Description
Meter Description
1.
Test Lead alligator clips
2.
Test lead input jacks
3.
L1, L2, L3 display icons
4.
Clockwise Rotation LCD Indicator R (right) and L (left)
icons
5.
Sequence grid
Display Description
1.
Line designators (L1, L2, and L3)
2.
Color codes for test leads
3.
Clockwise / Counter-Clockwise indicator
4.
LEFT (L) or RIGHT (R) rotation direction
5.
Phase Sequence grid
www.ponpe.com
1
2
3
4
1
2
3
4
3
2
3
5
4
5
5
480400‐en‐EU_V3.3 9/14
