- Page 1 1000BASE-T1 SFP MODULE USER MANUAL April 2019 Manual-Version: 2.0 Hardware-Version: 2.2...
-
Page 2: Table Of Contents
CONTENT GENERAL INFORMATION ................... 3 Functionality and Features of the 1000BASE-T1 SFP MODULE ....... 3 Warranty and Safety Information ................ 5 Declaration of conformity ..................6 HARDWARE INTERFACES ..................7 Molex Connector ....................7 SFP Socket Connector ..................8 STARTUP AND CONFIGURATION ................9 Startup ........................ -
Page 3: General Information
1.1 Functionality and Features of the 1000BASE-T1 SFP MODULE Figure 1-1: 1000BASE-T1 SFP MODULE The Technica Engineering 1000Base-T1 SFP Module fits into a standard Small Form- factor Pluggable slot. It uses the SGMII and generates 1000 Mbit/s full-duplex 1000BASE-T1. It is self-configurating after powerup to Automotive 1000BASE-T1. - Page 4 Weight: 0,1 kg International Protection: IP 2 0 Operating temperature: 0 to +70 °Celsius Integrated PHY 88Q2112_A0 from Marvell LINKS: The User can download the latest firmware and documentation for the 1000BASE-T1 SFP MODULE here: https://technica-engineering.de/produkt/1000base-t1-sfp-module/ 100BASE-T1 MediaConverter_BCM User Manual...
-
Page 5: Warranty And Safety Information
1.2 Warranty and Safety Information Before operating the device, read this manual thoroughly and retain it for your reference. The latest documentation for the 1000BASE-T1 SFP MODULE can be downloaded here: https://technica-engineering.de/produkt/1000base-t1-sfp-module/ Use the device only as described in this manual. -
Page 6: Declaration Of Conformity
1.3 Declaration of conformity Figure 1-2: Declaration of conformity 100BASE-T1 MediaConverter_BCM User Manual... -
Page 7: Hardware Interfaces
2 HARDWARE INTERFACES 2.1 Molex Connector The 1000BASE-T1 line is connected by a Molex connector. • Molex 0533250260 Header 2.0mm • Molex 510900200 Housing • Molex 50212-8000 Crimp Contact Name Picture Part Number Molex Header 2.0mm 0533250260 Molex Housing 51090-0200... -
Page 8: Sfp Socket Connector
2.2 SFP Socket Connector Pinning: Function Function SGMII_RXD_N n.c. SGMII_RXD_P I2C_DAT I2C_CLK 3.3. Volt 3.3. Volt n.c. SGMII_TXD_P n.c. SGMII_TXD_N Table 2-3: Pinning of SFP Socket Connector 100BASE-T1 MediaConverter_BCM User Manual... -
Page 9: Startup And Configuration
88Q2112_A0 transceiver by MDIO interface. This lasts 100ms. Do not apply any I2C activity on the bus during this time! 3.2 Self-Configuration The SFP Module configures itself to 1000BASE-T1 after power up. Master-/Slave Configuration is done according to the DIP switch on the bottom of the device. Figure 3-1: DIP-Switch To reconfigure the DIP switch the lock has to be opened (see pictures). -
Page 10: I2C Interface
3.3 I2C Interface 3.3.1 I2C configuration 100ms after power up of the module it can be configured by I2C. The module operates with f up to 53kHz without requiring clock stretching. The module may clock stretch with f greater than 53kHz and up to 400 kHz. The module processor listens as slave on the 7-bit address 0x50. -
Page 11: I2C Map Register
3.3.2 I2C map register Memory Map (read only registers): Data Bytes Byte Comment Number 0x03 Identifier SFP 0x04 Ext. Identifier 0x80 Connector 0x00, 0x00, 0x00, 0x00 Transceiver high 0x00, 0x00, 0x00, 0x00 7-10 Transceiver low 0x00 Encoding 0x01 Bitrate Nominal in 100 MBit 0x00 Reserved 0x00... -
Page 12: Random Address Read
Example: Read the current address of the SFP module (b1010000X). 3.3.3.2 Random address read The random address read requires two operations to perform the read. Example: Read a random address of the SFP module (b1010000X) First a write operation to specify the address desired to read: 100BASE-T1 MediaConverter_BCM User Manual... -
Page 13: Sequential Read
Then a read operation to read the previous address specified: 3.3.3.3 Sequential read The sequential reads are started by either a current word address read or a random address read. To specify a sequential read, the host responds with an acknowledge instead of a stop after each data word. -
Page 14: Byte Write
Then the read operations: 3.3.3.4 Byte Write The write operation requires 8-bits of data word address following the device address write word and acknowledgement. Example: Byte write operation into the SFP module (b1010000X) 3.3.3.5 Sequential write The sequential write is started in the same way as a single byte write, but the host master does not send a stop condition after the first word is clocked in. -
Page 15: I2C Access To The 88Q2112_A0 Transceiver
3.3.4 I2C access to the 88Q2112_A0 transceiver The 88Q2112_A0 PHY listens as slave on the 7-bit address 0x40. Every internal register of the PHY (16 bits) is accessed by defining the Device Number (1 byte) and the Register address (2 bytes). The I2C Memory address is mapped as: Address Register name 0x00... - Page 16 o Bit 3 – Write Start Condition Flag (Read) This flag is set by the slave when a write operation is trigged. o Bit 4 – Write In Progress Flag (Read) This flag is set by the slave during the writing operation o Bit 5 –...
-
Page 17: Additional Information
4 ADDITIONAL INFORMATION • The 1000BASE-T1 SFP MODULE is optimized for automotive use. The maximum cable length for 1000BASE-T1 segments is limited to 15 meters 100BASE-T1 MediaConverter_BCM User Manual... -
Page 18: List Of Figures
5 LIST OF FIGURES Figure 1-1: 100BASE-T1 SFP MODULE ................3 Figure 1-2: Declaration of conformity ................6 Figure 3-1: DIP-Switch ......................9 100BASE-T1 MediaConverter_BCM User Manual... -
Page 19: Changelog
6 CHANGELOG Version Chapter Description Date First release Complete rework of all chapters 25.04.2019 100BASE-T1 MediaConverter_BCM User Manual... -
Page 20: Contact
7 CONTACT If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Technical support: support@technica-engineering.de General information: Info@technica-engineering.de Most current user manuals and product information: https://technica-engineering.de/ 100BASE-T1 MediaConverter_BCM User Manual...
