- Page 1 Twin Top Overbed Table (948) Assembly & User Instructions Please read these instructions carefully before assembling or using this product. Ensure you are familiar with all of the safety and user instructions. Retain all packaging until you have accepted the product.
-
Page 2: Important Safety Information
Introduction The Twin Top overbed table can be used in conjunction with a bed or a chair, and is ideal for reading, writing, using a laptop computer, etc. It has two height adjustable tabletops, the larger of which is angle adjustable and has two lips to help prevent items slipping off the table. - Page 3 Parts Table top Table upright Table base Hardware 15mm Allen bolt x 4 40mm Allen bolt x 2 Washer & nut x 1 Base plate x 1 4mm Allen key x 1 5mm Allen key x 1 Spanner x 1...
- Page 4 Table Assembly Ensure the ‘plate’ on the bottom of the table upright (B) is positioned in the direction shown. Step 1 Step 1 b: Attach using 4 x 15mm allen bolts and Attach the table upright (B) to the table top (A).
- Page 5 Table Assembly Step 2 Step 2 b: Insert the 2nd 40mm allen bolt (2) up With help, attach the table base (C) to the table upright (B). through the table upright (B) and table base (C), fix using the washer and nut (3). a: Insert the 1st 40mm allen bolt (2) Tighten using the supplied 5mm allen key through the base plate (4), table base...
- Page 6 Table Adjustment Caution: • Remove all items from the table tops before any adjustments. Lift up to Push Down to Lock • When adjusting the table height/ angle, the table will drop unless it is supported. Lock Unlock • Do not force the main table when adjusting the angle.
- Page 7 Spares Available Z948 HGT: Height adjustment knob Z948 BC: Castor (Braked) Z948 ANG: Angle adjustment knob Z948 UC: Castor (Unbraked) Care and Maintenance • The table can be wiped down with a warm damp cloth and mild disinfectant. Do not use hot water or abrasive cleaners as these can damage the table. •...
