Harman JBL VTX-F18S Technical Manual

Technical Manual
JBL VTX-F18S

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• System Input Power Rating:
• Frequency Response (±3 dB): 32.5 Hz – 300 Hz
SYSTEM COMPONENTS:
• Low Frequency Driver:
• Nominal Impedance:
• Bandpass Sensitivity:
• D.C.Resistance:
PACKAGE
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
2000 W Continuous, 8000 W Peak
(AES / 2 hour)
One 2269H, 460 mm (18 in) dia.,100
mm (4 in) dual voice coil, dual neodym-
ium magnet, Differential Drive®, Direct
Cooled™
8 Ohms
92 dB, 1W / 1m (2.83 Vrms at 3.3 ft)
4.8 Ohms +/- 10%
Warranty Card
59660
Carton
5038958
Filler (2)
5038959
PKG, Microfoam (14)
49790P
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test (±1): 15V Input, 20 Hz to 500 Hz
Component Fee Air Sweep Test:
B. L.F.Aural Sweep Test (±1):
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Net Weight:
• Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.

WIRING DIAGRAM

(354096-001X)
Cone Replacement
(with DSP)
20V Input, 10 Hz to 300 Hz
640.1 x 548.6 x 713.7 mm (H x W x D)
(25.2 x 21.6 x 28.1 in.)
45.4 kg (100 lb)
51.7 kg (114 lb)
Input Plate Assy.
5038889
Wire Harness
2269H
413622-001
PCB Assy NL4,8
C8R2269
5022291
Yellow
Black
9-15
