SELECT GATE SG-1A V1.X
4.2.3 RELAY 1 UNLOCK TONE (Function 21)
This is the Touch-Tone™ number that the house would press to activate relay 1 on the
Select Gate for the programmed unlock time. This time is from 1 to 99 seconds. Any single
Touch-Tone™ from 1 through 9 may be used to energize relay 1. Touch-Tone™ 0 is used to
disable functions on the Select Gate.
To change from the default of 6 to 1:
4.2.4 RELAY 1 LATCH TONE ( Function 22)
This is the Touch-Tone™ number that the house would press, after calling the Select Gate
and entering the 2 digit control password, in order to activate relay 1 on the Select Gate for
unlimited time. Any single Touch-Tone™ from 1 through 9 may be used to energize relay 1.
Touch-Tone™ 0 is used to disable functions on the Select Gate.
To change from the default of 0 (disabled) to 4:
4.2.5 RELAY 1 ONE HOUR TONE (Function 23)
Relay 1 is energized for one hour when the house calls Select Gate, enters the 2 digit
control password and presses a valid one hour unlock Touch-Tone™.
To change from the default of 0 (disabled) to 7:
4.2.6 RELAY 1 OPEN TIME (Function 24)
This is the length of time that relay 1 is energized when the house presses a valid unlock
tone. This time can be programmed from 1 to 99 seconds.
To change from the default of 2 seconds to 5 seconds:
Note the leading "0" for time less than 10 seconds.
NOTE: IF LEADING 0 FOR TIME LESS THAN 10 SECONDS IS NOT
ENTERED, TIME WILL NOT CHANGE FROM PREVIOUS SETTING.
SELECT ENGINEERED SYSTEMS 11/01
2
1 1
4
2 2
2 3 7
21
