- Page 1 User’s Guide ES1100 Series Unmanaged Fast Ethernet Switches Version 1.00 Edition 5, 07/2019 Copyright © 2019 Zyxel Communications Corporation...
- Page 2 IMPORTANT! READ CAREFULLY BEFORE USE. KEEP THIS GUIDE FOR FUTURE REFERENCE. This is a User’s Guide for a series of products. Not all products support all firmware features. Screenshots and graphics in this book may differ slightly from your product due to differences in your product firmware or your computer operating system.
-
Page 3: Document Conventions
Document Conventions Document Conventions Warnings and Notes These are how warnings and notes are shown in this guide. Warnings tell you about things that could harm you or your device. Note: Notes tell you other important information (for example, other things you may need to configure or helpful tips) or recommendations. -
Page 4: Table Of Contents
Table of Contents Table of Contents Document Conventions ........................3 Table of Contents ..........................4 Chapter 1 Getting to Know Your Switch ......................5 1.1 Overview ............................5 1.1.1 Power over Ethernet (PoE) ..................... 6 1.2 Applications ............................6 1.2.1 Backbone Example Application ................... 6 1.2.2 Bridging Example Application .................... -
Page 5: Getting To Know Your Switch
H A P T E R Getting to Know Your Switch 1.1 Overview This User’s Guide covers the following models: ES1100-8P, ES1100-16, ES1100-16P, ES1100-24, and ES1100- 24E. The Switch can be used to build high-performance switched workgroup networks. Table 1 ES1100 Series Comparison Table... -
Page 6: Power Over Ethernet (Poe)
Chapter 1 Getting to Know Your Switch 1.1.1 Power over Ethernet (PoE) The Switch is a Power Sourcing Equipment (PSE) because it provides a source of power via its Ethernet ports. Each device that receives power through an Ethernet port is a Powered Device (PD). The Switch is configured in consumption mode, that is, it supplies the actual power the PD needs. -
Page 7: Bridging Example Application
Chapter 1 Getting to Know Your Switch Figure 1 Backbone Example Application 1.2.2 Bridging Example Application With its large address table and high performance, the Switch is an ideal solution for department networks to connect to the corporate backbone or for connecting network segments. The following figure depicts a typical segment bridge application of the Switch in an enterprise environment. -
Page 8: Poe Example Application
Chapter 1 Getting to Know Your Switch 1.2.3 PoE Example Application The following example figure shows a Switch supplying PoE (Power over Ethernet) to Powered Devices (PDs) such as an IP camera, a wireless router, an IP telephone and a general outdoor router that are not within reach of a power outlet. -
Page 9: Hardware Description And Connection
Hardware Description and Connection 2.1 Rear Panel The three-pronged power receptacle is located on the rear panel of the Switch. Refer to the power supply requirements on the panel. Figure 4 Rear Panel ES1100-8P ES1100-16 ES1100-16P ES1100-24 ES1100-24E ES1100 Series User’s Guide... -
Page 10: Rear Panel Power Connection
Connect one end of the supplied power cord to the power receptacle on the back of the Switch and the other end to the appropriate power source. For ES1100-8P, ES1100-16, ES1100-16P and ES1100-24E, use the POWER ON/OFF switch to have the Switch power on or off. -
Page 11: Ieee 802.3Az Energy Efficient Ethernet
Switch doesn't support EEE, EEE may not work in the Switch to save power. The EEE feature is enabled by default on the ES1100-16, ES1100-24 and ES1100-24E. Press in the IEEE 802.3az EEE ON/OFF button on the ES1100-8P and ES1100-16P front panel to turn on the EEE feature. -
Page 12: Hardware Installation
Chapter 2 Hardware Description and Connection The following table describes the LEDs. Table 4 LED Descriptions for ES1100-16/24/24E COLOR STATUS DESCRIPTION Green The Switch is on and is receiving power. The Switch is not receiving power. LINK/ACT Green The port is connected to an Ethernet network at 10M or 100M speed. -
Page 13: Wall Mounting
Table 7 Distance between the centers of the holes for wall mounting MODEL DISTANCE ES1100-8P and ES1100-16P 198 mm ES1100-16 150 mm ES1100-24E 210 mm The following figure shows the screw specifications used for wall mounting. • D = 7.00 mm •... -
Page 14: Rack Mounting
Chapter 2 Hardware Description and Connection Note: Make sure the screws are securely fixed to the wall and strong enough to hold the weight of the Switch with the connection cables. Use the mounting holes on the Switch to hang the Switch on the screws. Wall-mount the Switch with the Ethernet ports facing down and the ventilation holes on the side. -
Page 15: Mounting The Switch On A Rack
Chapter 2 Hardware Description and Connection Figure 8 Attaching the Mounting Brackets (ES1100-8P/16/16P/24E) Figure 9 Attaching the Mounting Brackets (ES1100-24) Using a #2 Philips screwdriver, install the M3 flat head screws through the mounting bracket holes into the Switch. Repeat steps to install the second mounting bracket on the other side of the Switch. - Page 16 Chapter 2 Hardware Description and Connection Figure 11 Mounting the Switch on a Rack (ES1100-24) Using a #2 Philips screwdriver, install the M5 flat head screws through the mounting bracket holes into the rack. Repeat steps to attach the second mounting bracket on the other side of the rack. ES1100 Series User’s Guide...
-
Page 17: Chapter 3 Troubleshooting
H A P T E R Troubleshooting This section describes common problems you may encounter with the Switch and possible solutions. Troubleshoot the Switch using the LEDs to detect problems. The PWR LED on the front panel does not light up. •... -
Page 18: Improper Network Cabling And Topology
Chapter 3 Troubleshooting 3.1 Improper Network Cabling and Topology Improper network cabling or topology setup is a common cause of poor network performance or even network failure. Figure 12 Troubleshooting Improper Network Cabling and Topology PROBLEM CORRECTIVE ACTION Faulty cables Using faulty network cables may affect data rates and have an impact on your network performance. -
Page 19: Appendix A Customer Support
• Brief description of the problem and the steps you took to solve it. Corporate Headquarters (Worldwide) Taiwan • Zyxel Communications Corporation • http://www.zyxel.com Asia China • Zyxel Communications (Shanghai) Corp. Zyxel Communications (Beijing) Corp. Zyxel Communications (Tianjin) Corp. • https://www.zyxel.com/cn/zh/ India • Zyxel Technology India Pvt Ltd • https://www.zyxel.com/in/en/ Kazakhstan •... - Page 20 • Zyxel Singapore Pte Ltd. • http://www.zyxel.com.sg Taiwan • Zyxel Communications Corporation • https://www.zyxel.com/tw/zh/ Thailand • Zyxel Thailand Co., Ltd • https://www.zyxel.com/th/th/ Vietnam • Zyxel Communications Corporation-Vietnam Office • https://www.zyxel.com/vn/vi Europe Belarus • Zyxel BY • https://www.zyxel.by Belgium • Zyxel Communications B.V. • https://www.zyxel.com/be/nl/...
- Page 21 Appendix A Customer Support • https://www.zyxel.com/be/fr/ Bulgaria • Zyxel България • https://www.zyxel.com/bg/bg/ Czech Republic • Zyxel Communications Czech s.r.o • https://www.zyxel.com/cz/cs/ Denmark • Zyxel Communications A/S • https://www.zyxel.com/dk/da/ Estonia • Zyxel Estonia • https://www.zyxel.com/ee/et/ Finland • Zyxel Communications • https://www.zyxel.com/fi/fi/ France •...
- Page 22 • Zyxel Communications Poland • https://www.zyxel.com/pl/pl/ Romania • Zyxel Romania • https://www.zyxel.com/ro/ro Russia • Zyxel Russia • https://www.zyxel.com/ru/ru/ Slovakia • Zyxel Communications Czech s.r.o. organizacna zlozka • https://www.zyxel.com/sk/sk/ Spain • Zyxel Communications ES Ltd • https://www.zyxel.com/es/es/ Sweden • Zyxel Communications • https://www.zyxel.com/se/sv/ Switzerland •...
- Page 23 Appendix A Customer Support Turkey • Zyxel Turkey A.S. • https://www.zyxel.com/tr/tr/ • Zyxel Communications UK Ltd. • https://www.zyxel.com/uk/en/ Ukraine • Zyxel Ukraine • http://www.ua.zyxel.com South America Argentina • Zyxel Communications Corporation • https://www.zyxel.com/co/es/ Brazil • Zyxel Communications Brasil Ltda. • https://www.zyxel.com/br/pt/ Colombia •...
- Page 24 Appendix A Customer Support Middle East • Zyxel Communications Corporation • https://www.zyxel.com/me/en/ North America • Zyxel Communications, Inc. - North America Headquarters • https://www.zyxel.com/us/en/ Oceania Australia • Zyxel Communications Corporation • https://www.zyxel.com/au/en/ Africa South Africa • Nology (Pty) Ltd. • https://www.zyxel.com/za/en/...
-
Page 25: Appendix B Legal Information
The contents of this publication may not be reproduced in any part or as a whole, transcribed, stored in a retrieval system, translated into any language, or transmitted in any form or by any means, electronic, mechanical, magnetic, optical, chemical, photocopying, manual, or otherwise, without the prior written permission of Zyxel Communications Corporation. Published by Zyxel Communications Corporation. All rights reserved. - Page 26 Appendix B Legal Information List of National Codes COUNTRY ISO 3166 2 LETTER CODE COUNTRY ISO 3166 2 LETTER CODE Austria Liechtenstein Belgium Lithuania Bulgaria Luxembourg Croatia Malta Cyprus Netherlands Czech Republic Norway Denmark Poland Estonia Portugal Finland Romania France Serbia Germany Slovakia...
- Page 27 Appendix B Legal Information Environment Statement European Union - Disposal and Recycling Information The symbol below means that according to local regulations your product and/or its battery shall be disposed of separately from domestic waste. If this product is end of life, take it to a recycling station designated by local authorities. At the time of disposal, the separate collection of your product and/or its battery will help save natural resources and ensure that the environment is sustainable development.
- Page 28 Appendix B Legal Information • 請參考產品型錄或是彩盒上的作業溫度。 • 設備必須接地，接地導線不允許被破壞或沒有適當安裝接地導線，如果不確定接地方式是否符合要求可聯繫相應的電氣檢驗機構檢驗。 • 如果您提供的系統中有提供熱插拔電源，連接或斷開電源請遵循以下指導原則 - 先連接電源線至設備連，再連接電源。 - 先斷開電源再拔除連接至設備的電源線。 - 如果系統有多個電源，需拔除所有連接至電源的電源線再關閉設備電源。 • 產品沒有斷電裝置或者採用電源線的插頭視為斷電裝置的一部分，以下警語將適用 : - 對永久連接之設備， 在設備外部須安裝可觸及之斷電裝置； - 對插接式之設備， 插座必須接近安裝之地點而且是易於觸及的。 About the Symbols Various symbols are used in this product to ensure correct usage, to prevent danger to the user and others, and to prevent property damage. The meaning of these symbols are described below.
-
Page 29: Index
Index Index Applications IEEE 802.3af Segment Bridge IEEE 802.3az applications installation backbone precautions auto-negotiating ports LED Descriptions Cabling Length LK/ACT certifications viewing Low Power Idle contact information LPI signal copyright customer support mounting brackets Data path loop disclaimer network cable crossover straight-through Network Cable Types... - Page 30 Index rack mounting Rear Panel Rear Panel Power Connection registration product Troubleshooting Improper Network Cabling and Topology wall mounting warranty note ES1100 Series User’s Guide...
