INSTALLATION INSTRUCTIONS FOR YOUR NEW
Before you begin—Read these instructions completely and carefully.
IMPORTANT—Save these instructions for local inspector's use.
IMPORTANT—OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer—Be sure to leave these instructions with the Consumer.
OWNER—Keep these instructions for future reference.
Note—This appliance must be properly grounded.
FOR YOUR SAFETY
CAUTION:
For Personal Safety remove house
STOP!
fuse or open circuit breaker before
beginning installation. Failure to do
so could result in serious injury or
even death.
• Be sure your cooktop is installed properly by a
qualified installer or service technician.
• To eliminate the risk of burns or fire by reaching over
heated surface elements, cabinet storage located
above the surface units should be avoided. If
cabinet storage space is to be provided, the risk can
be reduced by installing a range hood that projects
horizontally a minimum of 5" beyond the bottom of
the cabinets. Cabinet installation above the counter
unit may be no deeper than 13".
• The cooktop should be easy to reach and lighted
with natural light during the day.
• Always disconnect the electrical service to the unit
before repairing or servicing the counter unit. This
can be done by disconnecting the fuse or circuit
breaker.
Failure to do this could result in a
dangerous or fatal shock. Know where your main
disconnect switch is located. If you don't know,
have your electrician show you.
SR10239
Pub. No. 31-10147
4053P018-4
229C
30" ELECTRIC COOKTOP
• 1/8" drill bit
• Electric or hand drill
• Flat bladed screwdriver
• Pencil
• Ruler or tape measure and straightedge
• Hand or saber saw
ELECTRICAL REQUIREMENTS
This appliance must be supplied with the proper voltage
and frequency, and connected to an individual, properly
grounded branch circuit, protected by a circuit breaker
or time delay fuse, as noted on rating plate.
Wiring must conform to National Electrical Codes. You
can get a copy of the National Electrical Code, ANSI/
NFPA No. 70-Latest Edition by writing:
National Fire Protection Association
Batterymarch Park
Quincy, MA 02269
We recommend that you have the electrical wiring and
hookup of your counter unit done by a qualified
electrician. After installation, have the electrician show
you where your main disconnect is located.
The range connector block is approved for copper wire
connection only, and if you have aluminum house
wiring, you must use special UL approved connectors
for joining copper to aluminum.
You must use a three-wire, A.C. 208Y/120Volt or 120/
240 Volt, 60 Hertz electrical system. A white (neutral)
wire is not needed for this unit.
Refer to the rating plate on your unit for the K.W. rating
for your counter unit.
1
TOOL LIST

Advertisement

loading

  Related Manuals for GE Profile JP350AAAA

  Summary of Contents for GE Profile JP350AAAA

  • Page 1 INSTALLATION INSTRUCTIONS FOR YOUR NEW 30" ELECTRIC COOKTOP Before you begin—Read these instructions completely and carefully. IMPORTANT—Save these instructions for local inspector’s use. IMPORTANT—OBSERVE ALL GOVERNING CODES AND ORDINANCES. Note to Installer—Be sure to leave these instructions with the Consumer. OWNER—Keep these instructions for future reference.
  • Page 2: Preparing The Opening

    PREPARING THE OPENING The following MINIMUM clearance dimensions must be 29 1/2" 20 1/2" maintained: • To insure accuracy, it is best to make a template COOKTOP when cutting the opening in the counter. See Figure 3 3/8" 2 for all necessary dimensions. 28 1/2"...
  • Page 3: Electrical Connections

    Fig. 4 IMPORTANT: The junction box must be located MOUNTING SLOT where it will allow considerable slack in the conduit for serviceability. See Figure 3. BURNER BOX HOLD DOWN SIDES BRACKET BE SURE THIS CUT DOES NOT INTERFERE BE SURE THIS CUT DOES NOT INTERFERE WITH CABINET WITH CABINET STRUCTURE AT FRONT STRUCTURE AT FRONT...
  • Page 4 NOTE TO ELECTRICIAN: BE SURE THIS CUT DOES NOT INTERFERE WITH CABINET STRUCTURE AT FRONT The power leads supplied with this appliance BE SURE THIS CUT DOES NOT INTERFERE WITH CABINET are U.L. recognized for connection to larger STRUCTURE AT FRONT gauge household wiring.
  • Page 5 INSTRUCCIONES DE INSTALACION PARA SU NUEVA CUBIERTA DE COCINAR ELECTRICA DE 30" Antes de empezar—Lea estas instrucciones completa y cuidadosamente. IMPORTANTE—Guarde estas instrucciones para el uso del inspector local. IMPORTANTE—OBSERVE TODOS LOS CODIGOS Y ORDENANZAS VIGENTES. Nota al Instalador—Cerciórese de dejar estas instrucciones con el consumidor. DUEÑO—Guarde estas instrucciones para referencia futura.
  • Page 6: Prepare La Abertura

    Fig. 2 PREPARE LA ABERTURA Se deben mantener las siguientes dimensiones 29 1/2" 20 1/2" MINIMAS de espacio: CUBIERTA DE • Para asegurar la exactitud, es mejor hacer un patrón COCINAR cuando haga el corte en el mesón. Vea la figura 2 3 3/8"...
  • Page 7: Conexiones Electricas

    IMPORTANTE: La caja de conexiones debe RANURA DE MONTAJE estar ubicada de manera que provea una LADO DE CAJA soltura considerable en los circuítos para el ABARAZERA DE QUEMADOR servicio. Vea la figura 3. Fig. 4 Fig. 3 CERCIORESE DE QUE ESTE CORTE NO INTERFIERA CON LA BE SURE THIS CUT DOES NOT ESTRUCTURA DEL GABINETE AL...
  • Page 8 NOTA AL ELECTRICISTA: CERCIORESE DE QUE ESTE CORTE NO INTERFIERA CON LA Los conectores eléctricos que se proveen BE SURE THIS CUT DOES NOT ESTRUCTURA DEL GABINETE AL con esta estufa son reconocidos por U.L. INTERFERE WITH CABINET FRENTE para conexiones con alambres de casa de STRUCTURE AT FRONT tamaño más grande.
