  • Page 1 IST 03 C 358 - 01 BALI RTN INSTALLATION, USE AND MAINTENANCE...

  • Page 2: Warnings

    Dear Customer, Thank you for choosing and buying one of our boilers. Please read these instructions carefully in order to install, operate, and maintain this equipment properly.

  • Page 3: General Notes For The Installer, Maintenance Technician And User

    GENERAL NOTES FOR THE USER AND THE INSTALLER This INSTRUCTION BOOKLET is an When installing the equipment do IMPORTANT integral and essential part of this not throw the packing away. All the For equipment powered by gas fuel, if product and must be handed to the materials can be recycled and must you smell gas in the area, proceed as user by the installer for safekeeping...

  • Page 4: Table Of Contents

    CONTENTS Warnings ....................................... page 2 General notes for the installer, maintenance technician and user ......................page 3 1 Instructions for the user ..............................page 5 1.1 Control panel ....................................... page 5 1.2 Operating the boiler...................................... page 6 1.2.1 Switching on ...................................... page 6 1.2.2 Switching off ......................................

  • Page 5: Instructions For The User

    1. INSTRUCTIONS FOR THE USER 1.1 CONTROL PANEL fig. 1 1. General switch with line light (green) 5. Overheating cut-out LED (red) 8. Burner operation LED (yellow) 2. Reset button 6. LED to indicate cut-out due to no 9. Water thermometer (models RTN 18 3.

  • Page 6: Operating The Boiler

    1.2 Operating the boiler (fig. 1) • Switch the boiler’s main switch 1 to the On “E” models the cut-out light 7 comes ON position (the switch lights up). on. Should this happen, proceed as 1.2.1 Switching on • Turn the heating water temperature follows: adjustment knob 3 to set the temperature •...

  • Page 7: Cut-Out Due To Incorrect Draught On The Flue

    1.2.5 Cut-out due to incorrect draught 1.2.6 Cut-out due to insufficient gas Qualified personnel may install specific in the flue pressure (on models RTN 70 to RTN original kits on the boiler. 100) Should conditions arise that lead to a Manufacturer accepts faulty draught in the flue, the boiler cuts...

  • Page 8: Technical Characteristics And Dimensions

    2. TECHNICAL CHARACTERISTICS AND DIMENSIONS 2.1 Technical characteristics The models from RTN 18 to RTN 48 are pump operation, burner operation, fitted with a thermoelectric valve and a overheating cut-out, cut-out due to lack These boilers are fitted with a high piezoelectric ignition unit.

  • Page 9: Dimensions

    2.2 Dimensions Flue gas duct D MODEL L (mm) Flow M Return R Gas G (mm) RTN / RTN E 18 G1” 1/2 G1” 1/2 G 3/4” RTN / RTN E 24 G1” 1/2 G1” 1/2 G 3/4” RTN / RTN E 32 - RTN / RTN E 36 G1”...

  • Page 10: Technical Data

    2.3 Technical Data MODELS RTN / RTN E RTN / RTN E RTN / RTN E RTN / RTN E RTN / RTN E EC Efficiency class ★★ ★★ ★★ ★★ ★★ EC PIN 49BN3789 Category II2H3+ Type B11BS Heat output 18.0 24.0 31.5...
  • Page 11 MODÈLES RTN E 60 RTN E 70 RTN E 80 RTN E 90 RTN E 100 EC Efficiency class ★★ ★★ ★★ ★★ ★★ EC PIN 49BN3790 Category II2H3+ Type B11BS Heat output Heat input 76.3 87.3 98.2 109.7 Performance at nominal load 91.7 91.7 91.7...

  • Page 12: Instructions For The Installer

    3. INSTRUCTIONS FOR THE INSTALLER 3.1 Installation standards Manufacturer accepts 3.2.5 Flue gas discharge system responsibility for damage to people, This boiler must be installed in compliance animals, or property due to failure to The BALI boilers are fitted with a flue gas observe the instructions above.

  • Page 13: On-Site Measurement Of Combustion Efficiency

    3.2.6 On-site measurement A two-pole switch must be fitted 3.3 Filling the system combustion efficiency upstream of the boiler to allow all maintenance work to be carried out in Once all the connections in the system To determine combustion efficiency the complete safety.

  • Page 14: Preliminary Checks

    3.4 Starting the boiler 3.5 Wiring diagrams 3.4.1 Preliminary checks BC: Flame control EA: Ignition electrode Before starting the boiler it is advisable to check that: ER: Flame detection electrode • The flue gas duct has been installed in compliance with F1: Protection fuse F4A 250V instructions.

  • Page 15: General Layout

    3.5.1 General layout mod. 18 - 48 RTN fig. 6 mod. 18 - 48 RTN E fig. 7...
  • Page 16 mod. 60 RTN E fig. 8 mod. 70 - 100 RTN E fig. 9...

  • Page 17: Topographycal Diagrams

    3.5.2 Topographical diagrams mod. 18 - 48 RTN fig. 6A mod. 18 - 48 RTN E fig. 7A...
  • Page 18 mod. 60 RTN E fig. 8A mod. 70 - 100 RTN E fig. 9A...

  • Page 19: Gas Conversions

    3.6 Gas conversions • Unscrew the pressure regulating cap on • Remove the LPG nozzle on the main the gas valve and tighten the pressure burner and fit the natural gas nozzle, Changing a boiler over from natural gas regulating screw all the way. checking that this is as indicated in the to LPG and vice versa is only to be carried •...
  • Page 20 Tel. +39 0365 878.31 - Fax +39 0365 878 524 e mail: info@fondital.it - www.fondital.com The producer reserves the right to modify the data contained herein at any time without prior notice. Uff. Pubblicità Fondital IST 03 C 358 - 01 Ottobre 2009 (10/2009)
