BOLERO40 Series Promotion Kit

6.2 Installing your own SIM card and replacing the internal battery

To insert your own SIM card into the BOLERO40' SIM holder and replace the internal battery by a new one,
follow the steps shown in the package insert.
6.3 Conn ecting BOLERO40 series to your server
When using your own SIM card and another TCP server, the following table shows the basic configuration
settings that should be done in the BOLERO45 device to register the device in the GSM network and enable
internet connection to your TCP-Server. These configuration settings should be done locally via serial port
connection. After inserting your SIM card and powering up the device, send the following commands
(marked in red) from Workbench
Hint: Settings required for a GPRS attachment (please enter your mobile operator's data)
$PFAL,Cnf.Set,GPRS.APN=internet.t-d1.de (enter your operator's APN)
$PFAL,Cnf.Set,GPRS.QOS=3,4,3,0,0
SETUP
$PFAL,Cnf.Set,GPRS.QOSMIN=0,0,0,0,0
$PFAL,Cnf.Set,PPP.USERNAME=t-d1 (if your operator requires)
$PFAL,Cnf.Set,PPP.PASSWORD=gprs (if your operator requires)
Hint: Settings required for a TCP connection (enter your server settings)
Where: 2222.222.222.222 - is the IP-address of the TCP server to be connected;
SETUP
$PFAL,Cnf.Set,TCP.CLIENT.CONNECT=1,2222.222.222.222,1111 (enter your IP and Port)
Hint: Activate GPRS autostart to reconnect automatically when GPRS network connection gets lost.
SETUP
$PFAL,Cnf.Set,GPRS.AUTOSTART=1 (default = 0)
Hint: Enter the SIM PIN to register the BOLERO45 device into the GSM network:
Where: 1111 - is the PIN of the inserted SIM card.
SETUP
$PFAL,Cnf.Set,DEVICE.PIN=1111
Hint: After establishing TCP connection with your remote server, the following ServerLogin data is
automatically sent to your remote server. For more details refer to the Related Documents [1].
$<MSG.Info.ServerLogin>
$DeviceName=AVL Device
$Security=0
$Software=avl_3.0.0 (FBNCT0xFUk80NSByZXY6MDEtTlVhAgEA)
BOLERO45/41
$Hardware=BOLERO45 rev:01-NUa
sends login data
$LastValidPosition=$GPRMC,131040.000,A,5040.4089,N,01058.8536,E,0.01,162.02,250917,,
to your server
$IMEI=357520070404948
$PhoneNumber=+491134501024564
$LocalIP=10.208.151.168
$CmdVersion=2
$SUCCESS
$<end>
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Editor (see Fig. 8) to the
➒
1111 - is the TCP port number of the TCP server to be connected;
(enter the PIN of your (used) SIM card)
Table 8: Adapt device configuration settings to your application conditions.
Table 9: Login data sent automatically from the BOLERO45/41 to your remote server when the
device starts up.
BOLERO40.
Version 1.0.1
Page 20 of 21
