- Page 1 FUZZ...
- Page 3 Instruction: general info Suspension settings Rear wheel mounting & cs length adjust Adjusting the brake adapter External cable routing Internal cable routing Accessories Tightening torque Maintenance & periodical safety checks Box contents NS BIKES warranty Proof of purchase – warranty card...
- Page 4 FUZZ WARNINGS AND IMPORTANT INFORMATION ATTENTION: Please read this manual carefully. It contains important safety information! WARNING: Extreme riding is a very dangerous sport; it requires an amazing amount of skill. By engaging in this type of activity, you are accepting the risk of possible injury or even death. Even the best bike will not help you land a clean trick if you lack the skills.
- Page 5 FUZZ GENERAL RIDING INFORMATION Riding a bicycle can be dangerous. You must keep this in mind and be cautious at all times. See and be seen. Use lights and reflective clothing in low light conditions. Always wear a helmet when riding. It can save your life.
- Page 6 FRAME CONCEPT & INFORMATION The Fuzz is a true DH machine built to compete with the best in the pits, yet it is a modern do-it-all rig for any gravity assisted riding. The bike has been thrashed by Sam Pilgrim at events like Rampage and proved itself in the real racing environment too, taking podiums at major UCI events, piloted by the Polish DH star Slawek Lukasik.
- Page 7 FUZZ GEOMETRY METRIC EFFECTIVE TOP TUBE based on fork S: 590mm/M: 625mm/L: 655mm travel 200mm REACH S: 405mm/M: 440mm/L: 470mm SEAT TUBE S: 400mm/M: 400mm/L: 410mm SEAT TUBE EFFECTIVE ANGLE HEAD TUBE ANGLE 63.5° 73° BB HEIGHT -2mm CHAIN STAYS...
-
Page 8: Exploded View
FUZZ EXPLODED VIEW Seat stay Rocker arm Front triangle Chain stay Frame main parts Kit 7 Kit 6 Dropouts parts... - Page 9 FUZZ Kit 4 Kit 4 Kit 3 Kit 4 #6801 Kit 4 #6801 #6801 #6801 Kit 3 Kit 1 Kit 1 Kit 5 #6801-12x21x5 #6002 #6002-15x32x9 Rear triangle parts #6002 Kit 5 Kit 4 Kit 4 Kit 4 Kit 3...
- Page 10 *Please note that headsets with OD55 mm bottom cups or other internal headsets won’t fit. Only headsets with a bottom cup with 56mm OD will work with the FUZZ frame. The use of a wrong type of headset can be dangerous & can damage the frame Seatpost &...
- Page 11 FUZZ...
-
Page 12: Internal Cable Routing
The rear shock has to be disassembled for this operation. INTERNAL CABLE ROUTING The Fuzz frame has an option of running the cables inside the frame. Rubber groomets (one hole and closed ones) are included to seal the frame. - Page 13 FUZZ...
- Page 14 FUZZ ACCESORIES: The Fuzz comes with: - neoprene chain stay protector - self-adhesive protective foil for downtube - shock fender The neoprene CS protector should be placed over the rear-derailleur cable to protect it and the frame from the chain.
-
Page 15: Tightening Torque
FUZZ TIGHTENING TORQUE Correct tightening forces on fasteners, nuts, bolts, screws on your bicycle are crucial. Too little force, and the fastener may not hold securely. Too much force, and the fastener can strip threads, stretch, deform or break. Either way, incorrect tighten- ing force can result in component failure, which can cause you to loose control and fall. - Page 16 FUZZ MAINTENANCE & PERIODICAL SAFETY CHECKS DO NOT RIDE THE BICYCLE IF IT YOU SEE ANY DEFECTS. Take care of your frame and you will enjoy it for a longer time. Before every ride you should always make a pre-ride check. It...
-
Page 17: Box Contents
FUZZ BOX CONTENTS: - FUZZ frame - 157mm NS thru axle - seatpost clamp - shock fender - neoprene CS protector - self-adhesive protective foil for down tube SAM PILGRIM FMB CHAMPION NS TEAM RIDER SAALBACH AUSTRIA... - Page 18 FUZZ NS BIKES WARRANTY 1. 7ANNA sp. z o.o. sp. k. (hereinafter on referred to as 7ANNA), manufacturer of NS Bikes, warrants all new full suspension frames for a period of 3 years. 2. If any defects are noticed in the product, the Customer must stop using it immediately and should report this to the dealer that sold it within 14 days.
- Page 19 FUZZ Frame model : ....................PROOF OF PURCHASE - WARRANTY CARD Frame serial number : ....................Shock serial number (if any) : ....................Price : ....................Date of purchase : ....................Dealer’s stamp I certify that I am acquainted with the actual specification of the bicycle (this can be slightly different than that published by the distributor).
- Page 20 FUZZ...
