4.3.6. Profipower SD700 Type 4 Module
This is also a pre-defined module, although broader than the
previous one. A high number of Modbus registers for reading and
writing has been defined. User only must write the value of the
registers.
Pre-defined registers for these modules are shown in the attached
table.
The Profipower gateway receives 54 bytes of output data of the
ProfiBus-DP Master.
Output Data (Word)
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Variables
LOCAL_SPEED_REF
HOST_START_CONTROL
HOST_STOP_CONTROL
HOST_RESET_CONTROL
HOST_TRIP_CONTROL
LIMIT1_MIN_SPEED
LIMIT2_MIN_SPEED
LIMIT1_MAX_SPEED
LIMIT2_MAX_SPEED
CURRENT_LIMIT
TORQUE_LIMIT
INVERTED_SPEED_ENABLED
NAMEPLATE_MOTOR_CURRENT
NAMEPLATE_MOTOR_POWER
ACCELERATION_RATE
ALT_ACCELERATION_RATE
DECELERATION_RATE
ALT_DECELERATION_RATE
ACC_BRAKE_SPEED
DEC_BRAKE_SPEED
CURRENT_LIMIT_TIMEOUT
STOP_TIMEOUT
TORQUE_LIMIT_TIMEOUT
SUPPLY_UNDER_VOLTAGE
SUPPLY_OVE_VOLTAGE
CURRENT_LIMIT
TORQUE_LIMIT
