- Page 1 Dimension ES-1016A/ES-1024A Unmanaged 16/24-Port Ethernet Switch User’s Guide Version 1.0 April 2004...
- Page 2 Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patents rights of others.
-
Page 3: Zyxel Limited Warranty
Any replacement will consist of a new or re-manufactured functionally equivalent product of equal value, and will be solely at the discretion of ZyXEL. This warranty shall not apply if the product is modified, misused, tampered with, damaged by an act of God, or subjected to abnormal working conditions. -
Page 4: Interference Statements And Warnings
Dimension ES-1016A/ES-1024A Ethernet Switch Interference Statements and Warnings FCC Interference Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operations. -
Page 5: Customer Support
Dimension ES-1016A/ES-1024A Ethernet Switch Customer Support If you have questions about your ZyXEL product or desire assistance, contact ZyXEL Communications Corporation offices worldwide, in one of the following ways: Contacting Customer Support When you contact your customer support representative, have the following information ready: •... - Page 6 Dimension ES-1016A/ES-1024A Ethernet Switch METHOD SUPPORT E-MAIL TELEPHONE WEB SITE REGULAR MAIL SALES E-MAIL FTP SITE LOCATION SPAIN support@zyxel.es +34 902 195 420 www.zyxel.es ZyXEL Communications Alejandro Villegas 33 sales@zyxel.es +34 913 005 345 1º, 28043 Madrid Spain DENMARK support@zyxel.dk +45 39 55 07 00 www.zyxel.dk...
-
Page 7: Table Of Contents
Dimension ES-1016A/ES-1024A Ethernet Switch Table of Contents Copyright .................................. ii ZyXEL Limited Warranty............................iii Interference Statements and Warnings ........................iv Customer Support ..............................v List of Figures................................viii List of Tables................................viii Preface ..................................ix Chapter 1 Getting to Know Your Switch.......................1-1 Introduction ............................1-1 Features..............................1-1... - Page 8 Figure 2-2 Attaching Mounting Brackets and Screws..................2-2 Figure 2-3 Mounting the ES to an EIA standard 19-inch rack................2-3 Figure 2-4 Rear Panel ............................2-3 Figure 2-5 Front Panel: ES-1016A ........................2-4 Figure 2-6 Front Panel: ES-1024A ........................2-4 Figure 2-7 Front Panel LEDs: ES-1016A......................2-5 Figure 2-8 Front Panel LEDs: ES-1024A......................
-
Page 9: Preface
Congratulations on your purchase of the Dimension ES-1016A/ES-1024A Ethernet Switch. About the Dimension ES-1016A/ES-1024A Ethernet Switches The Dimension ES-1016A/ES-1024A switch is a cost effective Fast Ethernet switch ideal for setting up a small workgroup or for bridging two separate networks. -
Page 11: Chapter 1 Getting To Know Your Switch
Dimension ES-1016A/ES-1024A Ethernet Switch Chapter 1 Getting to Know Your Switch This chapter describes the key features, benefits and applications of your switch. Introduction The switch is a multi-port switch that can be used to build high-performance switched workgroup networks. -
Page 12: Ieee 802.1P Class Of Service
Dimension ES-1016A/ES-1024A User’s Guide • IEEE 802.1p supports two priority queues for outgoing traffic. • Back-Pressure-Base flow control on Half-duplex ports. • Pause-Frame-Base flow control on Full-duplex ports. • Store-and-forwarding switching architecture for abnormal packet filtering. • Supports automatic address learning. -
Page 13: Applications
Dimension ES-1016A/ES-1024A Ethernet Switch Auto-negotiation regulates the speed and duplex of each port, based on the capability of both devices. Flow- control allows transmission from a 100Mbps node to a 10Mbps node without loss of data. Auto-negotiation and flow-control may require disablement for some networking operations involves legacy equipment. -
Page 14: Figure 1-4 Bridging Example
Dimension ES-1016A/ES-1024A User’s Guide The following figure depicts a typical segment bridge application of the switch in an enterprise environment. The two workgroups, the standalone server and the two servers can all communicate with each other and share all network resources. -
Page 15: Chapter 2 Hardware Description And Installation
Dimension ES-1016A/ES-1024A Ethernet Switch Chapter 2 Hardware Description and Installation This chapter describes the hardware installation and gives a functional overview of the switch. Installation Option The switch is suitable for an office environment where it can be rack mounted on standard EIA racks or as a standalone. -
Page 16: Rack-Mount Installation
Dimension ES-1016A/ES-1024A User’s Guide Figure 2-1 Attaching Rubber Feet Do not block the ventilation holes. Leave space between switches when stacking. 2.1.2 Rack-Mount Installation The switch can be mounted on an EIA standard size, 19-inch rack or in a wiring closet with other equipment. -
Page 17: Rear Panel
Dimension ES-1016A/ES-1024A Ethernet Switch Figure 2-3 Mounting the ES to an EIA standard 19-inch rack Rear Panel The three-pronged power receptacle is located on the rear panel of the switch. Refer to the Product Specifications for power specification. Figure 2-4 Rear Panel 2.2.1... -
Page 18: Front Panel
Dimension ES-1016A/ES-1024A User’s Guide Front Panel The front panel of the switch includes the auto-negotiating 10Base-T/100Base-TX RJ-45 ports and the LEDs. 16 RJ-45 Ports Figure 2-5 Front Panel: ES-1016A 24 RJ-45 Ports Figure 2-6 Front Panel: ES-1024A 2.3.1 10Base-T/100Base-TX RJ-45 auto-negotiating ports Your switch comes with 16 or 24 10Base-T/100Base-TX RJ-45 ports depending on the model of your switch. -
Page 19: Front Panel Leds
Front Panel LEDs The LED Indicators give real-time information about the status of the switch. The following table provides descriptions of the LEDs. Figure 2-7 Front Panel LEDs: ES-1016A Figure 2-8 Front Panel LEDs: ES-1024A Table 2-2 The Front Panel LED Descriptions... -
Page 21: Chapter 3 Troubleshooting
Dimension ES-1016A/ES-1024A Ethernet Switch Chapter 3 Troubleshooting This section describes common problems you may encounter with the switch and possible solutions. Introduction Troubleshoot the switch using the LEDs to detect problems. 3.1.1 PWR LED The PWR LED on the front panel does not light up. -
Page 22: Improper Network Cabling And Topology
Dimension ES-1016A/ES-1024A User’s Guide Improper Network Cabling and Topology Improper network cabling or topology setup is a common cause of poor network performance or even network failure. Table 3-4 Troubleshooting Improper Network Cabling and Topology DESCRIPTION PROBLEMS AND CORRECTIVE ACTION... -
Page 23: Appendix A Product Specifications
Full/Half duplex for 10/100Mbps speeds Media Interface All ports are auto-crossover (auto-MDI-X) and auto-negotiating. Exchange Performance and Management Non-Blocking full wire speed forwarding rate: ES-1016A: 3.2Gbps Back plane ES-1024A: 4.8Gbps 14880 PPS for 10BASE-T Packet Forwarding Rate 148800 PPS for 100BASE-TX... - Page 24 Class of Service: IEEE 802.1p Frame size: 1522 bytes Broadcast storm control 19” rack mountable enclosure Dimensions 440(W) x 120(D) x 44(H) mm ES-1016A: 100-240VAC 50/60Hz 0.8A MAX Power Supply ES-1024A: 100-240VAC 50/60Hz 0.8A MAX ES-1016A: 14W Power Consumption ES-1024A: 19W...
-
Page 25: Index
Dimension ES-1016A/ES-1024A Ethernet Switch Index 10 Mbps Ethernet..........2-5 IEEE 802.1p............1-2 Installation Desktop ............2-1 Rack-Mount ..........2-2 About the ES-1000 Series Ethernet to Ethernet Switches ............ix Applications ............1-3 Segment Bridge ..........1-3 LED Descriptions FD/COL ............2-5 LK/ACT ............2-5 PWR..............2-5 Cabling Length ..........3-2 CE ................iv class A..............iv... - Page 26 Dimension ES-1016A/ES-1024A User’s Guide Return Material Authorization number ..See Improper Network Cabling and Topology .. 3-2 LK/ACT LED ..........3-1 Power LED........... 3-1 Service..............iii Standalone Workgroup ........1-3 Syntax Conventions ..........ix ventilation............2-1 Trademarks............ii ZyXEL Limited Warranty ........iii Troubleshooting Note ..............
