- Page 1 R6020 Temperature & Humidity USB Data Logger Instruction Manual REED-Direct.ca info@REED-Direct.ca 1.800.561.8187...
-
Page 2: Table Of Contents
Product Disposal and Recycling ..............9 Product Support ..................10 Introduction Thank you for purchasing your REED R6020 Temperature & Humidity USB Data Logger. Please read the following instructions carefully before using your instrument. By following the steps outlined in this manual your data logger will provide years of reliable service. -
Page 3: Product Quality
Product Quality This product has been manufactured in an ISO9001 facility and has been calibrated during the manufacturing process to meet stated product specifications. If a certificate of calibration is required please contact the nearest authorized REED distributor or authorized Service Center. Please note an additional fee for this service will apply. -
Page 4: Specifications
Specifications Temperature Measuring Range: -40 to 158°F (-40 to 70°C) Accuracy: ±1.8°F (1.0°C) Resolution: 0.1°F/°C Humidity Measuring Range: 0 to 100% RH Accuracy: 0 to 20% & 80 to 100%: ±5% 20 to 40% & 60 to 80%: ±3.5% 40 to 60%: ±3% Resolution: 0.1% RH General Specifications Datalogging Capabilities: Real-Time Clock and Date Stamp: Settable Alarms:... -
Page 5: Instrument Description
CD-ROM drive from your computer. Double click on the setup file and follow the on-screen prompts to install the software. If your computer does not have a CD drive please visit www.reedinstruments.com/software to download the latest R6020 software. Battery Installation or Battery Replacement A 3.6V battery is provided with the R6020. Please note that only a 3.6V battery should be used with the instrument. -
Page 6: Setting Up Or Downloading Data
Setting up or Downloading Data Once the software and battery have been installed, insert the R6020 in an available USB port on your PC. Double click the software icon on your desktop to load the program. In the bottom left corner of the software window there is a status indicator that should show your R6020 is connected "Connect". - Page 7 LEDs Status Indication Action Both LED Logging not active Start logging REC ALM lights OFF Low battery or no Install or replace battery installed battery Single Green Logging, no set No action required flash every alarm triggered** 10 seconds* REC ALM Double Green Manual start was Press and hold the...
-
Page 8: Led Status Notes
I cannot install my software on my work computer, do you know why? Please note that you will require administrative rights to install and run the R6020 software. In order to install and run the software you will have to contact your IT department/personnel. -
Page 9: Product Care
REED Instruments guarantees this instrument to be free of defects in material or workmanship for a period of one (1) year from date of shipment. During the warranty period, REED Instruments will repair or replace, at no charge, products or parts of a product that proves to be defective because of improper material or workmanship, under normal use and maintenance. -
Page 10: Product Support
Product Support If you have any questions on your product, please contact your authorized REED distributor or REED Instruments Customer Service by phone at 1-877-849-2127 or by email at info@reedinstruments.com. Please visit www.REEDINSTRUMENTS.com for the most up-to-date manuals, datasheets, product guides and software. Product specifications subject to change without notice. - Page 11 TeST & MeaSURe wITH ConfIDenCe CHeCk oUT oUR LaTeST PRoDUCTS! REED-Direct.ca info@REED-Direct.ca 1.800.561.8187...
- Page 12 REED-Direct.ca info@REED-Direct.ca 1.800.561.8187...
