Summary of Contents for NS BIKES SODA EVO
- Page 2 Instructions: SODA EVO cs lenght adjust Instructions: SODA SLOPE rear wheel mounting Instructions: SODA EVO travel adjust Instructions: SODA SLOPE BB assembly Instructions: SODA EVO / SODA SLOPE external cable routing Instructions: SODA EVO internal cable routing Tightening torque Maintenance: pre-ride & periodical checks...
- Page 3 SAM PILGRIM 2013 FMB TOUR WINNER...
- Page 4 WARNINGS AND IMPORTANT INFORMATION ATTENTION: Please read this manual carefully. It contains important safety information! WARNING: Extreme riding is a very dangerous sport; it requires an amazing amount of skill. By engaging in this type of activity, you are accepting the risk of possible injury or even death. Even the best bike will not help you land a clean trick if you lack the skills.
- Page 5 ATTENTION: When using the Soda EVO frame in the long travel setting (that is when shock bolts inside rocker arm are in the upper hole) the adapter in the droput must be set to long chain stay position! The frame will not work with long travel and short chainstay setup.
- Page 6 What really makes us happy is seeing normal riders using this frame on a day-to-day basis and enjoying years of heavy- duty, trouble-free use. It seems like our aim has been accomplished and we hope that you will be just as happy with your Soda as we are! Have fun! SODA EVO & SODA SLOPE TECH MANUAL...
- Page 7 OVERVIEW OF PRODUCT LINE frameset, available with coil or air shock category: freeride / bike park hype: the do-it-all frameset that can be built into any- thing from a short travel jump bike to a mini dh machine SLOPE frameset, available with air shock category: slopestyle / dirt jumping / bike park hype: radical bike for big moves, takes over where dirt jumping hardtails are not enough...
- Page 8 FRAME CONCEPT & INFORMATION: SODA EVO After several years of serving as our basic workhorse, the popular Soda frameset has undergone a major revamp. Now it’s compatible with 650B wheels, has a longer front end and slacker head angle for more stability. The main pivot has been raised for better pedalling and square bump absorption and the frame now has more travel (adjustable from 160 or 180mm).
- Page 9 FRAME CONCEPT & INFORMATION: SODA SLOPE The Soda Slope is a radical bike for big moves that takes over where dirt jumping hardtails are not enough. It’s most impor- tant feature is that it enables true single speed setups with no chain tensioners or standard derailleur / single front ring setups.
- Page 10 TECHNICAL SHEET: SODA EVO 160-180mm (6.3”-7”) adjustable rear wheel travel AL6061+AL6066 T6 custom formed and butted tubes smooth ‘double pass’ welding in all critical areas rear shock: 216x63mm (8.5x2.5”), mounting hardware: front 22.2 x 8 mm, rear 32 x 8mm...
- Page 11 TECHNICAL SHEET: SODA SLOPE 107mm (4.2”) rear wheel travel pivot around BB allowing true single speed setups AL6061+AL6066 T6 custom formed and butted tubes smooth ‘double pass’ welding in critical areas weight (w/o shock): ~3.05kg rear shock: 190x50mm (7.5 x 2.0”): mounting hardware: front & rear 22.2 x 8 mm head tube: fully integrated taper (IS42/IS52), length: 115mm fits forks with standard 1-1/8”...
- Page 12 REPLACEMENT PARTS: SODA EVO Make yourself familiar with the names of all the main parts of the frame by studying the diagrams below: Fig. 1 Soda EVO frame main parts Fig. 2 Soda EVO frame rocker arm links details...
- Page 13 Fig. 3 Soda EVO frame dropouts / dropout link details Fig. 4 Soda EVO frame main pivot link details...
- Page 14 REPLACEMENT PARTS: SODA SLOPE Make yourself familiar with the names of all the main parts of the frame by studying the diagram below: Fig. 5 Soda Slope frame main parts Fig. 6 Soda Slope frame rocker arm links details...
- Page 15 Fig. 7 Soda Slope frame dropout link details Fig. 8 Soda Slope frame BB / main pivot link details...
- Page 17 Max chainring size is only an approx reference. It can vary depending on the manufacturer, model, cranks & BB used. Biggest tire: The frames will fit the following tires: Soda EVO: 27.5” x 2.6”, Soda Slope: 26”x 2.3”. Note that these numbers are for reference only as the size and shape of the tire can vary depending on the manufacturer and rim width.
- Page 20 SUSPENSION SETTINGS Suspension settings are a matter of personal preference. Some riders like it plush, some like it firm. However here are some suggestions of shock settings that you can use as basic guidelines. Coil shocks: For rider weight of 70kg a 450 lbs spring will give a medium-soft ride in the long travel position (approximate sag35%), and a firm setting in the short travel position (approximate sag: 28%).
- Page 21 INSTRUCTIONS: SODA EVO REAR WHEEL MOUNTING Soda EVO frame are compatible with both 135x10 bolt–on hubs with female oversized axle + side bolts or 135x12 hubs. Two sets of dropouts inserts are included with the frame: 135x10, 135x12. NS 135x12 axle is also included with the frame.
- Page 22 INSTRUCTIONS: SODA EVO CS LENGTH ADJUST Choosing correct dropout inserts set: - For 135x10 bolt-on hubs use dropout inserts with 10mm holes there are no difference between left and right inserts. - For 135x12 hubs use dropouts inserts with 12mm holes: the smaller insert with tread inside is for the drive (right) side drop- out.
- Page 23 * always use threaded 135x12 dropout insert in the drive side (right) dropout! * Soda EVO frame comes with 135x12mm NS thru axle, optionally Rock Shox Maxle 135x12mm could be used. * always set long CS for long travel setup. frame will not work with long travel and short CS setup.
- Page 24 INSTRUCTIONS: SODA SLOPE REAR WHEEL MOUNTING TIP: for frames with horizontal dropouts & single speed we always suggest bolt on hubs or hubs with thru axles and track nuts. This way you can get much more clamping force than with any QR hub. Most riders don’t even use the axle positioners / chain tensioners when running bolt on hubs.
- Page 25 INSTRUCTIONS: SODA EVO TRAVEL ADJUST Fig 13 shows the long travel position (shock bolts inside rocker arm in upper hole) Note that in this setup the dropout inserts must be set to the long chainstay position! The frame will not work with long travel and short chainstay setup. Trying to use the frame anyway with this incorrect setting can damage the frame or result in fatal accidents!!! Fig 13.
- Page 26 INSTRUCTIONS: SODA SLOPE BB ASSEMBLY The Soda Slope frame comes with the main pivot around the BB to allow real singlespeed setups. In order to assemble the swingarm and cancel play in the assembly: -insert bearings into frame with the spacer between them (if removed) or check if bearings are pressed and sit well inside the frame and the spacer is straight -slide CS yoke into place -install BB shell paying attention to the position of the blocking tooth (fig.
- Page 27 Disassemble rocker arm using using a 2x6mm allen key. Make sure you don’t loose washers that are mounted between toptube and rocker. Fig 16. Soda EVO / Soda Slope external cable routing Fig 17. Rocker arm disassembled from top tube (hydraulic brakes)
- Page 28 INSTRUCTIONS: SODA EVO INTERNAL CABLE ROUTING The Soda EVO frame has an option of running the cables inside the frame. In order to avoid damage of the cables we added protective tubes to the frame. Cable installation procedure: - For this process you will need to disassemble the brake hose and / or derailleur cable.
- Page 30 - Make sure derailleur cable exits the downtube on the drive-side, and the brake cable exits from the downtube on the non- drive side. Use included cable housing to protect this area on both sides (Fig. 18). Insert the cables into the chainstays yoke. Adjust the position of the cable housing protector so both it’s ends enter the DT &...
-
Page 31: Tightening Torque
Soda 135x12 Maxle rear hub quick-release axle: follow Rock Shox instructions Soda Slope 135x10mm bolt-on hubs: 29-35Nm Soda EVO / Soda Slope rear derailleur bolt 9 Nm MTB crank to bottom bracket bolts: 40 Nm (or according to manufacturer instructions) 3pcs cranks to bottom bracket bolts: 12Nm, then pinch bolts (if used)–12Nm... - Page 32 MAINTENANCE & PERIODICAL SAFETY CHECKS DO NOT RIDE THE BICYCLE IF IT YOU SEE ANY DEFECTS. Take care of your frame and you will enjoy it for a longer time. Before every ride you should always make a pre-ride check. It should include the following points: clean the frame (note that high-pressure washing may cause damage to some compo- nents on the bicycle so it should be avoided if possible) and examine it CAREFULLY for any indications of potential failures including cracks, corrosion, dents, paint peeling and any other indications of potential problems, inappropriate use or abuse.
- Page 33 For information about servicing the shock and other parts like the headset mounted on the bike it is necessary to follow manufacturers instructions closely. The user manual for the additional parts are supplied in the frame box. BOX CONTENTS: SODA EVO BOX CONTENTS: SODA SLOPE...
- Page 34 Dealer’s stamp I certify that I am acquainted with the actual specification of the bicycle (this can be slightly different than that published by the distributor). Buyer’s signature : ....................Dealer’s signature : ....................SODA EVO & SODA SLOPE TECH MANUAL...
- Page 35 NS BIKES WARRANTY 1. 7ANNA sp. z o.o. sp. k. (hereinafter on referred to as 7ANNA), manufacturer of NS Bikes, warrants all new full suspension frames for a period of 3 years. 2. If any defects are noticed in the product, the Customer must stop using it immediately and should report this to the dealer that sold it within 14 days.
- Page 36 manufactured by: 7anna sp. z o.o. sp. k., Raciborskiego 123, 80-215 Gdansk, POLAND tel +48 520 18 04 / mobile + 48 533 01 90 80 Always wear a helmet when riding. It will not make you deathproof, but will increase your chances to avoid serious injury if you crash (and you WILL crash).
