Setting the Origin for
LaserPoint2
To set the Origin of where the LaserPoint2 cutter will
begin cutting from press the "Enter" button on "Local"
while on the Home Screen using the "Select" button to
highlight it if needed. This will enter the cutter into "Jog
Mode" where the left and right arrows of the control
pad adjust the position of the carriage and the up and
down arrows advance and retreate the media via the
feed rollers. Once you have your media and carriage
in position press the "Select" button, while in the Local
Screen, to move the cursor to "Current" then press
"Enter" and the origin is set.

Home Screen

SPD: 0mm/s PRS: 10g
LOCAL TEST COPY
Reset Select Enter
425.481.3555
Changing LaserPoint2 Speed
and Force
To set speed and force of the LaserPoint2, make sure you
are back in the "Home" screen with "Local" highlighted.
Press "Enter". Use the up and down arrows to adjust the
speed and the left and right arrows to adjust the cutting
force. A typical cutting speed is 500mm/s, and a typical
cutting force is 100.
Local Screen
SPD: 0mm/s PRS: 10g
ORIGIN CURRENT ON
Reset Select
15 17
www.uscutter.com
Control Panel
Enter
