Warning on power connection

Use a proper power cord for your local power supply.
The United States,
Canada
Plug type YP-3
Female end YC-13
Cord type SVT
Rated Voltage 10A/125V
& Current
Safety approval UL/CSA
* Use a rated plug that complies with the regulation of each country/region and the specifications.

Preset Signals

The following table shows the signals and video formats which you can project using this
unit.
When a signal other than the preset signal shown below is input, the picture may not be
displayed properly.
Memory Preset signal
No. (Resolution)
1 VIDEO/60
2 VIDEO/50
3 480/60i
4 576/50i
5 480/60p
6 576/50p
7 1080/60i
8 1080/50i
Continental Europe
YP-12A
YC-13D
H05VV-F
10A/250V
VDE
fH (kHz) fV (Hz)
60 Hz 15.734
50 Hz 15.625
DTV 480/60i 15.734
(720 × 480i)
DTV 576/50i 15.625
(720 × 576i)
480/60p 31.470
(720 × 480p)
(Progressive
NTSC)
576/50p 31.250
(720 × 576p)
(Progressive PAL)
1035/60i 33.750
(1920 × 1035i),
1080/60i
(1920 × 1080i)
1080/50i 28.130
(1920 × 1080i)
UK, Ireland,
Australia, New
Zealand
*
VM0303B
CEE (13) 53 rd
(OC)
10A/250V
VDE
Sync
59.940 –
50.000 –
59.940 SonG/Y or composite
sync
50.000 SonG/Y or composite
sync/composite video
60.000 SonG/Y
50.000 SonG/Y
60.000 SonG/Y
50.000 SonG/Y
Japan
YP-359
YC-13
VCTF
12A/125V
DENANHO
H Size
–
–
–
–
–
–
–
–
