ITT ProSmart Installation & Operation Manual page 71

ProSmart Installation & Operation Guide
APPENDIX A-2 PROSMART DATA SHEETS
ProSmart CM
CERTIFICATIONS
RATINGS..............................
RADIO
RADIO OUTPUT POWER...........200mW (B05686AXX, B06480AXX)
RADIO FREQUENCY.................2.4GHz FHSS (Frequency Hopping Spread
ENVIRONMENTAL LIMITS
ENCLOSURE RATING.....................NEMA 4X
ENCLOSURE MATERIAL..................Painted 304 Stainless Steel
HUMIDITY..................................10-90% non-condensing
ENVELOPE DIMENSIONS................20.0"H x 10.0'W x 5.5"D
WEIGHT....................................15lbs (6.8kg)
STORAGE TEMP. MAX..................185°F (85°C)
STORAGE TEMP. MIN...................-40°F (-40°C)
COMMUNICATIONS
WIRELESS ARCHITECTURE.............Point-to-Multipoint
WIRELESS PROTOCOL...................Proprietary Frequency Hopping Spread
DEVICE ENCRYPTION....................Up to 256-bit
GUI ENCRYPTION........................128 Bit SSL
GUI BROWSER............................Internet Explorer 7.0
TRANSMITTING RANGE................1.6 miles (2.5kM) Line of Sight
Certified for Construction Purposes only when signed
Date.......................................................................
Copyright 2011
Drawing is not to scale
ITT Corp.
Dimensions in inches
No reproduction without
permission
Page 71
Communication Module
CSA, FCC, CE
CM LAN – Class I Division 2 Groups A B C D T4
CM GPRS – Non-Hazardous
CM-CDMA – Non-Hazardous
100mW (B05385AXX)
Spectrum)
(includes antenna)
Spectrum (FHSS) 2.4 GHz
655-1310ft (200-400m) Plant*
*depends on industrial environment
ISSUE:
Data Sheet
ProSmart CM-LAN
OP TEMP. RANGE....................158°F (70°C) to -22°F (-30°C)
COMMUNICATIONS
NETWORK CONNECTION...........LAN or DSL
NETWORK PROTOCOL...............Standard Ethernet
NETWORK ADDRESSING............DHCP or Static IP
ELECTRICAL
SUPPLY VOLTAGE.....................12VDC
MAX. CURRENT DRAW...............400mA
POWER CONSUMPTION.............5W
ProSmart CM-GPRS
OP TEMP. RANGE....................131°F (55°C) to -8°F (-20°C)
COMMUNICATIONS
NETWORK CONNECTION...........GPRS Modem
NETWORK PROTOCOL...............Standard Ethernet
NETWORK ADDRESSING............DHCP
ELECTRICAL
SUPPLY VOLTAGE.....................12VDC
MAX. CURRENT DRAW...............2A
POWER CONSUMPTION.............24W
ProSmart CM-CDMA
OP TEMP. RANGE....................158°F (70°C) to -22°F (-30°C)
COMMUNICATIONS
NETWORK CONNECTION...........CDMA Modem
NETWORK PROTOCOL...............Standard Ethernet
NETWORK ADDRESSING............DHCP
ELECTRICAL
SUPPLY VOLTAGE.....................12VDC
MAX. CURRENT DRAW...............1A
POWER CONSUMPTION.............12W
Customer Name
......................................................................
Goulds S/N
.............................................................................
Customer P.O #
...............................................................................
Item No
..................................................................................
Drawn: J. Sullivan
Checked:
PROSMART
(T-Mobile cellular data service)
(Verizon cellular data service)
Drawing
A05686A
Revision Sheet
1 of 2
0
