LIVARNO Z30845 Assembly Instructions Manual

Chest of Drawers
Introduction
Before assembling and using the product
for the first time, take time to familiarise
yourself with the product first. Read the
following assembly instructions and safety instruc-
tions carefully. Only use the product as described
and for the designated areas of application. Please
keep these instructions in a safe place. If you hand
this product on to a third party, you must also pass
on all documents relating to the product.
Proper Use
The product is suitable for storing and keeping safe
small and lightweight objects. It is designed for use in
private, dry, indoor areas. Any use other than previ-
ously mentioned or any product modification is prohib-
ited and can lead to injuries and / or product damage.
The manufacturer is not liable for any damages
caused by any use other than for the intended pur-
pose. The product is not intended for commercial use.
Description of parts
and features
Top panel
1
Right side panel
2
Trim
3
Bottom connection piece
4
Back panel
5
Left side panel
6
Top connection piece
7
Separating panel
8
Middle connection piece
9
Back / sides (small drawer), preassembled
10
component
Bottom (small drawer)
11
Left front (small drawer)
12
Right front (small drawer)
13
Back / sides (large drawer), preassembled
14
component
64099_liv_Kommode_Content_LB4.indd 3
Bottom (large drawer)
15
Front (large drawer)
16
Wooden dowel (approx. ø 7.8 x 30 mm)
17
Cam pin (approx. ø 6 x 36 mm)
18
Cam connector (approx. ø 15 x 12 mm)
19
Drawer handle
20
Cross-head screw (approx. ø 4 x 20 mm)
21
Metal drawer runner (small drawer)
22
Cross-head screw (approx. ø 4 x 10 mm)
23
Dowel (approx. ø 6 x 30 mm)
24
Cross-head screw (approx. ø 3.5 x 40 mm)
25
Wooden dowel (approx. ø 5.8 x 30 mm)
26
Cam pin (approx. ø 6 x 25 mm)
27
Cam connector (approx. ø 12 x 10 mm)
28
Cam pin (approx. ø 6 x 36 mm)
29
Cross-head screw (approx. ø 4 x 9 mm)
30
Back panel restraint
31
Cross-head screw (approx. ø 2.5 x 16 mm)
32
Cap
33
Metal drawer runner (large drawer)
34
Cross-head screw (approx. ø 3 x 10 mm)
35
Supply Scope
Immediately after unpacking, check that the delivery
is complete and that the product and all its parts are
in perfect condition. Do not under any circumstances
assemble the product if the delivery is incomplete.
1 Top panel
1 Right side panel
1 Trim
1 Bottom connection piece
1 Back panel
1 Left side panel
1 Top connection piece
1 Separating panel
1 Middle connection piece
2 Back / sides (small drawer), preassembled
components
2 Bottoms (small drawer)
1 Left front (small drawer)
1 Right front (small drawer)
4 Back/sides (large drawer), preassembled
components
4 Bottoms (large drawer)
Introduction
