Rear Panel Overview - FALCOM BOLERO40 SERIES Getting Started

BOLERO40 Series Promotion Kit
Item
Testing
IOs as
analogue
inputs:
Testing IOs as digital
outputs:

4.3 Rear panel overview

A description of each of the items on the rear panel is provided in Table 6.
Item Description
Serial port 0
With the serial-toUSB adapter supplied with promotion kit you are able to connect the control-box to
a PC and evaluate the connected BOLERO45/41 device.
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Description
and will generate a falling edge event "IO.e1=fedge" and sets its state to low "IO.s1=low", if:
•
the position of the IO/2-Switch changes from "Digital IN - High" to "Digital IN -Low".
When the reference IO (e.g: IO/2) is configured as analogue input with "$PFAL,IO1.Config=AI,2,10,
you have to calibrate first this IO the low and high voltages. To do it, perform the following steps (e.g.
IO/1):
1. Switch the IO/2-Switch (IO/2) to "Digital IN - Low" position.
2. Send the command "$PFAL,IO0.Calibrate,offset=0" from the Workbench
8) to BOLERO40.
3. Switch the IO/2-Switch (IO/2) to "Digital IN - High" position.
4. Send the command "$PFAL,IO1.Calibrate,gain=15" from the Workbench
8) to BOLERO40.
5. Switch the IO/2-Switch (IO/2) to "Digital OUT / analogue IN" position. This position has a
fixed voltage of approx. 6V.
Now, you can configure an alarm (e.g. $PFAL,CNF.Set,AL31=Sys.Timer.e1&IO.s1>6.0:IO6.Set=high) to
switch on an LED (e.g. IO/3) when the voltage on the IO/3 is higher than e.g. 5.0 V. To test it, perform
the steps below:
6. Send
"$PFAL,CNF.Set,AL31=Sys.Timer.e0&IO.s2>5.0:IO13.Set=hpulse,5000"
➒
Workbench Editor
7. Switch the IO/1-Switch (IO/2) to "Digital OUT / analogue IN" position.
8. Send the command "$PFAL,Sys.Timer0.Start=single,1000" from the Workbench
(see Fig. 8) to BOLERO40.
After the timer expires (1 second has passed), the red LED of the BOLERO45/41 (front side, next to
the 6pin accessory port) goes ON for 5 seconds and then turns OFF.
the BOLERO40 device, refer to the Related Documents
When the reference IO (e.g: IO/2) is supposed to be used as digital output, there is no configuration to
be done in the firmware. To test it, perform the steps below:
1. Remove the
"$PFAL,IO0.Config="
2. Switch the IO/2-Switch to the "Digital OUT / analogue IN" position
3. Send the command "$PFAL,IO5.Set=high" to set it to High
4. Send the command "$PFAL,IO6.Set=low" to set it to Low.
Table 5: Components on the top panel of the control-box and their functionality
Figure 12: Rear panel of the control-box.
Table 6: Item description on the rear panel of the control-box.
the
(see Fig. 8) to BOLERO40.
[2].
available configuration
Version 1.0.1
➒
Editor (see Fig.
➒
Editor (see Fig.
configuration
from
Editor
For more details about the LED of
for the IO/2 with
Page 13 of 21
