ELCOS CIM-256/10 Instruction And User's Manual

UNIT FOR CONTROL AND PROTECTION
OF IRRIGATION MOTOR PUMPSET
MOUNTING AT PANEL
PROTECT
motor pump sets by stopping them
in the event of:
• low oil pressure
• over-temperature
• belt breakage
• minimum fuel level
• low coolant level
• low pump water pressure
• pump water overpressure
• A1 available
• low fuel pressure
GB CIM-256/10
CIM-256/10
TYPE
MADE TO:
PARMA
Tel. +39 0521/772021
E-mail: info@elcos.it - HTTP://www.elcos.it
COMPLETE OF GSM TELEPHONE
ANNUNCIATOR AND
COMMAND SYSTEM
• Notifies up to 3 users via SMS message
when the motor pump is on the alarm
• Allows you to control the stopping and
restarting of the pump
• Allows you to view the status of the
main tools of the control unit
• Comes complete with high-gain antenna
• By simply starting, it automatically
controls the motor pump
• Pump water electronic pressure switch
• Digital pump water pressure gauge
• Assembly also on the machine
and in the open air.
DISPLAY
on the panel the functions of:
• hour-meter
• oil pressure gauge
• water or oil thermometer
• tachometer
• pump water pressure gauge
• timer
• fuel level gauge
• pump protection exclusion
• battery and oil lights
• protections intervention
• emergency stop
®
ITALY
Fax +39 0521/270218
1
