Page 2
Cellular Select Gate Overview Please read this en re guide before a emp ng to install this system. This system should only be installed by an authorized installer/dealer. Site Survey Before installing this system, you need to be sure that there is good GSM cell coverage in the area it is to be installed. It is recommended that you conduct a site survey, and check recep on on the site for a GSM network. If recep on is poor in the area, then this system is not recommended. This unit currently operates on AT&T and T‐Mobile networks in the USA. It is recommended that the system be set up, config‐ ured, commissioned and tested on a workshop bench before being taken to customer site for installa on. SIM Card You will need a GSM network SIM card in order to use this system. It should be a regular voice and SMS text SIM card. Do not use a data only SIM, as this type of SIM is only for tablets and will not work in the Cellu lar Select Gate. SIM Card has already been installed in your New Cellular Select Gate Ac va on Instruc ons. Locate the AT&T SIM card holder a ached to the ac va on card en‐ closed with the Cellular Select Gate. Call 786‐202‐0862 to ac vate SIM card. (Basic informa on is required for add‐on or ac va on of new ac‐ count). ...
Page 3
Cellular Select Gate Components Cellular Antenna Keypad Can call 10 numbers. Speaker Can be used for PIN keypad entry codes. See Pg. 6 for Programming Instruc ons. Microphone Call Bu on Can call up to 3 phone numbers in rollover sequence. 16.5 20 VA AC Supplied Transformer Op onal Curb and Street mount pedestals. ...
Page 4
Cellular Select Gate Connec ons Side view Op onal Card Reader connec ons Relay 1 Power (Red) Comm (Blk) N/C COM D1 (Wht) N/O D0 (Grn) Power Connec ons: Control Signals 16.5 VAC 20 VA Request to Exit transformer provided. Relay 2 COM (Will also accept Connec ons Gate Sense AC or DC 12‐24 Volts.) Power must use 18 ga wire up to 50 feet. Top view Relay 2 N/O COM N/C ...
Page 5
Cellular Select Gate Grounding The Cellular Select Gate case MUST be grounded to a good earth ground. Use at least a #16 gauge wire no more than 25 feet from the Cellular Select Gate to the earth ground rod. Ground wire Grounding Rod Ground Rod Clamp...
Page 6
Cellular Select Gate Keypad Programming This is how to set a Cellular Select Gate keypad digit to dial a phone number; how to call a number; and how to clear a number already assigned to a keypad digit. Enter Programming Mode [4-digit password] * Keypad Steps Select Gate Response 2 beeps...
Page 7
Cellular Select Gate LED Indicators 3 Sec. Solid = Started, or in use. RF Clicker Read. 1.5 Sec. Flash = Ready (Useful for walk test.) Power on. Flashing = Standby RF Receiver on. Solid = In use Op onal RF Card Receiver. SGMC Mobile App available from Google Play or the App Store. (Scan QR code at le .) ...
Page 8
“BETTER TECHNOLOGY MAKES BETTER SYSTEMS” www.selectses.com 07/16 Select Engineered Systems, Inc. 7991 West 26th Ave. Hialeah, FL 33016 Toll Free: 1-800-342-5737 In FL: 305-823-5410 Fax: 305-823-5215 website www.selectses.com e-mail sales@selectses.com...
