CAR MULTIMEDIA SYSTEM (Model: MTXW100OS)
USER'S MANUAL
KONA
Please read this manual carefully before operating your set and retain it for future reference. Designs and specifica-
tions are subject to change without prior notice.
The screens shown in this manual may differ from the actual screens of the product.
The design and specification of this product may change without prior notification for product improvement.
When transferring the vehicle to another individual, include this user's manual so that the next driver can continue its use.
ENGLISH
TIẾNG VIỆT
Rev.2.0
Advertisement
Table of Contents
Related Manuals for Hyundai MTXW1000S
Summary of Contents for Hyundai MTXW1000S
- Page 1 ENGLISH TIẾNG VIỆT CAR MULTIMEDIA SYSTEM (Model: MTXW100OS) USER’S MANUAL KONA Please read this manual carefully before operating your set and retain it for future reference. Designs and specifica- tions are subject to change without prior notice. The screens shown in this manual may differ from the actual screens of the product. The design and specification of this product may change without prior notification for product improvement.
- Page 2 iPod® Cortex iPod® is a registered trademark of Apple Inc. Cortex is the name of the ARM Processor Architecture used in the AV System. Bluetooth® Windows Embedded Compact 7 The Bluetooth Wireless Technology word mark and logos are registered Windows Embedded Compact 7 is an operating system used in the AV trademarks owned by Bluetooth Wireless Technology SIG, Inc.
-
Page 3: Table Of Contents
Table of Contents Precautions for safety Selecting Presets Sound settings .............. Safety notes Selecting Lists ..............USB Video Auto Preset ........Key Product Features Saving Radio Frequency Playing USB Video ............Key Product Features Saving Manually Searching USB Video Files ...... - Page 4 Table of Contents Playing iPod® Music Before Using the Bluetooth® Handsfree Contacts ................Searching iPod® Music Files What is Bluetooth® Wireless Technology? Updating Mobile Phone Contacts ........Using the Menu Buttons Precautions for Safe Driving Making a call from contacts ......
- Page 5 Table of Contents Open an app Changing device name FCC Warning .................... Return to the CarPlay Home screen Auto Connection Priority ........Return to your car’s screen System .............. View additional apps Language ......
-
Page 6: Precautions For Safety
Precautions for safety Safety notes Always operate the vehicle in a safe manner. Do When driving your vehicle, be sure to keep the CAUTION not become distracted by the vehicle while driv- volume of the unit low enough to allow you to ing and always be fully aware of all driving condi- hear sounds coming from the outside. - Page 7 Precautions for safety • • Do not touch the antenna during thunder or WARNING: CAUTION: lightening as such acts may lead to lightning • Do not stare at the screen while driving. Staring Do not keep the navigation system running •...
-
Page 8: Key Product Features
Key Product Features Key Product Features Button Description Wide IPS Display Display Provides high quality video through a Wide IPS Display using an LED Back Light. Digital Tuner Feature Radio Digital Tuner using PPL method that supports memory of 20 broadcast stations for each AM and FM modes. Multimedia Support for various Media Formats Player... -
Page 9: Component Names And Functions
Component Names and Functions Head Unit Button Description • • Power on When power is off, press to turn power on. • • Power off POWER / When power is on, press and hold to turn power off. VOL Knob •... - Page 10 Component Names and Functions Head Unit Name Description Press to display the map screen of the current location when in a different mode. Press to move to the navigation menu screen. Press to move to the home menu screen. HOME Displays the Setup mode.
-
Page 11: Steering Wheel
Component Names and Functions Steering Wheel Button Description • Operates FM ▶ AM ▶ Available Media (USB Music/USB • Video/iPod®/Bluetooth® Audio/AUX/Apple CarPlay). • If the media is not connected, corresponding modes will • MODE be disabled. • Press and hold the key to turn the Audio system on/off. •... -
Page 12: Using The System For The First Time
Using the System for the First Time Turning the System On/Off Resetting the System Pressing the PWR key on the head unit will dis- play the safety warning page. This feature is used to reset the system in the Turning the System ON Press the Agree button to display the most occurrence of an unforeseen error or problem. -
Page 13: Fm/Am
FM/AM Basic Screen Button Description Mode tab Press the tab to change between FM and AM mode. Displays List, Preset, Scan, Preset scan and Sound settings MENU button menus. Back button Moves to the previous screen. Frequency bar Use the tap to move to the desired frequency. Frequency Displays the current frequency. -
Page 14: Listening To Fm/Am Radio
FM/AM Listening to FM/AM radio Manual tuning Selecting Lists < Turn the TUNE / ENTER knob or press the Press the button Press the Press the key to change the mode in MENU ▶ List RADIO > button to manually select the frequency. button. -
Page 15: Saving Radio Frequency
FM/AM Saving Radio Frequency Button Description Tune listens to frequency selected. Saving Manually overwrites frequency listening Save After selecting frequency ▶ Press the Preset to currently. button ▶ Press the button. + Add to Preset Delete deletes frequency. Starting from the current frequency, frequencies with superior reception are scanned for 3 sec- onds and the previous frequency is restored. -
Page 16: Usb
About USB • • Repeated connecting/disconnecting of USB • • The device may not support normal opera- devices within short periods of time may tion when using a USB memory type besides Connect the USB device after turning on the result in product malfunction. -
Page 17: Usb Music
USB Music Playing USB Music Searching USB Music Files Repeat TRACK While playing ▶ Press the ∧ Press the button. Once a USB is connected, USB Music mode will SEEK ∨ key or the button to play the previ- Each time the button is pressed, the option is operate automatically. -
Page 18: Album Cover View
USB Music Album Cover view List Sound settings < > Press the button ▶ Press the button Press the button ▶ Press the but- Press the button ▶ Press the MENU List MENU Options to search desired album. ton to display USB Music list screen. button ▶... -
Page 19: Usb Video
USB Video Playing USB Video Searching USB Video Files Repeat TRACK While playing ▶ Press the ∧ Press the button. Once a USB is connected, USB Video mode will SEEK ∨ key or button to play the previous/ Each time the button is pressed, the option is operate automatically. -
Page 20: List
USB Video List Display settings Sound settings Press the button ▶ Press the but- Press the button Press the button MENU List MENU MENU ton to display USB Video list screen. ▶ Press the button. ▶ Press the button. Display settings Sound settings For details, refer to the “Sound”... -
Page 21: Usb Photo
USB Photo Viewing USB Photo Switching to menu screen or full Searching USB Image Files screen < > Press the button or turn the Press the key ▶ Press the HOME Media TUNE / ENTER knob to view the previous/next button ▶... -
Page 22: Using The Menu Buttons
USB Photo Using the Menu Buttons Slideshow interval Display settings Press the button ▶ Press the Press the button ▶ Press the Press the button to set Slide show, Slide MENU MENU MENU button. button. time and Display settings menus. Slide time Display settings For details, refer to the “Display”... -
Page 23: Ipod® Music
iPod® Music About iPod® • • If iPod® touch or iPhone is used, iOS4.2 or a later version is recommended. iPod® is a registered trademark of Apple Inc. Some iPod®s with unsupported communica- • • tion protocols may not properly operate with the system. -
Page 24: Playing Ipod® Music
iPod® Music Playing iPod® Music Sound settings Searching iPod® Music Files You can play the previous or next file. Once a iPod® is connected, iPod® Music mode Press the button ▶ Press the MENU Options For details, refer to the page 17. will operate automatically. -
Page 25: Aux
Playing an AUX source Using the Menu Buttons If an external device connector is connected Press the button to set Sound. MENU with the AUX terminal, then AUX mode will auto- matically operate. Press the key ▶ Press the but- HOME Media ton ▶... -
Page 26: Bluetooth® Audio
Bluetooth® Audio Before playing the Playing Bluetooth® audio Using the Menu Buttons Bluetooth® audio Press the key ▶ Press the Press the button to set Sound settings HOME Media MENU button ▶ Press the button. menus. Bluetooth Audio • • Music saved in the mobile phone can be played in the car through Bluetooth®... -
Page 27: Getting Started With Navigation
Getting started with navigation Precautions for safe driving Acquiring satellite signals mission state, vehicle state (driving location and conditions), etc. Additionally, the car position Please observe and comply with local traffic Before the unit can determine your current posi- mark may differ from the actual position if the rules and regulations. -
Page 28: Bluetooth® Wireless Technology
Bluetooth® Wireless Technology Before Using the Bluetooth Precautions for Safe Driving Cautions upon Connecting Handsfree Bluetooth Phone Bluetooth® Handsfree is a feature that enables • • drivers to practice safe driving. Connecting the Before connecting the head unit with the •... -
Page 29: Bluetooth® Connection
▶ Press the but- PHONE ton. From the Bluetooth® device, search for the car name and pair the device. When searching from the Bluetooth® device, the car name is Hyundai Kona AVNC and the default passkey is ‘0000’ . -
Page 30: When A Phone Is Already Paired
Bluetooth® Connection NOTE When a Phone is Already Paired When your phone is • Once Bluetooth® connection is successful, the connected Press the key on the steering wheel or name of the connected mobile phone will be press the key ▶ Press the button displayed on the phone screen and Bluetooth®... -
Page 31: Bluetooth® Phone
Bluetooth® Phone Making/Answering Calls Calling through Redial Rejecting a Call Press and hold the button or Press the Incoming call notice ▶ Press the button Calling by Dialing a Number key on the steering wheel twice. or the key on the steering wheel. Enter number on the Dial Pad ▶... -
Page 32: Operating Menus During A Call
Bluetooth® Phone Operating Menus during a Ending a Call Making 3 way call Call While on a call ▶ Press the button or While on a call ▶ Press the button. ▶ key on the steering wheel. Press phone number you want to make a call ▶ Press the button. -
Page 33: Using The Menu Buttons
Bluetooth® Phone Using the Menu Buttons Contacts Making a call from contacts In Contacts screen ▶ Press the button ▶ In Phone screen ▶ Press the button to MENU MENU Updating Mobile Phone Contacts use Contacts , Calling list , Favorites , Bluetooth® Press the button ▶... -
Page 34: Calling List
Bluetooth® Phone Calling list Favourites In Contacts screen or Calling list screen ▶ Press and hold the contact you want to save ▶ Press Viewing Calling lists Calling Favourites button. Save to Favourites In Phone screen ▶ Press the button ▶ In Phone screen ▶... -
Page 35: Deleting Favourites
Bluetooth® Phone Bluetooth® settings Deleting Favourites Changing the Favourites name In Favourites screen ▶ Press the button In Favourites screen ▶ Press and hold the favourite MENU In Phone screen ▶ Press the button ▶ MENU ▶ Press the button ▶ Press the you want to change ▶... -
Page 36: Apple Carplay
Apple CarPlay About Apple CarPlay Precautions What you need? CarPlay puts key iPhone apps - the ones you Apple CarPlay is unavailable if the version of 1. An iPhone5 or higher. • • • • want to use while driving - on your vehicle’s communication protocol is not supported or 2. -
Page 37: Starting Mode
Apple CarPlay Starting mode Home Screen Connect your phone to your car using a USB cable. The CarPlay Home screen will be displayed automatically. Description Return to a call, or to turn-by-turn directions Home button When in a different mode, press Media ▶ Apple View current audio source CarPlay. -
Page 38: Speak To Siri
Apple CarPlay Speak to Siri Return to your car’s screen Return to a phone call or to turn-by-turn directions Press and hold the button on the steering Tap the car logo. Or press the key or HOME wheel, or touch and hold the Home button on the desired key on the device. -
Page 39: Setup
Setup Starting mode Position Tone In the Sound Settings screen ▶ Press the In Sound settings screen ▶ Press the button Press the key to display the Setup Tone SETUP ▶ Set the desired sound position. ▶ Set the desired sound balance. screen. -
Page 40: Arkamys
Setup Arkamys Volume setting Beep In Sound settings screen ▶ Press the In Sound settings screen ▶ Press the This menu allows you to play a beep sound Arkamys button ▶ Set the desired mode. button ▶ Set the desired volume. whenever you operate the touch screen. -
Page 41: Display
Setup Display Brightness Dimming mode In Display settings screen ▶ Press the This menu allows you to set the brightness This menu allows you to adjust the brightness according to mode changes. and set the dimming mode for the whole sys- button ▶... -
Page 42: Bluetooth® Settings
Setup Bluetooth® settings Bluetooth® connection Ringtone This menu allow you to manage the Bluetooth® The configured ringtone is played through the This menu allow you to set Bluetooth® settings. device list, such as pairing, connecting or delet- vehicle speakers when you receive a call. Press the key ▶... -
Page 43: Change Passkey
▶ Set the desired button ▶ Enter the passkey. Auto Connection Priority Change passkey settings. NOTE • The default device name is Hyundai Kona AVNC. NOTE NOTE • The default passkey is 0000. • If you press , the most recently No Phone Selected connected Bluetooth®... -
Page 44: System
Setup System Clock Factory settings In System settings screen ▶ Press the This menu allows you to reset settings specified Press the key ▶ Press the button. Clock SETUP System by the user. button ▶ Set the desired settings. I n System settings screen ▶ Press the button ▶... -
Page 45: Connectivity
Setup Connectivity This menu allows you to set the car connectivity of your system. Press the key ▶ Press the SETUP Connectivity button ▶ Press the desired settings. -
Page 46: Specification
Specification USB MP3 Specification Video and Image Specification Category Description Category Description Response Specification: MPEG1 AUDIO File Format AVI(DivX), MPEG MP3 File Specification LAYER3 Image Format jpg, gif, bmp, png Response Sampling Frequency : 32, 44.1, 48 Extensions avi, divx, mpg, mpeg, mp4, wmv (KHz) Recommended Bitrate and Sampling Frequency... -
Page 47: Tft-Lcd
Specification TFT-LCD Bluetooth® Wireless Technology Frequency Range 2402 ~ 2408 MHz Screen Size 8 inch (177.6 mm) diagonal Supported Bluetooth® Resolution 384,000 pixels (Resolution : 800 x 480) 2.1+EDR Specification Operating Method Supported Profile HFP (1.5) , A2DP (1.2) , AVRCP (1.4) , PBAP(1.0) Viewing Angle Left/Right, Top/Bottom: (80°, 80°, 80°, 80°) Bluetooth®... -
Page 48: Before Thinking There Is A Product Defect
Before thinking there is a product defect tires). • A route guidance signaling for a u-turn may The current car position as shown on occur in some No u-turn intersections. • When using tires of improper size. the navigation may differ from the • Route guidance signaling entrance into a actual position under the following • When the tire pressure for the 4 tires are... -
Page 49: Trouble Shooting
Trouble shooting 1. Errors which occur during the operation or installation of the device may be mistaken as a malfunction of the actual device. 2. If you are having problems with the device, try the suggestions listed below. 3. If the problems persist, contact your dealer Problem Possible Cause There are small red, blue, or green dots on the... - Page 50 Trouble shooting Problem Possible Cause Countermeasure Replace with a suitable fuse. • • The fuse is disconnected. The power does not If the fuse is disconnected again, please contact your point of purchase or service center. • • turn on. Device is not properly connected.
- Page 51 Trouble shooting Problem Possible Cause Countermeasure Vibration is occurring from where the The sound may be short circuited and the image distorted if the device vibrates. The sound or image conversion switch has been installed. quality is low. Image colour/tone quality is low. The device will return to normal once vibrations stop.
-
Page 52: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
