K-array Azimut Series Reference Manual page 16

Azimut
Reference Guide
Type Point source
Rated Power 60 W
Frequency Response 45 Hz – 150 Hz (-6 dB)
Maximum SPL 112 dB (peak)
Coverage Omni
4" woofer + passive
Transducers
radiator
Colors
Finishes
Material
Dimensions 120 x 116 x 190 mm
(WxHxD) (4.7 x 4.6 x 7.48 in)
Weight 1,5 kg (3.31 lb)
IP Rating
Impedance 4 Ω
Maximum SPL is calculated using crest factor 4 (12dB) from sensitivity scaled @1m and power handling specifications, exclusive of power compression.
1
Type 4-channel Class D audio amplifier
Rated Power 4x 50W @ 4Ω
Frequency Response 20 Hz – 20 kHz (±1 dB)
Bluetooth 4.1 Low Energy,
Connectivity
Wi-Fi, Ethernet
Control Dedicated Azimut Control Interface / wired Remote Control
Operating range Dedicated AC/DC power adapter 100-240V ~ AC, 50-60 Hz input / 24 V, 4 A DC output
Colors and Finishes Black / Powder Matte
Material Aluminium
Dimensions (WxHxD) 144 x 46 x 144 mm (5.6 x 1.8 x 5.6 in)
Weight 0,5 kg (11 lb)
Impedance minimum 4 Ω
Truffle-KTR24 Truffle-KTR25
Point source
80 W
45 Hz – 150 Hz (-6 dB)
115 dB (peak)
1
Omni
5.25" woofer + passive
radiator
151,5 x 145 x 250 mm
(5.96 x 5.71 x 9.84 in)
2,5 kg (5.51 lb)
4 Ω
Truffle-KTR26
Point source
100 W
45 Hz – 150 Hz (-6 dB)
120 dB (peak)
1
Omni
6.5" woofer + passive
radiator
Black
Powder Matte
Aluminium
181,5 x 176 x 322 mm
(7.15 x 6.93 x 12.68 in)
3,5 kg (7.72 lb)
IP54
2 Ω
Kommander-KA02
2x Phoenix Connectors (bal)
3.5 mm Jack Stereo (unbal)
Toslink Optical Connector
16
Rumble-KU44-2
Point source
120 W
50 Hz – 150 Hz (-6 dB)
116 dB (peak)
1 1
Omni
2 x 4" neodymium magnet
2 x 4" passive transducer
Black, white, Custom RAL
Gold, Polished, Brushed
Stainless Steel
116 x 500 x 101 mm
(4.6 x 19.7 x 4.0 in)
5,9 kg (13.0 lb)
2 Ω
