Quick Start Guide
AT-6010 Advanced Wire Tracer
Reliable, precise breaker
identification
Tested by Fluke and safety
certified by 3rd party labs
ENG FRE SPA
TestEquipmentDepot.com
Intuitive Transmitter
automatically senses whether
the system is energized or
de-energized
Most accurate wire tracing
in its class with eight
sensitivity modes
