CAR MULTIMEIDA SYSTEM (MTXNC10BA)
USER'S MANUAL
i10
Please read this manual carefully before operating your set and retain it for future reference. Designs and specifica-
tions are subject to change without prior notice.
The screens shown in this manual may differ from the actual screens of the product.
The design and specification of this product may change without prior notification for product improvement.
When transferring the vehicle to another individual, include this user's manual so that the next driver can continue its use.
ENGLISH
ESPAÑOL
Rev.2.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MTXNC10BA and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai MTXNC10BA

Summary of Contents for Hyundai MTXNC10BA

  • Page 1 ENGLISH ESPAÑOL CAR MULTIMEIDA SYSTEM (MTXNC10BA) USER’S MANUAL Please read this manual carefully before operating your set and retain it for future reference. Designs and specifica- tions are subject to change without prior notice. The screens shown in this manual may differ from the actual screens of the product.
  • Page 2 iPod® Cortex iPod® is a registered trademark of Apple Inc. Cortex is the name of the ARM Processor Architecture used in the AV System. Bluetooth® Windows Embedded Compact 7 The Bluetooth® Wireless Technology word mark and logos are registered Windows Embedded Compact 7 is an operating system used in the AV trademarks owned by Bluetooth®...

  • Page 3: Precautions For Safety

    Precautions for safety Safety notes Always operate the vehicle in a safe manner. Do When driving your vehicle, be sure to keep the CAUTION not become distracted by the vehicle while driv- volume of the unit low enough to allow you to ing and always be fully aware of all driving condi- hear sounds coming from the outside.
  • Page 4 Precautions for safety • Do not touch the antenna during thunder or • WARNING: CAUTION: lightening as such acts may lead to lightning • • Do not stare at the screen while driving. Staring • • Do not keep the AV system running with the induced electric shock.

  • Page 5: Key Product Features

    Key Product Features Key Product Features Button Description Wide TFT-LCD Display Display Provides high quality video through a Wide TFT-LCD Display using an LED Back Light. Digital Tuner Feature Digital Tuner using PPL method that supports memory of 20 broadcast stations for each AM and FM modes. Radio Radio broadcast station name Displays broadcast station names for key locations.

  • Page 6: Component Names And Functions

    Component Names and Functions Head Unit Name Description • Power on • When power is off, press to turn power on. Power / • Power off • Volume When power is on, press and hold to turn power off. • Knob Audio off •...
  • Page 7 Component Names and Functions Head Unit Name Description Takes user to phone screen. PHONE Displays the Setup mode. SETUP USB port Connect USB device or iPod. Tune / • FM/AM mode : changes the frequency. • ENTER • • MEDIA (USB/ iPod®) mode : changes the track, file or title Knob...

  • Page 8: Getting Started

    Component Names and Functions Getting started Steering Wheel Button Description When keys are pressed shortly. • FM/AM mode: scans and receives the previous/next fre- • quency. • Media mode: changes the track, file or chapter. ∧ • When keys are pressed and held. ∨...

  • Page 9: Basic Screen

    FM/AM Basic Screen Button Description Home Moves to the home screen. Mode Tab Press the tab to change mode. Back Moves to the previous screen. Preset Displays saved presets. Frequency Displays the current frequency. Preset No. Displays the current preset number. Single tap: seek down.

  • Page 10: Auto Store

    FM/AM Listening to FM/AM radio Scan Press the key to change the mode in FM/AM Press the button to save frequencis Scan order of FM1 ▶ FM2 ▶ AM ▶ FM1 . Plays frequencies saved to presets for 3 seconds Or Press the key ▶...

  • Page 11: Playing Usb Music

    USB Music Playing USB Music List Searching USB Music Files While playing ▶ Press the button Once a USB is connected, USB Music mode will l◀◀ ▶▶l Press the button to display USB Music list to play the previous/next file. operate automatically.

  • Page 12: Playing Usb Video

    USB Video Playing USB Video List Searching USB Video Files While playing ▶ Press the button Once a USB is connected, USB Video mode will l◀◀ ▶▶l Press the button ▶ Press the but- MENU List to play the previous/next file. operate automatically.

  • Page 13: Playing Ipod® Music

    iPod® Music Playing iPod® Music Searching iPod® Music Files Press the button to set List and options menus. While playing ▶ Press the button Once a iPod® is connected, iPod® Music mode l◀◀ ▶▶l to play the previous/next file. will operate automatically. •...
  • Page 14 Bluetooth® Audio Playing Bluetooth® audio Press the key ▶ Press the Media button ▶ Press the button. BT Audio Press the button to play/pause files. • • ▶/ ll Searching Bluetooth® audio Files While playing ▶ Press the button l◀◀ ▶▶l to play the previous/next file.

  • Page 15: Bluetooth Connection

    When a Bluetooth® device is connected, a new device cannot be paired. If you want to pair a new phone, first disconnect the connected Bluetooth® device. When searching from the Bluetooth® device, the car name is ‘Hyundai Motors’ and the default passkey is ‘0000’ .

  • Page 16: Making/Answering Calls

    Bluetooth® Connection Making/Answering Calls Operating Menus during a Call Answering a Call Incoming call notice ▶ Press the Accept Calling by Dialing a Number button or the key on the steering Enter number on the Dial Pad ▶ Press the wheel.

  • Page 17: Bluetooth® Phone

    Bluetooth® Phone Contacts Switching Call to Bluetooth® Phone Making a call from contacts During handsfree call ▶ Press the In Contacts screen ▶ Press the contact you want Use Private In Phone screen ▶ Press the tab. Contacts button or press and hold the key on to call.

  • Page 18: Call History

    Bluetooth® Phone Call History Bluetooth® settings In Phone screen ▶ Press the button. Viewing Call History In Phone screen ▶ Press the tab. Call History Button Description All Calls Displays all calling list. Displays the outgoing calling Dialed list. Displays the incoming calling Received list.

  • Page 19: Android Auto

    Android Auto™ About Android Auto™ Before starting Android Auto™ Home Screen Android Auto™ brings the most useful apps from Installing the Android Auto™ your phone to your vehicle´s screen, optimized Application for easy glancing and control while driving. You Install Android Auto™ Application by following will be able to control things like navigation, below procedure.

  • Page 20: About Apple Carplay

    Apple CarPlay About Apple CarPlay Before starting Apple CarPlay Home Screen CarPlay puts key iPhone apps - the ones you • • Setting Siri on the iPhone want to use while driving - on your vehicle’s Siri must be enabled on your iPhone. If Siri is built-in display.
  • Page 21 Setup Starting mode Sound Display Press the key to display the Setup This menu is used to adjust the sound effects This menu allows you to adjust the brightness SETUP screen. for the whole system. and set the dimming mode for the whole sys- Press the key ▶...

  • Page 22: Phone Projection

    Setup Bluetooth® Phone Projection Date and Time This menu allow you to set Bluetooth® settings. This menu allows you to set the car connectivity Press the key ▶ Press the SETUP Date/Time Press the key ▶ Press the of your system. button.
  • Page 23 Setup System Language This menu allows you to view system informa- This menu allows you to set the language of the tion and reset settings specified by the user. system. Press the key ▶ Press the but- Press the key ▶ Press the but- SETUP System...

  • Page 24: Specification

    Specification USB MP3 Specification Video and Image Specification Category Description Category Description Response Specification: MPEG1 AUDIO File Format AVI(DivX), MPEG MP3 File Specification LAYER3 Image Format jpg, gif, bmp, png Response Sampling Frequency : 32, 44.1, 48 Extensions avi, divx, mpg, mpeg, mp4, wmv (KHz) Recommended Bitrate and Sampling Frequency...
  • Page 25 Specification TFT-LCD Bluetooth Wireless Technology Screen Size 7 inch (154.08 x 85.92 mm) Frequency Range : 2402 ~ 2480 Mhz Resolution 384,000 pixels (Resolution : 800 x 480) Supported Bluetooth jpg, gif, bmp, png Specification : 2.1+EDR Operating Method TFT (Thin Film Tansistor) Active Matrix HFP (1.5) , A2DP ( 1.3) , AVRCP (1.4) , Viewing Angle Left/Right, Top/Bottom: (60°, 60°, 60°, 40°)

  • Page 26: Troubleshooting

    Trouble shooting 1. Errors which occur during the operation or installation of the device may be mistaken as a malfunction of the actual device. 2. If you are having problems with the device, try the suggestions listed below. 3. If the problems persist, contact your dealer Problem Possible Cause There are small red, blue, or green dots on the...
  • Page 27 Trouble shooting Problem Possible Cause Countermeasure • • Replace with a suitable fuse. The fuse is disconnected. The power does not If the fuse is disconnected again, please contact your point of purchase or service center. • • turn on. Device is not properly connected.
  • Page 28 Trouble shooting Problem Possible Cause Countermeasure Vibration is occurring from where the The sound may be short circuited and the image distorted if the device vibrates. The sound or image conversion switch has been installed. quality is low. Image colour/tone quality is low. The device will return to normal once vibrations stop.

  • Page 29: Limited Warranty

    Limited Warranty LIMITED WARRANTY ORIGINAL HEAD UNIT SUPPLIED BY VEHICLE DEALER Product : Product No. : WHAT THIS WARRANTY COVERS 1. Vehicle Dealer Shop (“Dealer”) warrants to you that the Hardware will be free from defects in workmanship and materials under Normal use (“Defects”) from the original date of the registration of the motor vehicle (“Warranty Period”).
  • Page 30 Limited Warranty DEALER LIMITED WARRANTY YOUR LEGAL RIGHTS 4. Some countries may not allow the exclusion or limitation of damages. If any part of this Limited Warranty is held to be invalid or unenforceable, the remainder of the Limited Warranty shall nonetheless remain in full force and effect. 5.

  • Page 31: Fcc Warning

    FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
