  • Page 1 Winner EVO Series OPERATION MANUAL...
  • Page 2 CAUTION The operator should read and be familiar with the precautions and operation of this device prior to beginning treatments. This device is not designed to be connected with any electrical equipment or accessories unless manufactured and/or approved by Rich-Mar. This includes whirlpools, lead cords, probes, self- adhesive electrodes and carbon electrodes NOT manufactured by Rich-Mar.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS WARRANTY ..................................3 WINNER SERIES ILLUSTRATIONS ..........................4 INTRODUCTION ................................. 11 STIMULATION INDICATIONS FOR TREATMENT ....................18 MICROCURRENT INDICATIONS FOR TREATMENT ..................18 ELECTRICAL STIMULATION WAVE FORMS .......................19 ULTRASOUND INDICATIONS FOR TREATMENT ....................21 ULTRASOUND CONTRAINDICATIONS & WARNINGS ..................21 ULTRASOUND INTRODUCTION AND OVERVIEW ..................22 ULTRASOUND CALIBRATION &...

  • Page 4: Warranty

    Product is returned to Rich-Mar. All repairs to the Product must be performed by Richmar or a Richmar Authorized Service Center. Any modifications or repairs performed by unarthorized centers or groups will void this warranty.
  • Page 5 WINNER EVO SERIES FRONT VIEW WINNER EVO COMBO WINNER EVO STIM Ultrasound User Interface E-Stim User Interface E-Stim User Interface Intensity Knob Intensity Knob 2 or 4 Channel Output 2 or 4 Channel Output...
  • Page 6 WINNER EVO SERIES REAR VIEW Ultrasound Applicator Cradle Unit Power Module with ON/OFF Switch Laser/Light Module (optional) Electrical Stim Lead Cord Test Jack Ultrasound Applicator Plug (CM units) Cooling Fan Combo Mode Stim Lead Jack...
  • Page 7 USER INTERFACE Winner EVO Combo...
  • Page 8 USER INTERFACE Winner EVO Stim...
  • Page 9 USER INTERFACE Ultrasound Time Display and Adjust Ultrasound Start/Stop Ultrasound Intensity Display and Adjust Ultrasound Frequency W/cm or Watts Display Select Ultrasound Duty Cycle Ultrasound Pause/Resume Applicator Select E-Stim Time Display and Adjust Pulse Rate Select Intensity Display Channel Select Pulse Rate Adjust Time ON/OFF Select User Defined Profiles...

  • Page 10: Introduction

    Introduction Electrical Stimulation The Winner units are products that resulted from dedication to Once the device is turned on, you will notice that the green research and development. The Winner units offer the most LED lights in the Waveforms (Quadpolar IFC, Pre-Mod IFC, flexible treatment possibilities in a convenient, easy-to-use Russian, HiVolt and Micro) and the Therapy Profiles are package.
  • Page 11 You will also notice that the green Selected LED light on Ch. Pre-Mod IFC will output pre-modulated, two-pad 1 went out but its green Active LED light is still illuminated. Interferential current in any of the desired Modes (Normal, This means that there is a treatment currently on Ch. 1 but its Surge, Co-Cont and Alternating).
  • Page 12 To Adjust Stimulation Intensity during Treatment The High-Low Scan pulse rate mode will split the treatment Intensity can be adjusted during treatment, even during the off time in half with the first half using the High pulse rate scan cycle in Surge or Alternating modes, simply by pressing the and the second half using the Low pulse rate scan.
  • Page 13 Therapy Profiles – Lead Cord Tester The Winner devices will allow you to use either the Easy The Winners have a set of lead jacks on the left side of the Therapy Profile mode or the Advanced Therapy Profile mode. unit.
  • Page 14 Combo - CM Models Only The Winner CM4 and CM2 units allows the user to combine a stim treatment with an ultrasound treatment by emitting stimulation and ultrasound through the soundhead at the same time. Quick and easy “self-jacking” can be accomplished by taking the lead cord from the stim channel you want to use and plug the desired lead tip into the special ultrasound jack for combination therapy.
  • Page 15 Electrical Stimulation Site Preparation, Electrode Removal and Storage of Electrodes Turn off the stimulation device and disconnect the cabling. Attachment, and Maintenance Guidelines Remove the electrodes from the skin and reapply to the plastic 1) Know the stimulation characteristics, indications, and backing.
  • Page 16 Patient Electrode Connection Plug shielded ends of lead cord into the output jacks on the device (red end into red jack and white end into white jack for each channel) Insert pin end of lead firmly into the electrode MAKE SURE THERE IS NO BARE METAL SHOWING BETWEEN PATIENT ELECTRODE and PIN Patient Electrodes Red Shielded Plug...

  • Page 17: Stimulation Indications For Treatment

    Rich-Mar Muscle Stimulator Indications for Treatment Precautions Precautions should be taken when using a Rich-Mar muscle stimulator in the presence of one or more of the following Contraindications and Warnings for Quadpolar IFC, Pre- conditions: Mod IFC, Hi-Volt (Monophasic), & Russian Waveforms 1) When there is a tendency to hemorrhage following WARNING - Federal law restricts this device to sale by or on acute trauma or fracture.

  • Page 18: Electrical Stimulation Wave Forms

    8) This device should be used only under the continued Quadpolar Interferential (four pads) supervision of a physician. Electrical stimulation at higher frequencies (5000Hz) 9) The user MUST keep the device out of the reach of penetrates the skin easily (due to capacitive effects of the skin) children.
  • Page 19 Pre-Mod IFC Interferential Hi-Volt (Monophasic) Parameters: Pre-Mod IFC Interferential operates with a carrier frequency  Carrier Frequency: Not Applicable but it is premodulated within the Winner stimulators. This  Pulse Rate: 2-200Hz Fixed enables a single channel (two-electrode) system to be used. ...

  • Page 20: Ultrasound Indications For Treatment

    Ultrasound Indications for Treatment (Therapeutic Ultrasound) Rich-Mar Ultrasound devices are indicated to produce therapeutic deep heat for the following condi- tions: 1) Relief of pain. 2) Muscle spasms. 3) Joint contractures. But not for the treatment of malignancies. WARNING - Federal law restricts this device to sale by or on the order of a physician or any other practitio- ner licensed by the law of the state in which said person practices.

  • Page 21: Ultrasound Introduction And Overview

    Introduction To stop a treatment, press the “Stop” button. Time will stop The Rich-Mar Winner CM Series are designed to provide flashing and revert to the last treatment time entered. Intensity therapy professionals with the best technology at affordable will revert to zero and the “Ultrasound Active” light will prices.

  • Page 22: Ultrasound Calibration & Tuning Procedures (Cm Models Only)

    Ultrasound Calibration and Tuning Frequency and Setting Voltage Tuning Procedure 5cm @ 1MHz Install the 5cm soundhead into the Ultrasound Service Information wattmeter making sure that only the face of the transducer is submerged. Rich-Mar Corporation recommends that all Zero the wattmeter. Rich-Mar ultrasonic therapy products be 2) Hold down the Start/Stop switch and returned to the factory or to a servicing Rich-...

  • Page 23: Cleaning Recommendations

    Cleaning Recommendations Tuning Frequency and Setting Voltage cont. To disinfect the soundhead(s) between therapy 10cm @ 1MHz treatments, Rich-Mar recommends using an Install the 10cm soundhead into the wattmeter making sure that only the face Ultrasound Disinfectant. OSHA address the of the transducer is submerged.

  • Page 24: Converting Between 230 Vac And 115 Vac

    Changing the Voltage from 115V to 230V WARNING: RISK OF ELECTRICAL SHOCK. Unplug unit prior to changing the voltage from 115 to 230. 3. Holding the regulator so that 1. After unplugging the unit, open 2. Once the outlet cover is open, 115V is right-side up, remove the the outlet cover with a flathead insert the flathead screwdriver into...
  • Page 25 Changing the Voltage from 230V to 115V WARNING: RISK OF ELECTRICAL SHOCK. Unplug unit prior to changing the voltage from 230 to 115. 3. Remove the two .5 amp slow 1. After unplugging the unit, open 2. Once the outlet cover is open, blow fuses from the voltage the outlet cover with a flathead insert the flathead screwdriver into...

  • Page 26: Trouble Shooting

    Trouble Shooting Winner Accessories Rich-Mar Corporation takes pride in its Technical Support The accessories that come standard with the Winner units, as Hotline: 1-888-549-4945. We have an outstanding staff ready well as the optional accessories available for the unit, are to take your calls and help with diagnosing and listed below.

  • Page 27: Appendix A

    APPENDIX A ULTRASOUND TECHNICAL INFORMATION...

  • Page 28: Ultrasound Technical Information

    Ultrasound Technical Information Applicator Type: The ultrasonic radiation fields produced by Rich-Mar therapeutic ultrasound transducers are of the plane wave type and are essentially cylindrical in shape. This type of applicator is referred to as a collimating applicator. Applicator Label: Each Rich-Mar applicator is labeled to provide the user with information on its applicable parameters.
  • Page 29 Transducer Parameters and Tolerances: Autosound Applicator The Rich-Mar ultrasound units operate at frequencies of either 1MHz or 3MHz +/- 10%. The effective The error in indication of radiated power in intensity radiating areas (ERA) of the transducers are ten, five, for the pulsed mode does not exceed +/-14% allowing three and a half (3.5), or two square centimeters, for an allowable 6% error in the wattmeter, which...
  • Page 30 The Rtpa tolerance does not exceed +/- 20%. The temporal maximum intensity for each duty cycle as well as the 100% modulation is whatever is indi- cated on the meter. The temporal average intensity for each duty cycle will be the meter indication multiplied by the percentage duty cycle.
  • Page 31 Page Intentionally Left Blank...
  • Page 32 Manufactured for: 3059.16.04.B ©2019 Compass Health Brands Corp.
