- Page 1 JC MACHINERY & TOOLS INC. Quality We Trust Banner Hot Air Welder JC-4200-PM User Manual Automatic Overlap Banner Welder Automatic Tape welder...
- Page 2 JC MACHINERY & TOOLS INC. Quality We Trust Applications It can be applicable for welding PVC-P、 PE、 TPO、 ECB、 CSPE、 EPDM、 PVDF and other Coated fabric covering, foil and homogeneous or coating sealing film and PE coating fabric. Notice 1. Unplug the tools before opening it to avoid of being hurt by exposed wires or component inside the machine with power 2.
- Page 3 JC MACHINERY & TOOLS INC. Quality We Trust Description 1. The description of Automatic Overlap Banner Welder Power cord Guide wheel Outer shell Control handle Moving switch Lift handle guide wheel Position handle of hot ON/ OFF switch Lift lever air blower Temperature setting Fixed set ( left) of hot...
- Page 4 JC MACHINERY & TOOLS INC. Quality We Trust 2. The description of Automatic Tape Welder 30. Tape fixed set 33. Disc Nut Tape pressure roller 31. Tape fixed cover 34. Tape limit set Tape hot air nozzle 32. Tape circular disc 35.
- Page 5 JC MACHINERY & TOOLS INC. Quality We Trust How to change Tape Welder to Overlap Banner Welder 1. Loosen screw ( 45 ), take down tape fixed set ( 30 ); 2. Loosen screw ( 46 ), take down tape limit set ( 34 ); 3.
- Page 6 JC MACHINERY & TOOLS INC. Quality We Trust viii. Positioning the welder 1. Automatic Overlap Banner Welder Keep both the edge of upper membrane and the side of guide wheel in the same cord of the overlap pressure roller, shown as Figure 1. 2.
- Page 7 JC MACHINERY & TOOLS INC. Quality We Trust 9. After finish the welding job, press the temperature setting knob- to make the hot air blower in a cold blowing condition for 5 mins in order to cool the nozzle. Then to power off the welder. If you want to keep the welding temperature data, before you power off the welder, you can press down both...
