ICOM M802 PROGRAMMING INSTRUCTIONS
Turn the right knob left or right
Dialing-in until the desired number in the
6 the selected column displayed in the
Frequency 100 KHz column (in this example
3).
Turn the left knob clockwise to
Dialing-in
move the cursor to the next
7 the
column you want to change (in
Frequency
this example the 10KHz column).
Turn the right knob left or right
Dialing-in until the desired number in the
8 the selected column displayed in the
Frequency 10 KHz column (in this example
1).
Turn the left knob clockwise to
Dialing-in
move the cursor to the next
9 the
column you want to change (in
Frequency
this example the 1KHz column).
Turn the right knob left or right
Dialing-in
until the desired number in the
10 the
selected column is displayed in the
Frequency
1 KHz column (in this example 3).
Press and hold the ENT key. When
the little right pointing arrow
disappears, the LCD display
Store the
reverts back to showing the
new
channel label, and SIMP is
11 Transmit &
displayed on the top line, the new
receive
frequency and mode has been set.
frequency
In this example the radio will
transmit and receive on 14.313
MHz.
Press the FREQ/CH key to toggle
12 Toggle between the channel and
frequency mode.
Note: It is not necessary to set each column individually. Put the cursor
under any of the columns and rotate the right-hand knob, tuning the
15
radio as you would a regular AM / FM radio. Remember, the farther to the
right a column is located, the finer the tuning increment.
Programming Simplex Frequencies into the User Channel Group
Step Instructions
Press the Freq/CH button to put
1 the M-802 into the Channel Mode
if necessary.
www.radios.net.au t. 07-41257700 f 03-8640-0419 e.
14352.0
14352.0
14312.0
14312.0
14313.0
The "SIMP" displayed on
the first line of the LCD
indicates the transmit and
receive frequencies are the
same.
What's Happening
With each press of the CH/
Freq button the LCD
display will toggle back and
forth, displaying the
selected radio channel, and
with the next press
displaying the frequency
stored in that radio
channel.
