- Page 1 technical data Ceiling Mounted Corner Cassette FXKQ-MAVE...
- Page 2 technical data Ceiling Mounted Corner Cassette FXKQ-MAVE...
-
Page 3: Table Of Contents
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE TABLE OF CONTENTS FXKQ-MAVE Specifications ............2 Technical Specifications . -
Page 4: Specifications
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Specifications ® M o u U n i A V E o o r Q - M I n d C e i F X K 1-1 TECHNICAL SPECIFICATIONS FXKQ25MAVE FXKQ32MAVE FXKQ40MAVE FXKQ63MAVE... -
Page 5: Electrical Specifications (50Hz)
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Specifications 1-1 TECHNICAL SPECIFICATIONS FXKQ25MAVE FXKQ32MAVE FXKQ40MAVE FXKQ63MAVE Notes Nominal cooling capacities are based on : indoor temperature : 27°CDB, 19°CWB, outdoor temperature : 35°CDB, equivalent refrigerant piping : 7.5m (horizontal) Nominal heating capacities are based on : indoor temperature : 20°CDB, outdoor temperature : 7°CDB, 6°CWB, equivalent refrigerant piping : 7.5m (horizontal) Capacities are net, including a deduction for cooling (an addition for heating) for indoor fan motor heat. -
Page 6: Safety Device Settings
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Safety device settings FXKQ25MA FXKQ32MA FXKQ40MA FXKQ63MA PC BOARD FUSE 250V 5A ±3 °C FAN MOTOR THERMAL FUSE ±5 °C FAN MOTOR THERMAL PROTECTOR OFF: 120 / ON: 105 or less °C DRAIN PUMP THERMAL FUSE 3D006691K... -
Page 7: Control Systems
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Control systems Individual control systems FXKQ25MA FXKQ32MA FXKQ40MA FXKQ63MA WIRED REMOTE CONTROL BRC1D52 INFRARED REMOTE CONTROL Heat pump BRC4C61 Cooling only BRC4C63 Centralised control systems FXKQ25MA FXKQ32MA FXKQ40MA FXKQ63MA CENTRALISED REMOTE CONTROL DCS302C51 UNIFIED ON/OFF CONTROL DCS301B51... -
Page 8: Capacity Tables
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Capacity tables 5 - 1 Cooling capacity tables FXKQ-MA TC: Total capacity;kW – SHC: Sensible capacity;kW Unit size Nominal Outdoor Indoor air temperature 14.0WB 16.0WB 18.0WB 19.0WB 20.0WB 22.0WB 24.0WB capacity air temp. -
Page 9: Heating Capacity Tables
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Capacity tables 5 - 2 Heating capacity tables FXKQ-MA Indoor air temperature °CDB Outdoor Unit Size Nominal capacity 16.0 18.0 20.0 21.0 22.0 24.0 air temperature °CDB °CWB -19.8 -20.0 -18.8 -19.0 -16.7... -
Page 10: Dimensional Drawing & Centre Of Gravity
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Dimensional drawing & centre of gravity 6 - 1 Dimensional drawing FXKQ25,32,40MA Required installation space 200 mm or more 1,500 mm or 200 mm or more more 20 mm or more Name Description Liquid pipe connection... -
Page 11: Centre Of Gravity
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Dimensional drawing & centre of gravity 6 - 2 Centre of gravity FXKQ-MA Model FXKQ25,32,40MA 1,110 FXKQ63MA 1,310 4D037079A ® • VRV Systems • Indoor Units... -
Page 12: Piping Diagram
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Piping diagram FXKQ-MA Gas pipe connection port Heat exchanger Liquid pipe connection port Filter Filter Electronic expansion valve Piping connection diameters Model Liquid FXKQ25,32,40MA ø12.7 ø6.4 FXKQ63MA ø15.9 ø9.5 4D034245A ®... -
Page 13: Wiring Diagram
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Wiring diagram 8 - 1 Wiring diagram FXKQ-MA Power supply Electric parts box 220-240V 220V 50Hz 60Hz Note 2 Input from outside Note 1 Note 3 Transmission wiring central remote control Wired remote control (Optional accessory) Indoor Unit... -
Page 14: Sound Data
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Sound data 9 - 1 Sound level data FXKQ-MA Sound pressure level - 220 V Sound pressure level - 240 V Model Sound power level FXKQ25MA FXKQ32MA FXKQ40MA FXKQ63MA data were not available at the time of publication NOTES Reference acoustic pressure 0dB=0.0002μbar Operation noise differs with operation and ambient conditions... -
Page 15: Sound Pressure Spectrum
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Sound data 9 - 2 Sound pressure spectrum FXKQ25,32MA 4D037071 FXKQ40MA 4D037072 Approximate threshold hearing for continuous noise Octave band center frequency (Hz) Approximate threshold hearing for continuous noise Octave band center frequency (Hz) FXKQ63MA 4D037073 Approximate... -
Page 16: Air Flow Pattern
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Air flow pattern FXKQ63MA Heating air velocity distribution Lower air blow 1.5 m/sec 1.0 m/sec 0.5 m/sec Heating temperature distribution Lower air blow 33°C 30°C 27°C 25°C 22°C NOTES The corner type is applicable on a high ceiling. The standard set-up height is 3 m. Shown here is the measurement distribution at the ceiling height of 3 m. -
Page 17: Installation
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Installation 11 - 1 Drainage instructions Rig the drain pipe as shown below and take measures against condensation. Improperly rigged piping could lead to leaks and eventually wet furniture and belongings. Install the drain pipes. - Page 18 • Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Installation 11 - 1 Drainage instructions When piping work is finished • Check if drainage flows smoothly. Open the inspection opening, add approximately 1,000 cc of water slowly into the drain pan and Inspection opening check drainage flow.
-
Page 19: Suspension Bolt Pitch Position
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Installation 11 - 2 Suspension bolt pitch position FXKQ-MA Decoration panel Ceiling opening port Indoor unit Suspension bolt (4 pc.) Model FXKQ25,32,40MA 1,110 1,150 1,200 1,240 FXKQ63MA 1,310 1,350 1,400 1,440 ®... -
Page 20: Service Space
• Indoor Units • CEILING MOUNTED CORNER CASSETTE • FXKQ-MAVE Installation 11 - 3 Service space FXKQ-MA 200 or more 200 or more 1,500 or more 20 or more (Discharge side) (Suction side) NOTES Above figures mean minimum values ® •... - Page 21 Specifications are subject to change without environment. This challenge demands the eco design prior notice. Daikin Europe N.V. explicitly rejects any liability for any direct or and development of a wide range of products and an indirect damage, in the broadest sense, arising from or related to the use energy management system, resulting in energy and/or interpretation of this publication.
