BIOCHROM EZ READ 400 MICROPLATE READER
QUICK START GUIDE

1. To turn on the instrument:

Connect instrument to a power source using the power supply. Turn on the instrument using the
switch at the back of the instrument.
Please note: Check user's manual for important safety information.

2. To connect the instrument to a PC:

Ensure that you first have administrator rights for installing the software and connecting the
instrument to the PC for the first time. Connect to the PC to the instrument using the USB port
on the PC to the USB port on the back of the instrument using the supplied USB A to B cable.
Determine the communication port (COM) used by the instrument. In the Start menu of the PC,
go to Control Panel\System\Hardware\Device Manager\Ports to determine the COM port used
by the instrument. If you are unsure which COM port is being used, please disconnect and
connect the USB cable and observe which COM port reappears after re-connecting to the PC.
Please Note: The instrument cannot connect to the PC if a COM port higher that 9 is used. If this
is the case please use the supplied COM port reassignment utility to reassign the COM port to
any unused port from 1-9.

3. To connect instrument to ADAP 2.0 software:

Insert the CD supplied with the instrument into a PC, install ADAP. Open ADAP. ADAP will prompt
for a user ID and password. Login using the pre-set ID and password: sadmin/sadmin. Once
logged as sadmin, specific user IDs, passwords and administrative rights may be set.
4. Select Setup/Instrument in the task bar. A dialogue box will open:
Biochrom EZ Read 400 Microplate Reader Quick Start Guide
Under the Instrument tab:
In Baudrate, select 9600
In COM Port, select port as determined in step 2
In Instrument Type, select EZRead400
Version 2.0
