Summary of Contents for Qeedji SMT210
- Page 1 User Manual SMT210 4.11.11 001A...
- Page 2 Please read carefully the following instructions before switching the product on: - WARNING! Correct fitting and installation is of the utmost importance. Incorrect fitting and/or installation may result in personal injury or loss. Qeedji disclaims all liability, of whatever kind, if the product is assembled, fitted and/or installed in an incorrect manner.
-
Page 3: Table Of Contents
Table of Contents Introduction Getting Started LEDs Connectors WebUI configuration Built-in RFID reader Technical specifications Troubleshooting Conformities Contacts 1.10... -
Page 4: Introduction
This device is intended to work with the supplied power supply unit. This power supply unit must be connected to a mains socket conforming to standard NF C 15-100. If the AC power cable is damaged, it must be replaced. It is possible to order a replacement mains unit by sending a request to the email address sales@qeedji.tech. -
Page 5: Getting Started
Getting started with the device Front face and side face RFID tag sensor Left side LED Right side LED Built-in speaker Touch screen Bottom face SD CARD DC IN USB2 USB1 CLIENT Power supply connector Power supply red LED Status green LED Jack 3,5 mm GPIO connector RJ45 LAN PoE connector Phoenix GPIO connector... - Page 6 Device fixture 258 mm 200 mm 6 mm ≤ Ø ≤ 8 mm Ø ≤ 4 mm Device dimensions 258 mm 35 mm...
- Page 7 ☛ The serial number of the device can be requested in case of technical support. www.qeedji.tech 5A rue P ierre Joseph C olin 35000 R E NNE S FR ANC E Model: SMT210 Input: 12V DC 830mA MAC : 00:1C :E6:02:01:A9 PSN00434-01043 C D9 www.qeedji.tech...
- Page 8 Device start-up step > Step 1 (T0=0s) Step 2 (T~21s) Step 3 (T~1min) Device start-up initialisation Device start-up finalisation Nominal mode This phase duration is depending on some variable values During this step, the device has to play the content. (like NTP), some network access duration or some data When firmware upgrade process occured, in checking (check-disk)
-
Page 9: Connectors
Then the fuse can be manually re-armed. During board (re)starting, the defaut level for GPIO4 is 3.3V The GPIO4 has: one 4.7 KOhms pull-up to 3.3V and one 182 KOhms pull-down to 0V Principle schematics of several use case Three wires input configuration for GPIO4: PERIPHERAL SMT210 3.3V 1 (Jack) 3 (Jack) Input CPU/GPIO4 Switch... - Page 10 Power supply SMT210 PERIPHERAL 3 (Jack) CPU/GPIO4 Output 2 (Jack) Logic gate, transistor or opto-coupler Jack 3,5 mm GPIO4 configuration The GPIO configuration des GPIOs can be realized by editing some user preferences in the device configuration Web interface or thanks to a configuration script.
- Page 11 Application when using a strike In case the device SMT210 has to drive a strike for an electric door, it is highly recommended to check, before any use, that a additionnal freewhell diode is really installed with the strike. Please read the strike user manual. If no frewheel diode is mounted on the electrical system of the strike when using for the first time, the user acts to deliberatly degrade the SMT210 device which is not warrantied in this case.
- Page 12 Freewheel diode Strike It is recommended to plug the freewheel diode very close to the strike. Phoenix connector GPIOs configuration The GPIOs configuration can be done by editing the user preferences in the device configuration Web interface or with a configuration script. The part related to the GPIO configuration is explained below: // Set Phoenix direction : input or output (aDirection == "out")
- Page 13 : allows to load the certificates required to play some specific HTML page or to connect to WebDAV servers with the https scheme Certificates It is highly recommended that your device SMT210 is on time. When it is possible, synchronize the time & date with a NTP server. ⚠...
- Page 14 It is recommended to enter a unic for each device used on your locak network. When using several devices SMT210 spread on several buildings or on ⚠ Hostname several locations, it is recommended to enter values having a specific key word reminding the building and the location of the device (for exmaple:...
-
Page 15: Built-In Rfid Reader
Built-in RFID reader The device smt210 has a RFID tag reader allowing to recognize the badges supporting the NFC wireless technology. The table below shows the kinds of wireless technologies of the tags most frequently used on the badges, with their manufacturers. It shows also, for each wireless... -
Page 16: Technical Specifications
Technical specifications Model Manufacturer SMT210 Qeedji Processor DM3730 1 GHz Peripherals 2x USB 2.0 Host (Low/Full/High Speed) 1x USB client 1x GPIO for the internal relay driving 3x GPIO bidirectional 2x side LEDs Storage Internal flash memory: 2 GB SD card: 2 GB Softwares BSP 3.50.X / eLinux 2.6... - Page 17 1,0 Kg 258 x 176 x 35 mm...
-
Page 18: Troubleshooting
Error while playing a media: message "This content <media path/file name> is not compatible with this device" Troubleshooting To solve the issue, remove this not supported media from your playout and publish again. ¹ ¹ For further information, read the document gekkota-supported-medias-and-performances.pdf ² For further information, contact support@qeedji.tech... -
Page 19: Conformities
Conformities In conformity with the following European directives: LVD 2014/35/EU EMC 2014/30/EU... -
Page 20: Contacts
For further information, please contact us at + 33 (0)2 23 20 01 62 or by e-mail: Technical support: support@qeedji.tech Sales department: sales@qeedji.tech FAQ and download at : https://www.qeedji.tech Qeedji INNES SA 5A rue pierre Joseph Colin 35700 RENNES Tel: +33 (0)2 23 20 01 62 Fax: +33 (0)2 23 20 22 59 https://www.qeedji.tech Qeedji INNES SA Verbindungsbüro Deutschland...
