ICOM M802 PROGRAMMING INSTRUCTIONS
Select the channel you wish to
program by turning the large
2
right-hand knob (channel selector
knob)
3 Press the CLAR/RX button
Enter the desired frequency using
4 the keypad, or dial it in using the
two large front panel knobs.
Press and hold the ENT key. When
the small right pointing arrow
disappears, the LCD display
5 reverts back to showing the
channel label, and SIMP is
displayed on the top line, the new
frequency and mode has been set.
Programming Duplex Frequencies into the User Channel Group
Step Instructions
Store the receive frequency
following the instructions for
1
programming a simplex frequency
described above.
2 Press the TX key
Enter the new transmit frequency
5
using the keypad, or knobs.
6 Press and hold the ENT key.
Adding Names/Labels to Your Channels
Step Instructions
Press the Freq/CH button to put
1 the M-802 into the Channel Mode
if necessary.
2 Press the "F" (Function button)
3 Press the Freq/CH
www.radios.net.au t. 07-41257700 f 03-8640-0419 e.
The channel selector knob
selects channels within a
Channel Group.
The small right pointing will
appear next to the RX on
the top line of the LCD
display. The channel label
will be replaced with the
stored frequency and
mode, and a cursor
(underline) will be under
one of the numbers
You are entering a new
receive & transmit
frequency.
Stores the new RX & TX
frequency and mode for
this radio channel into the
M-802's permanent
memory.
What's Happening
Writes the receive
frequency into memory.
LCD displays changes to
the frequency mode and TX
flashes.
Writes the new transmit
frequency into memory.
The LCD display reverts
back to showing the
channel label and DUP
replaces SMIP.
What's Happening
Put the M-802 into the
Channel Mode.
Enable the function mode.
The LCD dial display will
show a line of character
positions.
