Rear wheel mount

1 . Put the wheel back into the rear stay. Turn the wheel to find the position where
the axle fits into the dropout. Be careful to reposition the washers as before
demount.
2. Center the wheel and tighten nuts with wrench key size 1 8 mm.
3. Put plastic cups on axle nuts.
4. Turn the bike back to normal position.
5. Put noodle into noodle holder. If you have loosened the anchor bolt, return the
cable to its original position and tighten the anchor bolt again. Check brake pad
position and adjust as described in "Brakes" chapter.
6. Reconnect the motor connector and check that it is working properly. Fix motor
wire with plastic clamps again. You can use tape too. Do not use binding wire
7. Check shifting of derailleur.
8. Check rear brake.
9. Install derailleur protection.
