Krowne Royal Series Instruction Manual
Electronic faucet
Hide thumbs
Also See for Royal Series:
- Instruction manual (16 pages) ,
- Installation manual (8 pages) ,
- Installation manual (4 pages)
Subscribe to Our Youtube Channel
Related Manuals for Krowne Royal Series
Summary of Contents for Krowne Royal Series
- Page 1 ELECTRONIC FAUCET INSTRUCTION MANUAL Krowne Metal Corporation • 100 Haul Road • Wayne, NJ 07470 Toll Free: (800) 631-0442 • customerservice@krowne.com • krowne.com...
- Page 2 Electronic Faucet Parts COLD Part Model Spout Supply Hose 16-512 Control Module 16-198 Mechanical Mixing Valve 16-402L Hot & Cold Supply Hoses 16-510 AC Adapter (optional) 16-199 Thermostatic Mixing Valve (optional) 16-405L Replacement Filter 16-187...
- Page 3 Model 16-190 Model 16-191 Single Hole Wall Mount w/ 4-1/2” Swivel Single Hole Wall Mount w/ 6” Swivel Gooseneck Gooseneck No. Part Model No. Part Model 0.5 GPM Aerator 22-600L 0.5 GPM Aerator 22-600L Convex Sensor with Cable 16-506 Convex Sensor with Cable 16-506 Model 16-192 Model 16-649 Single Hole Wall Mount w/ 6”...
- Page 4 Model 16-650 Model 16-654 Single Hole Deck Mount w/ 6” Rigid Single Hole Deck Mount w/ Straight Spout Gooseneck No. Part Model No. Part Model 0.5 GPM Aerator 22-620L 0.5 GPM Aerator 22-600L Convex Sensor with Cable 16-506 Convex Sensor with Cable 16-506 4”...
-
Page 5: Tools Required
IMPORTANT • DO NOT USE PIPE DOPE AS A SEALANT. All water lines provided with faucet are compression fittings and do not require sealant. Pipe dope will damage the valve and filters and will void the warranty. • DO NOT OVERTIGHTEN. •... -
Page 6: Installation
INSTALLATION STEP 1 • INSTALL FAUCET ASSEMBLY MOUNT ON SURFACE UP TO 1” THICK • Feed sensor cable and spout shank through base gasket and mounting hole • Secure using lockwasher and nut as shown in below. Model 16-190 Model 16-191 Brass Washer Elbow... - Page 7 INSTALLATION (con’t) Model 16-650 Model 16-654 Base Gasket Mounting Surface Base Gasket Washer Mounting Surface Lock Washer Model 16-196 Model 16-197 Base Gasket Base Gasket Mounting Surface Mounting Surface Lock Washer Lock Washer...
- Page 8 INSTALLATION (con’t) Note: Refer to below diagram for step by step installation. STEP 2 • INSTALL MECHANICAL MIXING VALVE Install Mechanical Mixing Valve into inlet location #1 on the Control Module, which has a compression fitting. Do not use thread sealant and do not overtighten. The Control Module is to be mounted to a wall and the Mechanical Mixing Valve must be straight as per photo below.
-
Page 9: Troubleshooting
INSTALLATION (con’t) STEP 4 • INSTALL MECHANICAL MIXING VALVE • If you are using batteries as your source of power, remove the 3 phillips screws on the battery cover located on the front of the control unit. Install the (4) AA Alkaline batteries that are included. -
Page 10: Things To Know
TROUBLESHOOTING (con’t) If the faucet will not turn OFF... • The solenoid valve inside the control unit may not be functioning properly. Turn off the hot and cold water supply and activate the faucet. If you do not hear a click inside the control module, you will need to replace the control module, which contains the solenoid valve. -
Page 11: Terms And Conditions
25% of the purchase price plus transportation charges. 12. SHORTAGE. Krowne must be notified in writing within 5 days of receipt of shipment. 13. TAXES. Buyer will pay when due any and all taxes, tariffs, fees and assessments or any other similar charges imposed upon this contract, the goods covered hereby or the delivery, installation, use or resale thereof. - Page 12 Other Great Products from Krowne Metal Corporation • 100 Haul Road • Wayne, NJ 07470 Toll Free: (800) 631-0442 • customerservice@krowne.com • krowne.com...
