Technical data

Table 8- 1
Product type designation
Radio frequencies
Operating frequency
Maximum radiated power
Antenna gain
Opening angle for sending/receiving
when mounted on a metal surface of 15 cm x 15 cm
SIMATIC RF615A
Operating Instructions, 09/2018, C79000-G8976-C511-01
Technical specifications for the RF615A antenna
ETSI
FCC
ETSI
FCC
CMIIT
ARIB
ETSI
FCC
ETSI
FCC
SIMATIC RF615A
865 to 868 MHz
902 to 928 MHz
≤ 340 mW ERP
≤ 560 mW EIRP
≤ 340 mW ERP
STD-T107: RF650R: ≤ 500 mW EIRP
STD-T106: RF680R/RF685R: < 560 mW
EIRP
-13 dBi ... -5 dBi
Depends on background,
refer to the section "Antenna pattern ETSI
(Page 18)"
Depends on background,
refer to the section "Antenna pattern FCC
(Page 21)"
1)
Horizontal plane: 100°
Vertical plane: 75°
see section "Antenna pattern ETSI
(Page 18)"
Horizontal plane: 130
Vertical plane: 105°
see section "Antenna pattern FCC
(Page 21)"
8
6GT2812-0EA0x
27
