Rear wheel tube replacement

Tools: Wrench key size 1 8 mm, Allen key size 5 mm, Tire levers

Rear wheel demount

1 .
Shift the smallest sprocket.
2. Turn the battery off.
3. Release plastic clamps which fix the motor wire with chain stay. Be careful not to
damage wire Unplug the motor connector.
4. Push both brake arms to one another (like when braking) and release the noodle
from noodle holder. In some cases you will need to loosen the brake cable
anchor bolt with Allen key 5 mm to release noodle. Don't forget to return the
cable to its original position later
5. Demount derailleur protection with Allen key size 5 mm.
6. Release the rubber cups from axle nuts. Be careful not to damage the wire.
7. Use wrench key size 1 8 mm to loosen axle nuts. One turn anticlockwise is
