- Page 1 TMC-1-IMon Monitor Controller CB Electronics TMC-1-IMon Monitor Remote Use with the TMC-1Reference Provisional © 2016 CB Electronics Provisional...
-
Page 2: Table Of Contents
TMC-1-IMon Monitor Controller n ........................Error! Bookmark not defined. TMC-1-IMon User guide ............................3 TMC-1-IMon gain Structure............................3 s ............................4 s ..........................4 s ............................4 n ..............................4 GPO-3 ..................................4 XPand Surround Bass Expansion...........................4 g ............................5 5.1 ....................................5 ) ........................5 e ......................5 Internal Talkback Microphone..........................5 Talkback and Sate Routing ...........................6... -
Page 3: Tmc-1-Imon User Guide
TMC-1-IMon Monitor Controller TMC-1-IMon User guide This document only describes connection details and setup considerations when using I-Mon and should be used with the TMC-1 User guide. TMC-1-IMon gain Structure © 2016 CB Electronics Provisional... -
Page 4: B A S S E X T E N S I O N
TMC-1-IMon Monitor Controller The I-Mon allows for metering of the SLS and H/P Monitor send only, use the [Meter Cues] user key to access. Apart from the Link to the Monitor output there is no provision on the I-Mon to route a stereo input independently to the cue sends. -
Page 5: H D 1 5 C O N N E C T O R ( L A B L E D X - M O N )
You can assign a GPO to be active when 5.1 is selected and use this to drive a relay to switch the rear speakers to the side. The I-Mon is connected to the TMC-1-IMon via a DCC VGA cable, a 7 Meter cable is supplied as standard and extra long cables are available to order. Alternatively a pair RJ45 breakout boards are available with two 0.5 meter DCC VGA cables.. -
Page 6: Talkback And Sate Routing
TMC-1-IMon Monitor Controller Talkback and Sate Routing Headphone Jack The headphone jack is connected directly to the 15 pin "XMon" connector. The input is unbalanced with two ground returns. Listen Back Microphones Use Omni-directional microphones for Listen back, PZM or Boundary effect microphones should work well. -
Page 7: C O N N E C T I N G T H E T M C - 1 T O I - M O N
TMC-1-IMon Monitor Controller Connecting the TMC-1 to XMon using a long DDC VGA Cable RJ45 Breakout card A pair of RJ45 breakout boards can be ordered for use with I-Mon Connecting the TMC-1 to the I-Mon using a pair of RJ45 breakout boxes... -
Page 8: I - M O N B L O C K D I A G R A M
TMC-1-IMon Monitor Controller © 2016 CB Electronics Provisional... - Page 9 Speaker trim range is restricted to +/- 4dB Input makeup gain +20dB to -10dB CB Electronics has made every effort to ensure the accuracy of information contained within this document, which is nevertheless supplied for information purposes only and does not constitute any form of warranty or guarantee.
- Page 10 TMC-1-IMon Monitor Controller CB Electronics Loddonside, Lands End House Beggars Hill Road Charvil Berkshire RG10 0UD Tel: +44 (0)118 9320345 Fax: +44 (0)118 9320346 Email: support@colinbroad.com Tech Support: +44 (0)118 9320345 Web: www.colinbroad.com © 2016 CB Electronics Provisional...
