- Page 1 100BASE-T1 MEDIACONVERTER USER MANUAL July 2020 Manual-Version: 2.5 Hardware-Version: 1.5...
-
Page 2: Table Of Contents
Status LEDs (2) ..................10 Configuration ....................11 Standard usecase ..................12 100BASE-T1 filter ..................13 Additional information ................... 14 List of figures ....................15 Changelog ...................... 16 Contact ......................17 10 Declaration of conformity ................18 100BASE-T1 MediaConverter NXP User Manual... -
Page 3: Product Description
1 Product description 1.1 Functionality Figure 1-1: 100BASE-T1 MediaConverter_NXP The Technica Engineering 100BASE-T1 MediaConverter_NXP transmits data frames directly from the physical layer BroadR-Reach (100BASE-T1) to Fast Ethernet (100BASE-TX) with a constant delay time of 2.0µs. 1.1.1 Features 1 port BroadR-Reach (100BASE-T1) Ethernet with NXP TJA1100 Transceiver... -
Page 4: Technical Data
Should Technica Engineering’s products be operated in voltage ranges beyond those specified in the norms, which represents a breach of the conditions of operation, then this will void the product warranty and Technica Engineering will assume no liability whatsoever for the results and/or consequences thereof. -
Page 5: Warranty And Safety Information
The operator/user of this devices must take measures for the right protection of the power supply lines and the according connector. The maximum power consumption of the Technica Engineering products is written in this user manual. Please take care that some of the products are working with a step-up converter. So, the current needed in case of undervoltage conditions must be considered as higher than at nominal voltage level. - Page 6 When integrating the modules in a vehicle or test set-up, the user must ensure appropriate ventilation or air convection. Technica Engineering products must not be considered as a safety element out of context when using safety-critical systems and must be included in the safety assessment when used. The development class in a safety system must be taken into account with standard QM referred to ISO26262.
-
Page 7: Rohs Certificate Of Compliance
1.3 RoHS certificate of compliance Technica Engineering’s 100BASE-T1 MediaConverter NXP complies with RoHS (Restriction of Hazardous Substances Directive) Certificate of Compliance. 1.4 Scope of delivery The delivery includes: 1x 100BASE-T1 MediaConverter NXP 1x 1m Ethernet Cable 1x Black MQS Connector... -
Page 8: Hardware Interfaces
The pinning of the ECU connectors is listed on the label on top of the device as well. (See 2-1). IGURE The power supply for the device is supplied by pin 1 (12 Volt) and pin 10 (Ground) If you apply a voltage higher than 18 volts, the device will be damaged! 100BASE-T1 MediaConverter NXP User Manual... -
Page 9: Ethernet Connectors(3)
100BASE-T1 port, negative n.c. 100BASE-T1 port, positive n.c. Table 2: Pinning of black MQS connector 2.1.2 RJ-45 ethernet connectors(3) There is one RJ45 Standard Ethernet connector for Fast Ethernet (100BASE-TX). 100BASE-T1 MediaConverter NXP User Manual... -
Page 10: Other Interfaces
There is a bug in the used BroadR-Reach PHY. When the 100BASE-T1 Plus and Minus lines are swapped, and the 100BASE-T1 port is set to Slave then the Link LED is lit, but there is no data transmission possible. So please connect the 100BASE-T1 lines correctly. 100BASE-T1 MediaConverter NXP User Manual... -
Page 11: Configuration
In a 100BASE-T1 Link one device has to be set as Master, the other has to be set as Slave. The 100BASE-T1 MediaConverter_NXP should always be set to FullOut. HalfOut was a former configuration for EMC optimization but it will cause an unstable link. 100BASE-T1 MediaConverter NXP User Manual... -
Page 12: Standard Usecase
Figure 4-1: Example of a use case MediaConverter Device under Test. DIP-Switch 2 should be always ON, DIP-Switch 1 is dependent on the DUT. If DUT is Master, MC must be configured as Slave (DIP-switch 1: OFF) and vice versa. 100BASE-T1 MediaConverter NXP User Manual... -
Page 13: 100Base-T1 Filter
5 100BASE-T1 filter The following 100BASE-T1 filter is used in the 100BASE-T1 MediaConverter_NXP Hardware version 1.0 and following Figure 5-1: 100BASE-T1 filter for HW v1.0 and following 100BASE-T1 MediaConverter NXP User Manual... -
Page 14: Additional Information
MediaConverter_NXP is the used transceiver for the 100BASE-T1 PHY. At the beginning of development, there were problems with the interoperability of different PHY manufacturers. Now the interoperability is given, and the functionality is independent of the PHY manufacturer. 100BASE-T1 MediaConverter NXP User Manual... -
Page 15: List Of Figures
7 List of figures Figure 1-1: 100BASE-T1 MediaConverter_NXP ..............3 Figure 2-2 100BASE-T1 MediaConverter_NXP ..............8 Figure 4-1: Example of a use case .................. 12 Figure 5-1: 100BASE-T1 filter for HW v1.0 and following ..........13 100BASE-T1 MediaConverter NXP User Manual... -
Page 16: Changelog
July 2020 of Technica Engineering’s Products 1.1.5 Added information on General Design Rules for the Power Supply of Technica Engineering’s Products Warranty and Safety Information updated RoHS Certificate of Compliance added Declaration of conformity added 100BASE-T1 MediaConverter NXP User Manual... -
Page 17: Contact
If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Technical support: support@technica-engineering.de General information: Info@technica-engineering.de Most current user manuals and product information: https://technica-engineering.de/en/ 100BASE-T1 MediaConverter NXP User Manual... -
Page 18: Declaration Of Conformity
Български English С настоящото Technica Engineering GmbH Hereby, Technica Engineering GmbH declares декларира, че продуктът Модул за улавяне that the product 100BASE-T1 MediaConverter 100BASE-T1 MediaConverter NXP (TE1600), е (TE1600), complies with Directive в съответств ие с Директива 2014/30/ЕС. 2014/30/EU. The full text of the EU declaration Цялостният... - Page 19 Internet: geraadpleegd op het volgende internetadres: https://technica-engineering.de/wp- https://technica-engineering.de/wp- content/uploads/2021/03/eu-declaration-of- content/uploads/2021/03/eu-declaration-of- conformity-1600.pdf conformity-1600.pdf Latviešu Polski Ar šo Technica Engineering GmbH deklarē, ka Technica Engineering GmbH niniejszym produkts 100BASE-T1 MediaConverter NXP oświadcza, że produkt 100BASE-T1 (TE1600), atbilst Direktīvai 2014/30/ES. Pilns MediaConverter NXP (TE1600), jest zgodny z ES atbilstības deklarācijas teksts ir pieejams...
- Page 20 Slovensky Technica Engineering GmbH týmto vyhlasuje, že produkt Capture Module LIN Combo (TE- 1170), je v slade so smernicou 2014/30/EÚ. Úplné EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: https://technica-engineering.de/wp- content/uploads/2021/03/eu-declaration-of- conformity-1600.pdf 100BASE-T1 MediaConverter NXP User Manual...
