- Page 1 Installation, use and maintenance instructions Light oil burners Low - High or modulating operation CODE MODEL C9514300 - C9514301 - C9514303 RL 70/M C9515300 - C9515301 - C9515303 RL 100/M C9516300 - C9516301 RL 130/M 2916050 (8) - 11/2014...
-
Page 3: Table Of Contents
CONTENTS INFORMATION ABOUT THE INSTRUCTION MANUAL INFORMATION ABOUT THE INSTRUCTION MANUAL ..page 1 INTRODUCTION The instruction manual supplied with the burner: SAFETY AND PREVENTION ......2 is an integral and essential part of the product and must not be sepa- TECHNICAL DATA. -
Page 4: Safety And Prevention
SAFETY AND PREVENTION GUARANTEE AND RESPONSIBILITY The manufacturer guarantees its new products from the installation date, in accordance with the regulations in force and/or the sales contract. At INTRODUCTION the moment of the first start-up, check that the burner is integral and com- The burners have been designed and built in compliance with current plete. -
Page 5: Technical Data
TECHNICAL DATA Model RL 70/M RL 100/M RL 130/M MBtu/hr 1792 - 3136 2688 - 4480 3564 - 5824 High 12.8 - 22.4 19.2 - 32 25.6 - 41.6 Output MBtu/hr 756 - 1792 1260 - 2688 1568 - 3584 5.4 - 12.8... -
Page 6: Burner Models Designations
• Kit for lengthening the combustion head = Standard length L1 = Length obtainable with the kit COD. 3010280 L = 10 ” L1 = 15 ” • RL 70/M 23 / 32 5 / 32 COD. 3010281 L = 10 ” L1 = 15 ”... -
Page 7: Burner Description
Flame safeguard Lock-out: if the Flame relay 23)(A) pushbutton lights up, it indicates that the burner is in lock-out. To reset, press the pushbutton. inch Motor trip: release by pressing the pushbutton on ther- RL 70/M 9 / 32 “ 5 / 8 “ 3 / 16 “... -
Page 8: Firing Rates
FIRING RATES (A) During operation, burner output varies between: • MINIMUM OUTPUT: area A; • MAXIMUM OUTPUT: area B (and C for model RL 130/ Graphs (A): Horizontal axis: Burner output Vertical axis: Combustion chamber pressure The firing rate may be found by plotting a vertical line from the desired delivery and a horizontal line from the pressure in the combustion chamber. -
Page 9: Installation
INSTALLATION NOTES ON SAFETY FOR THE INSTALLATION inch After carefully cleaning all around the area where the RL 70/M “ “ - 12 “ 9 / 32 27 / 32 13 / 16 1 / 2 burner will be installed, and arranging the correct lighting RL 100/M “... -
Page 10: Choice Of Nozzle
RL 70/M, maximum light oil delivery = 16 GPH Diagram (F) indicates that for a delivery of 16 GPH the RL 70/M Model requires the combustion head to be set to approx. three notches, as shown in Figure (E). Max Fuel oil delivery... -
Page 11: Fuel Supply
HYDRAULIC SYSTEM Explosion danger due to fuel leaks in the presence of a flammable source. Precautions: avoid knocking, attrition, sparks and heat. Make sure that the fuel interception tap is closed before performing any operation on the burner. The fuel supply line must be installed by qualified personnel, in compliance with current standards and laws. -
Page 12: Pump
PUMP (A) PUMP SUNTEC J7 C 1 - Suction 1/2" NPT 2 - Return 1/2" NPT 3 - Pressure gauge attachment G 1/8" 4 - Vacuum gauge attachment G 1/8" 5 - Pressure adjustment screw 6 - By-pass screw A - Min. delivery rate at 290 PSI pressure B - Delivery pressure range C - Max. -
Page 13: Servomotor
SERVOMOTOR (A) The servomotor gives simultaneous regulation of the air damper through the adjustable profile cam 2)(F) and the pressure controller (A) pag. 13. It rotates by 130° in approx. 35 s. The factory settings must not be changed for the first fir- ing, just check that they comply with the details below. -
Page 14: Burner Calibration
BURNER CALIBRATION PRESSURE CONTROLLER The first start-up of the burner must be carried out by qualified personnel, as indi- cated in this manual and in compliance WARNING with the standards and regulations of the laws in force. Check the correct working of the adjust- ment, command and safety devices. -
Page 15: Burner Starting
BURNER STARTING Position jumpers Trim potentiometers Close the control circuit, with the switches in fig. (C) and (E) in the AUTO position. On firing turn the switch (C) to MAN. MAXIMUM OUTPUT Slide switch Using button (B), "increase output" until it stops at app. 130°... -
Page 16: Burner Operation
BURNER OPERATION BURNER STARTING (A) - (B) • Operating control closes, the motor starts. The pump 3) draws the fuel from the tank through the piping 1) and pumps it under pressure for delivery. The piston 4) rises and the fuel returns to the tank through the piping 5) - 7). -
Page 17: Flame Signal Measurement
FLAME SIGNAL MEASUREMENT (A) LAL2... Sub-base Min value for a good signal: 8 µA. If the value is lower, it can be due to: • Worn photocell; • Low current; • Bad set up of the burner. In order to measure the current, use a microammeter of 100 A c.c., connected to the scanner, as in the dia- gram. -
Page 18: Final Checks
FINAL CHECKS • Obscure the photocell and switch on the control devices: the burner should start and then lock-out about 5 s after starting. • Illuminate the photocell and switch on the control devices: burner should go into lock-out. • Obscure the photocell while the burner is operating: flame should go out and burner lock out within 1 s. -
Page 19: Opening The Burner
Pump The pump delivery pressure must be stable at 290 PSI. The suction must be less than 6.5 PSI. Unusual noise must not be evident during pump opera- tion. If the pressure is found to be unstable or if the pump runs noisily, the flexible hose must be detached from the line filter and the fuel must be sucked from a tank located near the burner. -
Page 20: Burner Faults
BURNER FAULTS SYMBOL (1) FAULT PROBABLE CAUSE SUGGESTED REMEDY The burner does not start - A limit or safety control device is open ....Adjust or replace - Control box lock-out . -
Page 21: Electrical Wiring
ELECTRICAL WIRING NOTES ON SAFETY FOR THE ELECTRICAL WIRING The electrical wiring must be carried out with the electrical supply disconnected. Electrical wiring must be carried out by qualified personnel and in compliance with the regulations currently in force in the country of destination. -
Page 22: Calibration Of The Thermal Relay
To reset, in the case of an intervention of the thermal relay, press the but- ton 1). D8267 FUSE AND CABLE CALIBRATION Three phase (IE 2/Epact) RL 70/M RL 100/M RL 130/M 208 - 230 V 460 V 575 V... -
Page 23: Motor Connection
Motor connection at 208-230 or 460V WARNING: the motors, manufactured for 208-230/460 IE2/Epact voltage, have a different connection than IE1 motors, no more star/delta but star/double star. Please, pay attention to the indications in case of modification of voltage, maintenance, or substitution. IE2/Epact S8380 S8379... -
Page 24: Spare Parts
APPENDIX - SPARE PARTS... - Page 25 RL 70/M RL 100/M RL 130/M CODE DESCRIPTION • • • • • • • • 3012454 AIR INTAKE • • • • • • • • 3003948 AIR DAMPER ASSEMBLY • • • • • • • • 3003949 GRID •...
- Page 26 RL 70/M RL 100/M RL 130/M CODE DESCRIPTION • • • • • • • • 3012476 NEEDLE VALVE • • • • • • • • 3007169 O RING • • • • • • • • 3012012 HALF-SHELL •...
- Page 27 RL 70/M RL 100/M RL 130/M CODE DESCRIPTION • • • • • • • • 3006098 PIN JOINT • • • • • • • • 3003841 BEARING • • • • • • • • 3012470 TUBE •...
-
Page 28: Procedure To Refer Burner Operating Condition In High Altitude Plants
APPENDIX - PROCEDURE TO REFER BURNER OPERATING CONDITION IN HIGH ALTITUDE PLANTS Find the corrected burner capacity for the plant’s altitude in chart 1 and the corrected pressure in chart 2. Check in the firing rate graph of the burner (page 7), if the working point defined by the values above is within the range limits. If not, higher burner size is needed.
