- Page 1 SVEX-T500A Explosion Proof User Manual...
- Page 2 SVEX-T500A Explosion Proof Camera User Manual. Safety Notes Please carefully read this Instruction Manual before installation and use. 1. Installation Please carefully read this Instruction Manual and follow the warnings before installation and use. Be sure to cut off the power supply before maintenance and repair of the equipment.
-
Page 3: Table Of Contents
SVEX-T500A Explosion Proof Camera User Manual. Content 1. Overview ................4 2. Technical Index ..............5 2.1 Model Description ............ 5 2.2 Certification .............. 5 2.3 Model ............... 5 2.4 Electrical Index ............5 2.5 Mechanical Index ............. 6 2.6 Ambient Condition ............ 6 2.7 Product Dimension ........... -
Page 4: Overview
SVEX-T500A Explosion Proof Camera User Manual. 1- Overview Designed and manufactured strictly according to the standards such as GB3836.1-2010 Explosive atmospheres - Part 1: Equipment - General requirements, GB3836.2-2010 Explosive atmospheres - Part 2: Equipment protection by flameproof enclosure “d”, GB12476.1-2000 Electrical apparatus for use in the presence of combustible dust - Part 1-1:... -
Page 5: Technical Index
SVEX-T500A Explosion Proof Camera User Manual. 2- Technical Index 2.1 Model Description T500 Blank: with wiper / -1: without wiper B 为短形护 /A: with wiper / -1/A: without wiper Design serial number Product code Company code 2.2 Certification II 2 GD Ex d II C T6 Gb Explosion-proof mark Ext III C T80°C Db... -
Page 6: Mechanical Index
SVEX-T500A Explosion Proof Camera User Manual. 2.5 Mechanical Index SVEX-T500A Material Stainless steel 304 or 316L Level of protection IP66 Outside dimension 657(L) x 198(H) x 212(W) mm Inside dimension Sight window 15mm thick Φ80mm Area of sight window Weight / Shipping weight... -
Page 7: Product Dimension
SVEX-T500A Explosion Proof Camera User Manual. 2.7 Product Dimension Figure 1. Outside Dimension of SVEX-T500A Explosion-proof All-weather Camera Housing Figure3. Outside Dimension of SVEX-T500A Explosion-proof All-weather Camera Housing 2.8 Installation Dimension Figure 3. Fixing Holes at the Bottom of Housing... -
Page 8: Installation
SVEX-T500A Explosion Proof Camera User Manual. 3- Installation 3.1 Installation of Camera and Lens Carefully read the instruction manual before installation to learn whether the CCD specifications and interface forms of the lens and camera are consistent; the 1/3 or 1/2 inch lens can be installed in the 1/3 inch CCD camera, and only the 1/2 inch lens can be installed in the 1/2 inch CCD camera, otherwise, vignette may be generated on the picture edge. -
Page 9: Cable Treatment
SVEX-T500A Explosion Proof Camera User Manual. 3.2 Cable Treatment 3.2.1 Cable Treatment at Delivery A.B-type cable gland packing filled inside Hold-down nut Outgoing cable Bakelite HPS89-01 Explosive-proof Flat Rubber Gasket Rubber Nut seat gasket epoxy seal joint gasket gasket seal ring resion Figure 3.3.1 Structure of Standard Packing Box at Delivery... -
Page 10: Installation Of Housing Barrel
SVEX-T500A Explosion Proof Camera User Manual. 3.3 Installation of Housing Barrel The flameproof surface of the housing fits quite closely since the explosion-proof grade is high. During installation, especially pay attention to protecting the flameproof surface; as shown in the figure, the rear cover and the rear side of the barrel are flameproof surfaces, which shall not be impacted or scratched during installation. -
Page 11: Installation Of Housing Onto Electric Pan-Tilt
SVEX-T500A Explosion Proof Camera User Manual. Insulating layer Figure 12. Pay Attention to Insulating Layer between Rear Cover and Drawer Plate Note: 1. S/N 1 consists of 2 line groups. One group is for heating (red, 0.5mm ); the other group is the common motor terminal (white, yellow);... -
Page 12: Installation Precautions
SVEX-T500A Explosion Proof Camera User Manual. 3.6 Installation Precautions Check the following items before installing the product, and the product cannot be used if it is non-conforming. Whether there is explosion-proof certificate number; Whether the explosion-proof mark applies to the environment of explosive gas mixture;... -
Page 13: Description Of Explosion-Proof Structure
SVEX-T500A Explosion Proof Camera User Manual. Description of Explosion-proof Structure Various special circumstances are adequately considered during structural design, so that no explosion will occur in the environment full of explosive mixture outside the equipment if sparks are generated in the equipment; moreover, the explosion-proof performance of the equipment is guaranteed from the following aspects: enclosure strength, gap between components, and highest surface temperature limitation of enclosure. -
Page 14: Transportation And Storage
SVEX-T500A Explosion Proof Camera User Manual. 6- Transportation and Storage The packaged product can be transported by various methods in the condition that it is protected from direct exposure to rain and snow; it can be stored for more than one year in the environment with the temperature of 0º... -
Page 15: Quality Assurance
„ Veilux owns the final design changing and final specification rights and no responsibility to inform user. „ This manual book belongs to Veilux rights, without permits or any book inform, any company private copy of whole or part of the book shall be prohibited. -
Page 16: Appendix Ii: Use Of Desiccant
SVEX-T500A Explosion Proof Camera User Manual. Take the computar H2Z4516CS-2 lens which has three adjustable rings as an example: “OPEN” and “CLOSE” are marked on the aperture ring, and the aperture ring can be directly rotated to adjust the aperture; “OPEN” means increasing the aperture, and “CLOSE” means decreasing the aperture. -
Page 17: Appendix Iii: Content Reference Table Of Toxic And Hazardous Substances Or Elements
SVEX-T500A Explosion Proof Camera User Manual. Appendix III: Content Reference Table of Toxic and Hazardous Substances or Elements Toxic and Hazardous Substances or Elements Polybrominated Part Name Hexavalent Polybrominated Lead Mercury Cadmium Diphenyl Chromium Biphenyls (Pb) (Hg) (Cd) Ethers (PPB)
