Lemco Mod7 Manual

"full band" rf pal modulator

Advertisement

Quick Links

Technical Specifications
:
1 x 1 Vpp / 75Ω
Input video signal
:
1 x RCA' female'
Input connectors
:
1 x Mono 0,25...0,5 V
Input audio signal
:
1 x L/R RCA 'female'
Input connectors
:
VHF: E5...E12
Working RF channels
S3...10 & S11...S20 & S21...S41
UHF: C21...C69
:
85dBμV (MOD7)
RF output level
100dBμV (MOD8)
:
Yes (MOD7)
Loop-through circuit:
:
No (MOD8)
:
0...20 dB
Output channel
:
PAL B/G (ask for other norms)
Norm:
:
75Ω
Output Impedance
:
230VAC / 4.2VA
Power Supply
:
0...+45
Operation Temperature
Lemco may change any technical specification of this product without prior notice
**
/ 47 ΚΩ
RMS
o
C
Lemco - www.lemco.gr
MOD7/8
"Full Band" RF PAL Modulator
Description
The MOD7/8 is a "full-band" RF PAL mono modulator operating all channel
frequencies from VHF and UHF band. It accepts one CVBS and one L/R
audio signal and modulates them to the preferred RF output frequency.
The MOD7/8's user interface comprises two tact switches (for the channel
selection) as well as one SSD (Seven Segment Display) to display the current
working frequency. An internal PLL ensures the stability of the output
channel frequency.
The MOD7 modulator offers a loop-through circuit (for multiple modulator
interconnect) as well as an output RF level of 85dBμV.
The MOD8 does not support loop-through circuit but offers a high output
level of 100dBμV for situations where high RF level is mandatory.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mod7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lemco Mod7

  • Page 1 Working RF channels Description S3...10 & S11...S20 & S21...S41 UHF: C21...C69 The MOD7/8 is a “full-band” RF PAL mono modulator operating all channel frequencies from VHF and UHF band. It accepts one CVBS and one L/R 85dBμV (MOD7) RF output level audio signal and modulates them to the preferred RF output frequency.
  • Page 2 Programming guidelines MOD7 Top cover The following steps are required for the programming of the MOD7/8: Step No 1: With the use of the UP/DOWN buttons the user is able to select the desired RF output channel. The number of the current selected RF output channel is displayed on the SSD (Νο.2) while the “C”...
