthernet4/0/0 RJ-45 1 Gbps ens2f1 GigabitEthernet4/0/1 RJ-45 1 Gbps ens2f2 GigabitEthernet4/0/2...

  • Page 10: Connecting To The Console Port

    CONNECTING TO THE CONSOLE PORT Connecting to the VGA console is identical to connecting any computer to a monitor. Just connect the VGA cable (DB-15) between the Netgate appliance and the monitor. Use USB or PS/2 keyboard and mouse as applicable to your hardware.

  • Page 11: Additional Resources

    Netgate training has got you covered. https://www.netgate.com/training/ 4.3 Resource Library To learn more about how to use your Netgate appliance and for other helpful resources, make sure to browse our Resource Library. https://www.netgate.com/resources/...

  • Page 12: Warranty And Support

    CHAPTER FIVE WARRANTY AND SUPPORT • One year manufacturer’s warranty. • Please contact Netgate for warranty information or view our Product Lifecycle page. • All Specifications subject to change without notice. Enterprise Support is included with an active software subscription, for more information view our...

  • Page 13: Safety And Legal

    CHAPTER SAFETY AND LEGAL Contents • Safety and Legal – Safety Notices – Electrical Safety Information – FCC Compliance – Industry Canada – Australia and New Zealand – CE Marking – RoHS/WEEE Compliance Statement – Declaration of Conformity – Disputes –...

  • Page 14: Electrical Safety Information

    Secure Router Manual, XG-1541 6.2 Electrical Safety Information 1. Compliance is required with respect to voltage, frequency, and current requirements indicated on the manu- facturer’s label. Connection to a different power source than those specified may result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed.

  • Page 15: Ce Marking

    Secure Router Manual, XG-1541 6.6 CE Marking CE marking on this product represents the product is in compliance with all directives that are applicable to it. 6.7 RoHS/WEEE Compliance Statement 6.7.1 English European Directive 2002/96/EC requires that the equipment bearing this symbol on the product and/or its packaging must not be disposed of with unsorted municipal waste.

  • Page 16: Declaration Of Conformity

    6.8 Declaration of Conformity 6.8.1 ˇ Cesky[Czech] NETGATE tímto prohla uje, e tento NETGATE device, je ve shod se základními po adavky a dal ími p íslu n mi ustanoveními sm rnice 1999/5/ES. 6.8.2 Dansk [Danish] Undertegnede NETGATE erklærer herved, at følgende udstyr NETGATE device, overholder de væsentlige krav og...
  • Page 17 Alulírott, NETGATE nyilatkozom, hogy a NETGATE device, megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak. 6.8.10 Íslenska [Icelandic] Hér me l sir NETGATE yfir ví a NETGATE device, er í samræmi vi grunnkröfur og a rar kröfur, sem ger ar eru í tilskipun 1999/5/EC. 6.8.11 Italiano [Italian] Con la presente NETGATE dichiara che questo NETGATE device, è...

  • Page 18: Disputes

    Secure Router Manual, XG-1541 6.8.16 Slovensky [Slovak] NETGATE t mto vyhlasuje, e NETGATE device, sp a základné po iadavky a v etky príslu né ustanovenia Smernice 1999/5/ES. 6.8.17 Svenska [Swedish] Härmed intygar NETGATE att denna NETGATE device, står I överensstämmelse med de väsentliga egenskapskrav och övriga relevanta bestämmelser som framgår av direktiv 1999/5/EG.

  • Page 19: Applicable Law

    Secure Router Manual, XG-1541 4616 West Howard Lane, Suite 900 Austin, Texas 78728 legal@netgate.com The arbitration will be conducted by the American Arbitration Association (AAA) under its rules. The AAA’s rules are available at www.adr.org. Payment of all filing, administration and arbitrator fees will be governed by the AAA’s rules.
  • Page 20 Secure Router Manual, XG-1541 THE PRODUCTS/SERVICES AND ALL INFORMATION, CONTENT, MATERIALS, PRODUCTS (INCLUD- ING SOFTWARE) AND OTHER SERVICES INCLUDED ON OR OTHERWISE MADE AVAILABLE TO YOU THROUGH THE PRODUCTS/SERVICES ARE PROVIDED BY US ON AN “AS IS” AND “AS AVAILABLE” BA- SIS, UNLESS OTHERWISE SPECIFIED IN WRITING.
