Technica 100BASE-T1 SPY Mini User Manual

Hide thumbs Also See for 100BASE-T1 SPY Mini:
Table of Contents

Advertisement

Quick Links

Download this manual
100BASE-T1
1000BASE-T1
MEDIACONVERTER
SPY mini
BCM
USER MANUAL
July 2019
Manual-Version: 2.2
Hardware-Version:1.0

Advertisement

Table of Contents
loading

Related Manuals for Technica 100BASE-T1 SPY Mini

Summary of Contents for Technica 100BASE-T1 SPY Mini

  • Page 1 100BASE-T1 1000BASE-T1 MEDIACONVERTER SPY mini USER MANUAL July 2019 Manual-Version: 2.2 Hardware-Version:1.0...

  • Page 2: Table Of Contents

    CONTENT GENERAL INFORMATION ................... 3 Functionality and Features of the 1000BASE-T1 SPY mini ....... 3 Warranty and Safety Information ................ 5 Declaration of conformity ..................6 HARDWARE INTERFACES ..................7 Connectors ......................7 2.1.1 Power and 1000BASE-T1 Connector ............8 2.1.2 SubD 9 Trigger Connector ................

  • Page 3: General Information

    1.1 Functionality and Features of the 1000BASE-T1 SPY mini Figure 1-1: 1000BASE-T1 SPY mini The Technica Engineering 1000Base-T1 SPY mini samples 1000Base-T1 Frames directly on the bus without influence of the original network. The data Frames are enhanced with additional in-formation as an exact timestamp and the bus port which the data was originally sent on.
  • Page 4 110 x 108 x 28 mm Weight: 0,4 kg International Protection: IP 2 0 Operating temperature: -20 to +80 °Celsius LINKS: The User can download the latest firmware and documentation for the 1000BASE-T1 SPY mini here: https://technica-engineering.de/en/produkt/1000base-t1-spy-mini/ 1000BASE-T1 SPY mini User Manual...

  • Page 5: Warranty And Safety Information

    1.2 Warranty and Safety Information Before operating the device, read this manual thoroughly and retain it for your reference. The latest documentation for the 100BASE-T1 SPY mini can be downloaded here: https://technica-engineering.de/en/produkt/1000base-t1-spy-mini/ Use the device only as described in this manual.

  • Page 6: Declaration Of Conformity

    1.3 Declaration of conformity Figure 1-2: Declaration of conformity 1000BASE-T1 SPY mini User Manual...

  • Page 7: Hardware Interfaces

    2 HARDWARE INTERFACES 2.1 Connectors On the label on top of the device you can see an overview about all HW-Interfaces of the 1000BASE-T1 SPY mini Figure 2-1: Label of 1000BASE-T1 SPY mini with pinning information 1000BASE-T1 SPY mini User Manual...

  • Page 8: Power And 1000Base-T1 Connector

    2.1.1 Power and 1000BASE-T1 Connector Power supply for the device is supplied by Pin 18 (12 Volt) and Pin 20 (Ground). Warning: If you apply a voltage higher than 18 Volt, the device will be damaged! The Tyco Electronics (TE) Nano Micro Quad Lock System (NanoMQS) is used. Name Picture Part Number...

  • Page 9: Subd 9 Trigger Connector

    2.1.1.1 Official Crimp Tool Name TE CONNECTIVITY CS11K NANO-MQS, 0.13-0.35 SQ.M TE Internal Number 4 -1579014 – 0 Distributor Börsig GmbH www.boersig.com Address Siegmund-Loewe-Str. 5 74172 Neckarsulm 2.1.2 SubD 9 Trigger Connector Standard SubD 9 Pos. female connector. This connector is used for digital input and output trigger functions. 1000BASE-T1 SPY mini User Manual...

  • Page 10: Rj45 Ethernet Connectors

    Function Digital Trigger Input / Output 1 Digital Trigger Input / Output 2 Signal Ground Reference Signal Ground Reference Signal Ground Reference Digital Trigger Input / Output 3 Digital Trigger Input / Output 4 Digital Trigger Input / Output 5 Digital Trigger Input / Output 6 Table 2—3: Pinning information SubD9 Connector Digital Trigger Output:...

  • Page 11: Other Interfaces

    2.2 Other Interfaces 2.2.1 Status LEDs The 1000Base-T1 SPY mini has several status LEDs at the front side of the case. State Host Toggles slowly (approx. 2sec) FPGA GB A On when 1000BASE-T1 link is detected on port 1 GB B On when 1000BASE-T1 link is detected on port 2 RJ45 (orange) On when link is detected...

  • Page 12: Configuration Of The Device

    3 CONFIGURATION OF THE DEVICE The 1000Base-T1 SPY mini is configured by 8 DIP Switches on the front of the device. DIP-Switch Status Description ON (up) 1000Base-T1 Port A is set to Master. OFF (down) 1000Base-T1 Port A is set to Slave. ON (up) 1000Base-T1 Port B is set to Master.

  • Page 13: Use Cases

    4 USE CASES Four different Use Cases can be configured by DIP Switch 3 and 4 for the 1000Base- T1_SPY_mini. After changing these switches, a hardware reset is required. 4.1 Dual Media Converter Mode The simplest Use Case is the double Media Converter, selected by setting the DIP switches 3 and 4 to “00”...

  • Page 14: Spy Mode Independent

    4.2 Spy Mode Independent The user can select this mode by setting the DIP switches 3 and 4 to “01” (DIP Switch 3 down and DIP Switch 4 up). In this mode the copied data from the two 1000Base-T1 Ports are logged independently through the 2 Ethernets ports.
  • Page 15 In the Spy Mode, the signals received in 1000Base-T1 Port 1 and 1000Base-T1 Port 2 are combined in one stream and sent on Ethernet Port. The PC is not able to send data. The RJ45 Ports are output only. The communication between the two 1000Base-T1 ports is possible.

  • Page 16: Spy Mode With Wrapper

    4.4 Spy Mode with wrapper The user can activate the wrapper by setting the DIP Switch 5 to the up position. With this feature, a header is added on the Ethernet sent frame. The packet received in the 1000Base-T1 port will be logged through the corresponding Ethernet Port into an Ethernet RAW frame.
  • Page 17 Port The following table shows the values of field: Port Value 1000BASE-T1 A 0x01 1000BASE-T1 B 0x02 Table 4-2: Values of Field “Port” in wrapped frame The following picture shows an example of a 1000Base-T1 payload frame encapsulated in a 1000Base-T1 RAW frame, with header: Figure 4-5: Screenshot of 1000BASE-T1_SPY_mini frame 1000BASE-T1 SPY mini User Manual...

  • Page 18: 1000Base-T1 Spy Mini Lua Dissector For Wrapped Data

    In order to dissect the 1000Base-T1 SPY mini RAW Ethernet Frames, a LUA file for Wireshark is available on Technica Engineering website. To install the LUA file in Wireshark, the user must do the following steps: 1. Close Wireshark in case that the program is running on PC.

  • Page 19: 802.1 As Synchronization

    6. To copy or move the LUA files to the specified Wireshark plugins folder, Administrator rights will be needed. In that case, this window should appear. Press Continue to proceed with the copy. Figure 5-1: Dialog Box for Administrator rights 7.

  • Page 20: Ptp Of 802.1 As Protocol

    5.1.1 PTP of 802.1 AS Protocol In an 802.1AS topology, the com- munication between a Master and a Slave Node is as you can see in the picture to the right. For a generic time t , the Slave device can correct this time as follows: tx‘...

  • Page 21: 802.1 As (Ptp) In 1000Base-T1 Spy Mini

    5.1.2 802.1 AS (PTP) in 1000Base-T1 SPY Mini The 1000Base-T1 SPY Mini device works only as a Slave device, sending Request messages to the Master device through GB-2 port. Connecting a Master Device to this port, the device will synchronize its internal clock and it will use this corrected clock as Timestamping on the Wrapper Mode.

  • Page 22: Additional Information

    6 ADDITIONAL INFORMATION For the SPY mode -independent or combined-, the delay between two BroadR- • Reach ports is around 1.19µs. The delay is independent of the Ethernet packet frame size. The SPY is especially built for testing AVB. For minimum delay the SPY must be •...

  • Page 23: List Of Figures

    7 LIST OF FIGURES Figure 1-1: 1000BASE-T1 SPY mini ................... 3 Figure 1-2: Declaration of conformity ................6 Figure 2-1: Label of 1000BASE-T1 SPY mini with pinning information ......7 Figure 4-1: Dual Media Converter Mode ................. 13 Figure 4-2: SPY mode independent ................. 14 Figure 4-3: UseCase "10": Spy Mode Combined .............

  • Page 24: Changelog

    8 CHANGELOG Version Chapter Description Date First release 01.06.2018 6.4 table 4 Correction of Ethertype 06.08.2018 Second release with new design 06.08.2018 2.1.1 Correction bugs 25.02.2018 2.1.2 Correction pinning table 09.05.2019 General upgrade 05.06.2019 1000BASE-T1 SPY mini User Manual...

  • Page 25: Contact

    9 CONTACT If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Technical support: support@technica-engineering.de General information: Info@technica-engineering.de Most current user manuals and product information: https://technica-engineering.de/ 1000BASE-T1 SPY mini User Manual...
