Antenna patterns
6.3 Antenna pattern FCC
Directional radiation pattern of the RF615A (FCC) on metallic mounting surface (15 cm x 15 cm)
Figure 6-8
22
Pattern of the vertical plane of the antenna
Pattern of the horizontal plane of the antenna
Directional radiation pattern of the RF615A (FCC) on metallic mounting surface
Operating Instructions, 09/2018, C79000-G8976-C511-01
SIMATIC RF615A
