7.2 Calibration

The Workshop Pro must be calibrated initially and should periodically re-calibrated.
The reason for this is to maintain creditability and accuracy in tests and acceptance
of data according to international standards. Calibration is not required during daily
use. Periodic calibration should be done every 6 months.
If the Workshop Pro is not active the calibration button will not work. To activate
the unit you will need to follow the process outlined in
Once activated you can navigate from the Main menu > Settings > Calibration
where the steps to complete calibration will be displayed on screen. The steps will
involve orientating the tablet in certain positions and waiting 5 seconds without moving
it.
For any steps where you are unable to visually read the screen a vibration will notify
you of that steps completion.
Calibration Process:
Step Calibration Status
1
User hits "Calibration" within the
settings menu
2
Test setup countdown reaches 0
3
All calibration steps are
completed
4
AutoTest Workshop Pro User Manual
App Action
Calibration displays instructions
with and image and window
begins counting down from 5
Calibration window prompts user
for next orientation with
additional instructions
Calibration window displays the
recorded values during
calibration
Screen prompts "Calibration
saved" towards the bottom of the
screen
section 4.1 of this user manual.
User Action
Arrange the unit according to
the image/instructions. Make
sure the tablet completely
secure/stable and don't bump it
Complete any further
orientations as directed by the
Calibration window
Hit the save icon in the bottom
right of the window
Return to the settings menu
and confirm the date calibrated
underneath Calibration button
Page 18
